Page 1 Installation manual KNX building management system domovea domovea basic TJAS671 domovea plus TJAS471...
Page 2 Using the Hager Pilot application..................15 2.5.1 Installing the Hager Pilot application................... 15 2.5.2 Launching the Hager Pilot application.................15 2.5.3 Accessing the configurator without using hager Pilot............16 2.5.4 Logging onto the server.......................16 Using domovea application....................17 2.6.1 Installing the domovea Client application................17 2.6.2...
Page 3 RELATED FUNCTIONS IN THE MENUS....33 Account configuration....................... 33 Parameters.......................... 33 5.2.1 Configuration........................33 5.2.2 Users.............................37 5.2.3 Data management........................ 43 5.2.4 About............................ 44 MY DOMOVEA INSTALLATION........ 46 Dashboard........................... 46 Installation........................... 46 6.2.1 Devices..........................46 6.2.2 Groups..........................47 Automations........................47 6.3.1 Sequences..........................48 6.3.2 Home status.........................
Page 4 Generic..........................65 7.1.6 Network..........................65 Cameras..........................65 IOT devices......................... 65 7.3.1 Philips Hue........................... 65 7.3.2 Sonos............................66 7.3.3 Netatmo..........................66 7.3.4 Tado............................66 Additional connectivity control point................66 7.4.1 Alexa............................. 67 7.4.2 Google Home........................67 7.4.3 IFTTT.............................67 HEMS........................... 68 7.5.1 Hager flow..........................68...
Page 5 INTRODUCTION Purpose of the document INTRODUCTION Purpose of the document The purpose of this document is to get to know the configuration interface of the domovea server. This document defines the steps to be followed to achieve this configuration. To do so, the following condi- tions are usually required: –...
Page 6 Configuration and operation is carried out via the Hager Pilot app. The device has integrates easyTool and allows the complete con- figuration of a KNX installation with easy-compatible devices.
Page 7 – Display and trigger of KNX- and IoT functions via app – Visualisation of the KNX installation via the domovea app – Configuration of Easy-compatible KNX devices via Hager Pilot and the integrated easyTool – Configuration of the visualisation via Hager Pilot and the integrated domovea configurator –...
Page 8 Additional domovea plus product features (TJAS471) – Up to 50 IP cameras can be integrated – Up to 100 sequences can be set (via Hager Pilot) – KNXnet/IP tunnel interface: local access and remote access – Up to 10 virtual thermostats...
Page 9 GENERAL DESCRIPTION Operation Operation 2.3.1 RGB status LED RGB status LED display domovea has an RGB status LED display (Fig. 3/2) to signal errors that have occurred or to display on- going operations in domovea (see Tab. RGB status LED display (Fig.
Page 10 192.168.0.253 / 255.255.255.0. With a fixed IP address, the device immediately adopts the parameters of the server set in the Set- tings menu via the Hager Pilot app under the tab Configuration – Interface – IP address – Manual se- lection: –...
Page 11 GENERAL DESCRIPTION Operation With a fixed IP address, the module does not automatically adopt the alternative address in the event of IP address conflicts in the network (other equipment is already using the fixed IP address). PC mode To be used when a PC is connected directly to the device. This mode activates the DHCP server inte- grated in the module.
Page 12 The device automatically restarts and the status LED flashes green until the restart is complete. Update via Hager Pilot Software update via Hager Pilot is only possible from software version 8.0.x onwards. Open the Hager Pilot application and check the software version in the Settings menu: Fig. 2: Software version (as shown)
Page 13 GENERAL DESCRIPTION Introduction to the domovea server Introduction to the domovea server 2.4.1 Technical data Medium TP1-256 Supply voltage 21 ... 32 V SELV Current consumption 3.3 mA Power supply Supply voltage 230 V~ +10 %/-15% 240 V~ +/- 6% Frequency 50/60 Hz Power consumption depending on CPU load 230 V~...
