- Page 1 INTEGRATED COOLDRAWER WITH ASSISTED OPENING ACCESSORY MULTI-TEMPERATURE DRAWER RB90S ASSISTED OPENING ACCESSORY OPEX1 INSTALLATION GUIDE NZ AU...
- Page 3 CONTENTS Safety and warnings Integrated CoolDrawer™ Supplied parts Handle kit CoolDrawer™ dimensions Assisted Opening Accessory dimensions Product and cabinetry overview Cabinetry dimensions Custom panel dimensions Electrical connection Cabinet preparation Install Assisted Opening Accessory Cabinetry preparation Attach power cord & trim brackets Position product into cabinetry Panel preparation Attach drawer panel...
- Page 4 SAFETY AND WARNINGS READ AND SAVE THIS GUIDE WARNING! Electric Shock Hazard WARNING! To avoid hazard, follow these instructions carefully before Installing or using this appliance. Failure to follow this advice may result in Please make this information available to the persons installing the appliance. electrical shock or death.
- Page 5 INTEGRATED COOLDRAWER™ SUPPLIED PARTS COOLDRAWER™ INTEGRATED COOLDRAWER MULTI-TEMPERATURE DRAWER RB36S & RB90S models MULTI-TEMPERATURE DRAWER RB90S model SERVICE & WARRANTY SERVICE ET GARANTIE ΣΈΡΒΙΣ ΚΑΙ ΕΓΓΎΗΣΗ SERVIZIO E GARANZIA SERVICE & GARANTIE HUOLTO JA TAKUU SERVICE OG GARANTI 保 修 和 维 修...
- Page 6 The handle kit is not supplied and must be purchased separately through an authorised Fisher & Paykel dealer. Visit fisherpaykel.com for more information. Contemporary DESCRIPTION MODEL CODE Stainless steel silver AHD3-RB90S square handle Stainless steel silver AHD5-RD90S square fine handle Stainless steel black...
- Page 7 COOLDRAWER™ DIMENSIONS PRODUCT DIMENSIONS A Overall height of product* B Overall width of product* C Depth of chassis** D Width of internal drawer front E Depth of internal drawer front F Depth of drawer (open) measured from front* * Does not include custom door panel and handle. ** Includes power terminal.
- Page 8 ASSISTED OPENING ACCESSORY DIMENSIONS Actuator Striker Plate Lens cover PLAN VIEW ISOMETRIC VIEW ISOMETRIC VIEW FRONT VIEW PROFILE VIEW PROFILE VIEW ASSISTED OPENING ACCESSORY DIMENSIONS Overall height of Assisted Opening Accessory Depth of lens cover flange Overall depth of Assisted Opening Accessory Distance between centre of lens cover and centre of actuator* Overall width of Assisted Opening Accessory Distance between center of lens cover and outside of main body...
- Page 9 PRODUCT AND CABINETRY OVERVIEW Cabinetry frame Base Panel Bridge Trim (must be removeable to allow AOA servicing) Cabinetry frame with cabinetry components and AOA installed Lens Cover Assisted Fixed shelf Spacer Opening Unit Custom Drawer Striker Plate Cooldrawer (installed Panel upside down) EXPLODED ISOMETRIC VIEW...
- Page 10 CABINETRY DIMENSIONS CRITICAL Fixed Shelf Bridge Trim CRITICAL PROFILE VIEW DETAIL A DIMENSIONS A Overall width of cabinetry frame B Inside width of cabinetry frame C Inside height from top inner face of cabinetry frame to top fixed shelf ISOMETRIC VIEW D Clearance height for AOA unit * min 38 E Inside height of cabinetry frame **...
- Page 11 CABINETRY DIMENSIONS BASE PANEL FIXED SHELF PLAN VIEW PLAN VIEW CABINETY BASE PANEL DIMENSIONS FIXED SHELF DIMENSIONS A Width of cutouts A Width of left hand cutout B Depth of cutouts B Width of right hand cutout C Centre of cutout to centre of cabinetry base panel C Depth of cutouts front of fixed shelf to rear of cutout D Distance from front of base panel to front of cutouts* D Distance from front of fixed shelf to front of cutouts*...
