Connect Router to the Network
Port Connection Guidelines
Depending on the chassis and installed line cards, you can use Quad Small Form-Factor Pluggable Plus
(QSFP+), QSFP28, QSFP-DD, SFP, SFP+, CFP2, CFP-DCO, and RJ-45 connectors to connect the ports on
the line cards to other network devices.
To prevent damage to the fiber-optic cables when installing a transceiver in the line card, we recommend that
you disconnect the transceiver from its fiber-optic cables. Before removing the transceiver from the router,
remove the cable from the transceiver. You can change or remove the cable without removing the transceiver.
To maximize the effectiveness and life of your transceivers and optical cables, do the following:
• Wear an ESD-preventative wrist strap that is connected to an earth ground whenever handling transceivers.
• Do not remove and insert a transceiver more often than is necessary. Repeated removals and insertions
• Keep the transceivers and fiber-optic cables clean and dust free to maintain high signal accuracy and to
Port Connection Guidelines , on page 1
Connecting a Console to the Router, on page 2
Connect the Management Interface, on page 3
Installing and Removing Modular Port Adapters, on page 4
Installing Dust Caps, on page 7
Install and Remove Transceiver Modules, on page 8
Connect Interface Ports, on page 19
Maintain Transceivers and Optical Cables, on page 19
Set Fabric Bandwidth Threshold, on page 20
The router is typically grounded during installation and provides an ESD port to which you can connect
your wrist strap.
can shorten its useful life.
prevent damage to the connectors. Attenuation (loss of light) is increased by contamination and should
be kept below 0.35 dB.
• Clean these parts before installation to prevent dust from scratching the fiber-optic cable ends.
• Clean the connectors regularly; the required frequency of cleaning depends upon the environment.
In addition, clean connectors when they are exposed to dust or accidentally touched. Both wet and
Connect Router to the Network
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the NCS 5500 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Cisco NCS 5500 Series

  • Page 1 Connect Router to the Network • Port Connection Guidelines , on page 1 • Connecting a Console to the Router, on page 2 • Connect the Management Interface, on page 3 • Installing and Removing Modular Port Adapters, on page 4 •...
  • Page 2 Connect Router to the Network Connecting a Console to the Router dry cleaning techniques can be effective; refer to your site's fiber-optic connection cleaning procedures. • Do not touch the ends of connectors. Touching the ends can leave fingerprints and cause other contamination.
  • Page 3 Connect Router to the Network Connect the Management Interface Procedure Step 1 Configure the console device to match the following default port characteristics: • 9600 baud • 8 data bits • 1 stop bit • No parity Step 2 Connect an RJ-45 rollover cable to the CONSOLE SERIAL PORT. You can find this cable in the accessory kit.
  • Page 4 Connect Router to the Network Installing and Removing Modular Port Adapters Procedure Step 1 Connect a modular, RJ-45, UTP cable to the MGMT ETH port on the Route Processor card. Step 2 Route the cable through the central slot in the cable management system. Step 3 Connect the other end of the cable to a 10/100/1000 Ethernet port on a network device.
  • Page 5 Online Insertion and Removal Caution Cisco IOS XR Software 6.6.1 and later releases support online insertion and removal (OIR) of Cisco NCS 5500 series modular port adapters (MPAs). Cisco NCS 5500 series modular port adapters (MPAs) support online insertion and removal (OIR). Modular port adapters (MPAs) can be inserted or removed independently from the modular line card (MLC).
  • Page 6 Connect Router to the Network Modular Port Adapter Installation and Removal Modular Port Adapter Installation and Removal This section provides step-by-step instructions for removing and installing a modular port adapter (MPA) in a NC55-MOD-A-S and NC55-MOD-A-SE-S modular line card (MLC). Note After you remove the MPA from the slot, wait for 60 seconds before you reinsert the MPA.
  • Page 7 NC55-CFP2-DCAP(=) Cisco NCS5500 Series Dust cover for CFP2 (Qty: 1 per Kit) Note Dust caps are orderable separately from Cisco and are available for a variety of input/output connectors. Figure 2: SFP Dust Cap Figure 3: QSFP Dust Cap Connect Router to the Network...