Page 14 GENERAL DESCRIPTION KNX bus connection terminal USB 2.0 slot 2 x RJ45 slot (100Base-TX)
Page 15 Installing the Hager Pilot application On a mobile device: – Search and download the hager Pilot application from the AppStore or Google Play Store, – install the hager Pilot application; an icon will appear on the screen. On a Windows PC: –...
Page 16 Using the Hager Pilot application 2.5.3 Accessing the configurator without using hager Pilot In some cases, the configurator must be accessed directly without using the hager Pilot application. – Using the web browser This connection mode requires knowing the IP address of the server: –...
Page 17 Only the last two major versions for iOS or the last six major versions for Android are offi- cially supported. On a Windows PC: – search and download the domovea application from the Hager website, – install the domovea application; an icon will appear on the screen. 2.6.2...
Page 18 GENERAL DESCRIPTION Using domovea application 2.6.4 How to change the password If passwords are lost, it is possible to reconnect to the server locally only. This procedure is only possible via a web browser – Connect the device supporting your web browser to the same local network as the server. –...
Page 19 GENERAL DESCRIPTION – Switch to off-line mode . – Press and hold the key for more than 2 seconds to select the operating mode. The indicator light flashes green. – Briefly press the indicator light button until the indicator light flashes blue. –...
Page 20 GENERAL DESCRIPTION Using the KNXnet-IP Secure interface integrated into domovea Using the KNXnet-IP Secure interface integrated into domovea 2.7.1 Configuration of the KNXnet/IP interface in ETS Protecting connected buildings from unauthorized access is increasingly important. To ensure optimal protection, the KNX Secure standard has been developed and integrated into do- movea servers.
Page 21 – The recommended format for a first boot is .knxproj, which includes: – Group addresses – The structure of the building – Information specific to Hager devices TIP: After the initial import, a partial (incremental) import is possible to add new group addresses.
Page 22 GENERAL DESCRIPTION Using the KNXnet-IP Secure interface integrated into domovea Notice Alternative: Export OPC data – Another method to export group addresses from ETS is exporting OPC data. Warning: This method only exports group addresses and requires a backup of the project.
Page 23 GENERAL DESCRIPTION Using the KNXnet-IP Secure interface integrated into domovea In ETS, the domovea server appears as a communication interface with the KNX bus. 2.7.3 Connection to a remote network Connecting to a remote network is only possible with a TJAS471 domovea plus server starting with version 8.0.7.
Page 24 GENERAL DESCRIPTION Using the KNXnet-IP Secure interface integrated into domovea Prerequisites: To establish a remote connection using the KNX / IP interface, the following conditions must be complied with: Have a domovea expert server TJAS471 (software version 8.0.7 or later) Install ETS version 5.7.4 or later (ETS6 is recommended).
Page 25 – Open or create the KNX project – Search the KNXPROD - TJAS471 (domovea plus) program in the ETS online catalog (or down- load it from the Hager website). – Insert TJAS471 (domovea plus) into the project topology – Assign a password to the project (if not already done) .
Page 26 GENERAL DESCRIPTION Using the KNXnet-IP Secure interface integrated into domovea – Configure the secured certificate for the TJAS471. After entering the KNX certificate, three more tunnel addresses appear in ETS under the ‘do- movea plus’ device. Program the physical address –...
Page 27 – Launch the application: The server starts the auto-programming with its local interface. Notice The KNX Secure password is sent to the interface. Enable connection in ETS – Open ETS and go to the ‘Panels’ tab to select ‘all Panels’. – Select ‘Hager controls SAS’ and click on ‘domovea secured proxy app’.
Page 28 GENERAL DESCRIPTION Using the KNXnet-IP Secure interface integrated into domovea – Enter the myHager login to get the connection. It is recommended to add the application as a favorite (star icon). Establish connection with ETS A list of servers connected to the myHager account appears. –...