- Page 12 CABINETRY DIMENSIONS BRIDGE TRIM SPACERS IMPORTANT: • Cutout not central to panel and cabinetry. • Bridge trim must be removeable to allow servicing of AOA unit. CENTRELINE OF PANEL AND CABINETRY FRONT VIEW ISOMETRIC VIEW BRIDGE TRIM PANEL DIMENSIONS SPACER DIMENSIONS A Width of cutout A Width of spacers 36-50...
- Page 13 CUSTOM PANEL DIMENSIONS DRAWER PANEL DIMENSIONS A Height of custom drawer panel * min 737 B Height from base of chassis to top of custom drawer panel * min 661 C Height from base of chassis to base of custom drawer panel * min 76 D Width of custom drawer panel min 896...
- Page 14 ELECTRICAL CONNECTION Services can be located on either side of the CoolDrawer and Assisted Opening Accessory. Disconnect power to surrounding appliances before preparing the cavity. 2000mm 2000mm 1850mm 1250mm 2050mm 2050mm COOLDRAWER ELECTRICAL SPECIFICATIONS Supply 230 V, 50 Hz Service 10 amp circuit Socket 3-pin earthing-type...
- Page 15 CABINET PREPARATION INSTALL SPACERS Smooth the sharp edges eg. with a file Secure spacers to either side of cabinet. Ensure there is 35mm* clearance to front of cabinetry frame. 35mm *based on 19mm bridge trim panel Secure the vent ducts by fixing with screws (3x).
- Page 16 INSTALL ASSISTED OPENING ACCESSORY Ø2mm Locate holes at rear of AOA unit marked with drill symbol. Spot drill 2x Ø2mm pilot holes into the Route the accessory power shelf using the marked holes as a guide. cord from the rear of the cabietry.
- Page 17 CABINETRY PREPARATION INSTALL BRACKETS Pre-drill Ø2mm pilot hole at a 45° angle using the accessory as a guide. Ø2mm Locate the brackets to the top of the fixed shelf. Ensure there is 23mm clearance between the front of cabinetry 23mm frame and front of bracket.
- Page 18 ATTACH POWER CORD & TRIM BRACKETS POSITION PRODUCT INTO CABINETRY Connect the power plug to the back Place the Cooldrawer in front of the cabinetry and connect the of the Cooldrawer and clip the power plug to the power outlet. cord in place.
- Page 19 PANEL PREPARATION ATTACH DRAWER PANEL CUSTOM PANEL Refer to the dimensions below for the preparation of the Custom door panel when attaching Locate the top attachment hooks (2x) the attachment hooks. On the rear of the panel predrill holes using a Ø2.5mm drillbit, ensure in correct orientation to the predrilled you do not drill all the way through the custom panel.
- Page 20 ATTACH DRAWER PANEL Close the drawer and ensure there is a 2mm clearance between the rear Remove the panel and adjust the of the panel and cabinetry frame when the drawer is fully closed. If top attachment hooks as necesary. not, the product may have to be pulled back or forward.
- Page 21 ATTACH BRIDGE TRIM SECURE PRODUCT TO CABINETRY Ensure there is a 2mm clearance between the rear of the panel and cabinetry frame when the drawer is fully closed. Adjust if required. With the drawer open place bridge trim panel. Secure with the ability to Open the drawer and secure the remove for servicing product to the cabinetry by securing...
- Page 22 TEST ASSISTED OPENING ACCESSORY ADJUST MODE TEST dial can be used to adjust the overall use settings of your Assisted Opening MODE Accessory. MODE DESCRIPTION Push door Prevents the Assisted Opening Accessory from operating during Push the door to open slightly. The door will 1 - DEACTIVATED installation.
- Page 23 FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Has all packaging been removed from the appliance? Has the power cord been plugged into a properly earthed 3-prong outlet, which has been installed in accordance with all applicable electrical codes? Is the appliance securely fastened to the cabinetry? Is the control panel lit? Does the drawer slide freely and close properly? Can you hear the compressor motor running?
- Page 24 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2024. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