  • Page 8 Connect Router to the Network Install and Remove Transceiver Modules Figure 4: CFP2 Dust Cap To install the dust cap: 1. Hold the dust cap by its handle. 2. Insert the dust cap in to the appropriate unused ports (SFP, QSFP, CFP2). Install and Remove Transceiver Modules Install and Remove SFP Modules Before you remove or install an SFP or SFP+ module, read the installation information in this section.
  • Page 9 Connect Router to the Network Bale Clasp SFP or SFP+ Module Figure 5: SFP/SFP+ Module Cage Cover Caution Protect the SFP or SFP+ modules by inserting clean dust covers into them after the cables are removed. Be sure to clean the optic surfaces of the fiber cables before you plug them back into the optical ports of another module.
  • Page 10 Connect Router to the Network Install a Bale Clasp SFP or SFP+ Module Figure 6: Bale Clasp SFP or SFP+ Module Install a Bale Clasp SFP or SFP+ Module To install this type of SFP or SFP+ module, follow these steps: Procedure Step 1 Attach an ESD-preventive wrist or ankle strap and follow its instructions for use.
  • Page 11 Connect Router to the Network Remove a Bale Clasp SFP or SFP+ Module Procedure Step 1 Attach an ESD-preventive wrist or ankle strap and follow its instructions for use. Step 2 Disconnect and remove all interface cables from the ports; note the current connections of the cables to the ports on the line card.
  • Page 12 Connect Router to the Network Remove a Bale Clasp SFP or SFP+ Module Figure 8: Removing a Bale Clasp SFP or SFP+ Module Step 5 Place the removed SFP module on an antistatic mat, or immediately place it in a static shielding bag if you plan to return it to the factory.
  • Page 13 Install and Remove QSFP Transceiver Modules Note In this section, QSFP refers to QSFP+, QSFP28, and QSFP-DD. Refer to the Cisco Optical Transceiver Handling Guide for additional details on optical transceivers. This section provides the installation, cabling, and removal instructions for the Quad Small Form-Factor Pluggable (QSFP) transceiver modules.
  • Page 14 Connect Router to the Network Installing the QSFP Transceiver Module • Antistatic mat or antistatic foam to set the transceiver on. • Fiber-optic end-face cleaning tools and inspection equipment. For information on inspecting and cleaning fiber-optic connections, see Maintaining Transceivers and Optical Cables.
  • Page 15 Connect Router to the Network Attach the Optical Network Cable Figure 11: Seating the QSFP Transceiver Module Attach the Optical Network Cable Before you begin Before you remove the dust plugs and make any optical connections, follow these guidelines: • Keep the protective dust plugs installed in the unplugged fiber-optic cable connectors and in the transceiver optical bores until you are ready to make a connection.
  • Page 16 Connect Router to the Network Removing the QSFP Transceiver Module Step 3 Remove the dust plugs from the transceiver module optical bores. Step 4 Immediately attach the network interface cable MPO connectors to the transceiver module (see the figure below). Figure 12: Cabling a Transceiver Module Removing the QSFP Transceiver Module Caution...
  • Page 17 Connect Router to the Network Installing and Removing CFP2 Modules Figure 13: Removing the QSFP Transceiver Module Step 4 Slide the transceiver out of the socket. Step 5 Place the transceiver module into an antistatic bag. Installing and Removing CFP2 Modules Before you remove or install a CFP2 module, read the installation information in this section.
  • Page 18 Connect Router to the Network Removing a CFP2 Module Figure 14: Aligning a CFP2 Module into a Port Socket Step 3 Slide the CPT2 module in until the EMI gasket flange makes contact with the line card faceplate. Step 4 Press firmly on the front of the CFP2 module with your thumbs to fully seat it in the transceiver socket.
  • Page 19 Connect Router to the Network Connect Interface Ports Procedure Step 1 Attach an ESD-preventive wrist or ankle strap and follow its instructions for use. Step 2 Disconnect and remove all interface cables from the ports; note the current connections of the cables to the ports on the line card.
  • Page 20 Connect Router to the Network Set Fabric Bandwidth Threshold Set Fabric Bandwidth Threshold Fabric bandwidth refers to the percentage of the number of active fabric links and total available links between each NPU and all available fabric cards. Fabric bandwidth algorithm monitors the number of active links on all NPUs of each line card and turns the line card interfaces on or off.