Page 29 GENERAL DESCRIPTION Using the KNXnet-IP Secure interface integrated into domovea Remote access remains active until one of the following events occurs: – Restarting the domovea server – Disabling installer access by the end user If, for some reason, the connection between ETS and the domovea server does not estab- lish, the connection status should be checked.
Page 30 Optionally, it is possible to enter installation information by clicking on Customer Information Note: Optionally, it is possible to enter installation information by clicking on Customer Information For more information, please see tutorial 3. Create a new domovea project with Hager Pilot easyTool. From a backup file This enables the creation of a new installation from a backup file.
Page 31 FIRST USE Using relearning Using relearning This enables the creation of a new installation when there is no installation backup. This is possible by performing relearning on the installation. Relearning of the installation is only possible if the products have been configured with easyTool.
Page 32 MY PROJECT MY PROJECT Project domovea This section enables the project to be set: – Using the Easytool configuration tool: – click on the Easytool symbol A KNX product configuration window appears, enabling the installation to be set. For more information, refer to the installation manual for the configuration tool TXA100 –...
Page 33 RELATED FUNCTIONS IN THE MENUS Account configuration RELATED FUNCTIONS IN THE MENUS Account configuration This enables the connected user account to be configured. When the connection is established, the general settings are accessible from the drop-down menu on the top right. –...
Page 34 RELATED FUNCTIONS IN THE MENUS Parameters 5.2.1.1 Update Click on Update to view the software versions: – the server version (application software version), – the BSP version (motherboard software version), – the container version (software version – the JVM version (Java virtual machine software version). Click on Update to select the update mode: –...
Page 35 – click on Save to confirm the selection. Remote connection is possible using: – hager Pilot or domovea client. – select the TJAS671-XXXXX or TJAS471-XXXXX server. If the server does not appear on the list, – click on Add a server, –...
Page 36 RELATED FUNCTIONS IN THE MENUS Parameters - Enable remote access to KNX/IP (Only with TJAS471 domovea plus) By activating KNX/IP remote access, you can connect to the server via the Internet using the ETS tool. This feature makes it possible to remotely program devices, monitor groups and other functions. When this function is enabled and fully operational, a green dot is displayed.
Page 37 RELATED FUNCTIONS IN THE MENUS Parameters – Periodic sending of the KNX frame allowing the broadcasting of the date and time on the network (disable by default) – click on Save to confirm the selection. 5.2.1.5 domovea Click on domovea to view: –...
Page 38 RELATED FUNCTIONS IN THE MENUS Parameters If you do not have a Hager Business account, you need to create one now by clicking the Register here link Once identified, the system launches the authentication process. Click on Next. If the authentication does not match your identity, you can change the login by clicking the Change Account link The account is verified and the gateway is now registered in the installer’s myHager account.
Page 39 RELATED FUNCTIONS IN THE MENUS Parameters – Fill in the email address of the owner, – Click on Validate to send a notification for the transfer of administrator rights to the owner; this message includes a link accepting the invitation using their myHager account. b) I am the owner: The handover process is complete and you can log in to the gateway with your myHager ac- count username.
Page 40 5.2.2.2 Finalization of the handover process by owner To finalize the handover, the owner should accept the invitation received by email, using the domovea application on his smartphone. Once the invitation is accepted, connection to the gateway via Hager Pilot is enabled.
Page 41 RELATED FUNCTIONS IN THE MENUS Parameters Click on the link Login with your myHager account? Log in with the owner account on myHager site. Once the account is identified: Click on the TJAS471-XXXXX or TJAS671-XXXXX server.
Page 42 RELATED FUNCTIONS IN THE MENUS Parameters The owner account is now the new administrator account. Warning From this step: – the new installer account is disabled from the gateway when the owner finalization of the handover is complete, – only the owner can permanently or temporarily reactivate the installer’s account. This will enable the installer to remotely control the installation.
Page 43 – click on Export to carry out a backup For more information, please see tutorial 7. Export personal data from Hager Pilot. 5.2.3.2 System diagnostic This part provides all the log files containing the data about the system operation and the tracking of user activities.
