MODULAR COOKTOP
FLUSH AND PROUD INSTALLATION
MULTIPLE PRODUCT WITH DOWNDRAFT VENTILATION
CI905DTTB1, CI764DTTB1, CI604DTTB1, CI392DTTB1, CI392DB1,
CI302DB1, CI905DTTG1, CI764DTTG1, CI604DTTG1, CI392DTTG1,
CI392DG1, CI302DG1 CIT392DX1 and CIT302DX1 models
INSTALLATION GUIDE
NZ AU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CI905DTTB1 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher & Paykel CI905DTTB1

Summary of Contents for Fisher & Paykel CI905DTTB1

  • Page 1 MODULAR COOKTOP FLUSH AND PROUD INSTALLATION MULTIPLE PRODUCT WITH DOWNDRAFT VENTILATION CI905DTTB1, CI764DTTB1, CI604DTTB1, CI392DTTB1, CI392DB1, CI302DB1, CI905DTTG1, CI764DTTG1, CI604DTTG1, CI392DTTG1, CI392DG1, CI302DG1 CIT392DX1 and CIT302DX1 models INSTALLATION GUIDE NZ AU...

  • Page 2: Safety And Warnings

    SAFETY AND WARNINGS WARNING! Electric Shock Hazard Failure to follow this advice may result in electric shock or death. • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance. • Connection to a good earth wiring system is essential and mandatory.
  • Page 3 SAFETY AND WARNINGS READ AND SAVE THIS GUIDE General Use Read these instructions carefully before installing this product. Save these instructions for the local electrical inspector’s use. Installation must comply with your local building and local electricity regulations. This appliance is to be installed and serviced only by Fisher & Paykel trained and supported service technician or qualified person.

  • Page 4: Components Required

    COMPONENTS REQUIRED Supplied: Induction Cooktop and Teppanyaki Communication cable (1) Clamp screws (4) Shims (6) Joiner kit (supplied with auxiliary modules only) T spacer (2) Securing brackets (4) Supplied: Downdraft Ventilation Backing plate T spacer (2) Outlet to suit 2.25" x 12" metal Securing brackets (4) ducting* Clamp screws (4)
  • Page 5 ACCESSING YOUR PRODUCT SPECIFICATIONS For full product, cabinetry and service specifications, refer to the Planning Guide. To access the Planning Guide, scan the QR code or visit fisherpaykel.com/specify. Search by appliance type, product name or model code.
  • Page 6 CHECK CLEARANCES IMPORTANT NOTE Ensure clearances are achieved for the product with the greater clearance requirements. INDUCTION AND CABINETRY CLEARANCE DIMENSIONS TEPPANYAKI MODELS Minimum clearance from side edges of cutout to nearest combustible surface Minimum clearance from rear edge of cutout to nearest combustible surface Minimum clearance from benchtop to: Overhead cabinet centered above the cooktop (non combustible) Rangehood or downward facing combustible surface...
  • Page 7 CHECK CLEARANCES VENTILATION OVERVIEW The Induction and Tepanyaki modules require ventilation to allow cooling of the electronic components within the chassis. When multiple products are installed their individual ventilation requirements must also be combined. For detailed ventilation guidance, refer to the planning guide. VENTILATION OPTION 1 INTAKE VIA SERVICE CHANNEL Air is drawn up from the kick cavity through service channel at rear of...

  • Page 8: Prior To Installation

    PRIOR TO INSTALLATION 1. Ensure cabinetry and servicing specifications have been met and clearances have been considered. Refer to the Planning Guide for details. fisherpaykel.com/specify 615mm 2. Create a 615x390mm cutout in the base of the cavity for the external blower. Ensure cutout is oriented correctly for selected ducting option.
  • Page 9 UNPACK ALL PRODUCTS 1. Ensure all products and accessories are present. 2. Carefully remove products from cartons. Set aside on a protected surface. Dispose of packaging responsibly. 3. Test electrical connections of all products before proceeding with installation.
  • Page 10 PREPARE PRODUCTS 1. Remove foam tape backing before attaching the downdraft outlet and backing plate using the supplied nuts and washers. Ensure ducting orientation has been considered. 2. If required, lift the inner box out of the chassis. Remove both downdraft alignment guides and refit on the opposite side.
  • Page 11 INSTALL IN CUTOUT 1. Gently lower the first product into the cutout. 2. Align the rear of the joining bracket to the back edge of the cutout and slot into place.. 3. Fit cover onto joining bracket before sliding it under the adjacent product.
  • Page 12 INSTALL IN CUTOUT 4. Gently lower additional products and joining strips into cutout as required.
  • Page 13 ALIGN PRODUCTS 1. Slot the T spacers between the products. Adjust positioning to ensure even spacing between products is achieved. 2. Flush installations: Place the shims around the outer edges of the cutout. Adjust positioning to ensure even spacing around the product set is achieved.
  • Page 14 SECURE TO CUTOUT 1. Fit the securing brackets to the base of each cooktop. A minimum of two brackets per cooktop is recommended. 2. Tighten all clamp screws to secure the cooktops to the cutout and joiner strips. 3. Tighten the front and rear clamping bracket screws to secure the downdraft to the cutout.

  • Page 15: Connect Power

    CONNECT POWER Before connecting to the mains power supply check that: The domestic wiring system is suitable for the power drawn by the cooktop. The voltage corresponds to the value given on the rating plate. The power supply cable sections can withstand the load specified on the rating plate. Refer to the Planning Guide for full service information.
  • Page 16 CONNECT POWER CI302, CI392, CIT302 AND CIT392 MODELS Single-phase connection 220 – 240V~ The models are supplied with a cable. This must be wired into a suitably rate plug, permanent connection outlet or power isolator. CI604 AND CI764 MODELS Single-phase connection Two-phase connection 220 – 240V~ 380 – 415V 2N~ CI905 MODELS...
  • Page 17 INSTALL DUCTING 1. Place the external blower into the cutout and connect power cord. 2. Cut ducting to required lengths and slot together. Secure and seal using duct tape.
  • Page 18 LINK PRODUCTS 1. Link each product to the adjacent product using the supplied communication cables. Ensure 8-pin plugs are only connected to 8-pin sockets and 6-pin plugs connected to 6-pin sockets. 2. Connect the downdraft unit to the external blower via the central communication cable.
  • Page 19 SEAL PRODUCTS INTO CAVITY (FLUSH INSTALLATIONS) Some silicone products may cause discoloration of the glass, in most cases this will fade as the silicone cures. Avoid applying too much silicon during installation. 1. Mask the area to be siliconed ensuring all products and the countertop are protected.

  • Page 20: Installer Checklist

    INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER GENERAL … Specified clearances have been maintained. … Products are level – front to back and side to side. … All packaging materials have been removed. … There is constant flow of cool air from the cabinetry to the base of the products. …...
  • Page 21 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2024. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