Page 44 RELATED FUNCTIONS IN THE MENUS Parameters Click on Download Log Files A text file is generated. 5.2.3.3 Resource management The domovea server has an allocated and restricted space for storing resources by category (mea- surements, photos, videos, etc.). The memory capacity allocated to each category is shown below: If the memory used is less than 80% of the allocated memory.
Page 45 RELATED FUNCTIONS IN THE MENUS Parameters...
Page 46 MY DOMOVEA INSTALLATION Dashboard MY DOMOVEA INSTALLATION Dashboard The Dashboard page can be used when an installation is selected: – go to Architecture to display an overview of the installation elements – The number of groups – The number of devices –...
Page 47 Pilot. Automations (Only with TJAS471 domovea plus) Automations are not available in the configurator with the domovea basic version (TJA670 or TJAS671). They are available in the client application (domogram). For more information, please see tutorial 11. Configure domograms in the domovea appli-...
Page 48 – click on Edit to set the parameters for the action to be performed – add other actions if required. For more information, please see tutorial 12. Configure sequences in domovea expert with Hager Pilot. 6.3.2 Home status Home Status is the general state of the home. Sequences can be activated or deactivated according to this status.
Page 49 MY DOMOVEA INSTALLATION Automations – Rename the home status directly in the field on the top right. – Choose an icon for your home status. You can add a description if necessary. – click on Add a trigger. – configure properties –...
Page 50 MY DOMOVEA INSTALLATION Automations In the table, click on Add an Action to start the configuration. A window is displayed to define the conditions used to perform the execution of the domogram. Getting to understand the domogram When: This is intended to define how you want to launch the execution of the domogram. The following options can be selected: –...
Page 51 MY DOMOVEA INSTALLATION Automations It is intended to define the conditions under which you want the domogram to run. The following options can be selected: – At device's new state – At a new house status – Change in weather forecast Action: It is intended to define the action to be taken with the domogram.
Page 52 To create a device, please refer to the (devices) Depending on the type of device, it is possible to assign a subscription. For more information, please see tutorial 15. Configure a Hager electric meter with easy- Tool and domovea. 6.4.2 Subscriptions A subscription defines the cost of power consumptions for a given installation.
Page 53 KNX products connected to the domovea will be easily accessible via the application of the home au- tomation assistant and the domovea application. Configuration can be easily performed via Hager Pi- lot or the domovea client application.
Page 54 MY DOMOVEA INSTALLATION Pairing the domovea to a Matter wizard 6.5.1.1 Configuration using Hager Pilot For a first configuration of a smart home automation assistant compatible with Matter, two prerequi- sites are required: – the activation of domovea devices that are to be displayed in the application of the home automa- tion assistant –...
Page 55 MY DOMOVEA INSTALLATION Pairing the domovea to a Matter wizard The symbol displayed next to the device indicates that it cannot be added to the list in the application of the home automation assistant. To make it selectable, the device should be assigned to a group (such as Home, Room, Kitchen, etc.).
Page 56 MY DOMOVEA INSTALLATION Pairing the domovea to a Matter wizard The pairing process begins. The server can be connected to a home automation assistant in three easy steps: Open the application of the home automation assistant (Google Home, Apple Home, Alexa, etc.). Add the domovea server as a Matter device or accessory and follow the installation steps specific to each application.
Page 57 MY DOMOVEA INSTALLATION Pairing the domovea to a Matter wizard On the configurator side, a notification confirms the successful pairing process. If the pairing fails, a notification is displayed prompting the user to restart the pairing process, within a 10-minute timer. Notice Possible reasons for unsuccessful pairing: –...
Page 58 MY DOMOVEA INSTALLATION Pairing the domovea to a Matter wizard – Click onLink to other Ap- Upon first login, no products plications in the domovea installation A page dedicated to the are displayed in the Matter configuration of Matter environment links appears.
Page 59 MY DOMOVEA INSTALLATION Pairing the domovea to a Matter wizard When the pairing with the server is complete, it will be identified and displayed in the applica- tion of the home automation assistant. Once the server is detected, KNX devices previously activated in domovea will also appear in the smart assistant application.
Page 60 MY DOMOVEA INSTALLATION Pairing the domovea to a Matter wizard From the domovea client application: – Click Reset Pairing – Click Reset confirmed Smart home assistants are now disconnected from domovea. To restore the use of a smart home assistant with domovea, a complete re-pairing process should be performed.
Page 61 MY DOMOVEA INSTALLATION Configuration For more information, please see tutorial 17. Manage user rights in domovea. Configuration This part is identical to the one dedicated to the configuration from the project (please refer to the (Configuration) chapter)
Page 62 LIST AND DETAILS OF THE DEVICES KNX devices LIST AND DETAILS OF THE DEVICES This section lists all of the peripherals that are available to the installation program to create a project. KNX devices 7.1.1 Comfort Devices Actions Readable Light Switch on Switch off Set the brightness to x%...
Page 63 LIST AND DETAILS OF THE DEVICES KNX devices Devices Actions Readable HVAC mode area x Current temperature of area x Load-shedding Hot water Overtime switch Variance activated Forcing Forcing activated KNX scene Launch scene x Scene x launched Forcing Activate/deactivate forcing Forcing activated/deactivated Audio Switch on...
Page 64 LIST AND DETAILS OF THE DEVICES KNX devices Devices Actions Readable Intruders Intrusion confirmed Alert Silent alarm Fire alarm Technical alarm Door striker Open door Door open 7.1.3 Sensors Devices Actions Readable Temperature Temperature at x°C Wind Wind at x km/h CO2 at x ppm Humidity Humidity at x%...
Page 65 LIST AND DETAILS OF THE DEVICES KNX devices Devices Actions Readable Water Flow rate Counter 7.1.5 Generic Devices Actions Readable Generic device ON/OFF Switch on Switch off Command maintained Switch on Switch off Generic pulsed device Switch on Generic device Writing of value x on the KNX bus The value is equal to x 7.1.6...
Page 66 – click on the Add button, – change the name of the device if necessary, – complete the KNX group addresses if necessary. For more information, please see tutorial 21. Add a Netatmo weather station with Hager Pi- lot. 7.3.4 Tado This enables you to add a smart Tado°...
Page 67 Connect to the Amazon Alexa website or to the Alexa application: – select Skills in the menu, – install the Hager skills domovea, – enter the user name and password for your Alexa account, – enter the user name and password of your myHager account, –...
Page 68 Click on New device : – select hager flow in theHEMS section, – select the flow devices to be integrated into the domovea application. – An installation can include up to 3 charging stations, an energy management controller, a battery and a photovoltaic system.
Page 69 LIST AND DETAILS OF THE DEVICES HEMS Symbols Type of device Functions Value Charging station Connected vehicule Boost available Loading Instantaneous power Value in Watt Fault Energy meter by sup- Instantaneous power (production) Value in Watt plier Instantaneous power (used) Value in Watt Fault Photovoltaic...
Page 70 LIST AND DETAILS OF THE DEVICES HEMS Symbols Type of device Functions Value Instantaneous power (used) Value in Watt Battery status Charging Discharged On hold - Example on how to optimise energy consumption If the battery has a low level of energy available and the photovoltaic system is not producing, the en- ergy consumption should be automatically reduced.
Page 71 LIST AND DETAILS OF THE DEVICES HEMS...
Page 72 LIST AND DETAILS OF THE DEVICES HEMS What is SG Ready? SG-Ready statuses are based on an algorithm used to optimise the energy used by heat pumps. These statuses make it possible to intelligently manage the use of energy accord- ing to its price, availability, current production and needs.
Page 73 Hager Controls BP10140 67703 Saverne Cedex France +33 (0) 3 88 02 87 00 info@hager.com hager.com 2025-04...
