1136750312 INSTALLATION MANUAL OWNER’S MANUAL AIR CONDITIONER (SPLIT TYPE) Indoor unit RAS-H10, 13, 18, 24B2KCV2G-M Outdoor unit RAS-H10, 13, 18, 24B2ACV2G-M PRECAUTIONS FOR SAFETY Read the precautions This appliance is filled in this manual carefully with R32. before operating the unit. Warning indication Description CAUTION...
Page 2
Follow the precautions provided here to avoid safety risks. Symbols and their meanings are shown below. Incorrect use of this unit can result in a high DANGER possibility of severe injury(*1) or death. Incorrect use of this unit may cause severe injury or WARNING death.
Page 3
DANGER • FOR USE BY QUALIFIED PERSONS ONLY. • TURN OFF MAIN POWER SUPPLY BEFORE ATTEMPTING ANY ELECTRICAL WORK. MAKE SURE ALL POWER SWITCHES ARE OFF. FAILURE MAY CAUSE ELECTRIC SHOCK. • CONNECT THE CONNECTING CABLE CORRECTLY. IF CONNECTING CABLE IS CONNECTED WRONGLY, ELECTRIC PARTS MAY BE DAMAGED.
Page 4
DANGER • THE APPLIANCE SHALL BE INSTALLED IN ACCORDANCE WITH NATIONAL WIRING REGULATION. • THE APPLIANCE MUST BE STORED IN A ROOM WITHOUT CONTINUOUSLY OPERATING IGNITION SOURCES (FOR EXAMPLE, OPEN FLAMES, AN OPERATING GAS APPLIANCE OR AN OPERATING ELECTRIC HEATER). •...
Page 5
WARNING • When an abnormality (burning smell, etc.) occurs, stop the air conditioner and disconnect the power supply or turn off the breaker. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 6
CAUTION • Please read this Safety Manual carefully before installing the unit. It contains further important instructions for proper installation. • The manufacturer shall not assume any liability for the damage caused by not observing the description of this manual. •...
INSTALLATION MANUAL ACCESSORIES PARTS ACCESSORIES PARTS INDOOR Part name Q’ty No. Part name Q’ty No. Part name Q’ty Installation plate Remote controller holder Screw (For 24k model only) Wireless remote controller Mounting screw Ultra Pure Filter Battery Flat head wood screw Instruction Manual (This manual) Maintenance Filter...
Page 9
For 10k, 13k (Unit : mm) Indoor unit outline Hook Hook Installation Pipe hole Hook Hook Pipe hole plate Drain hose position Weight Thread Drain hose position Mounting screw For 16k, 18k (Unit : mm) Indoor unit outline Hook Hook ...
Page 10
When the installation plate is directly mounted on the wall...
Page 11
(To the forefront of flare) Model A mm Push 10k, 13k Gas side Push B mm Liquid side 16k, 18k Outward form of indoor unit R 30 mm (Use polisin (polyethylene) core or the like for bending pipe.) Use the handle of screwdriver, etc.
OUTDOOR UNIT OUTDOOR UNIT Installation Place Refrigerant Piping Connection • A place which provides the spaces around the outdoor unit as shown in Flaring the diagram. • A place which can bear the weight of the outdoor unit and does not allow 1.
Page 13
Outer dia. of copper pipe Tightening torque (N·m) CAUTION Ø6.35 mm 14 to 18 (1.4 to 1.8 kgf·m) • KEEP IMPORTANT 7 POINTS FOR PIPING WORK. Ø9.52 mm 30 to 42 (3.0 to 4.2 kgf·m) (1) Take away dust and moisture (inside of the connecting pipes). Ø12.70 mm 50 to 62 (5.0 to 6.2 kgf·m) (2) Tighten the connections (between pipes and unit).
Page 14
Model Power source 50Hz, 220V Single phase Maximum running current 9.3 A 9.3 A 1 .0 A Circuit breaker rating H07RN-F or 60245 IEC66 Power supply cable H07RN-F or 60245 IEC66 (1.0 mm or more) (1.5 mm or more) H07RN-F or 60245 IEC66 Connecting cable H07RN-F or 60245 IEC66 (1.0 mm or more)
Page 15
Connecting cable connect to Power supply input Wiring Diagram Power supply input at Outdoor Terminal Block Indoor Terminal Block Outdoor Terminal Block Power supply input RESET Button...
INSTALLATION CHECK LIST Model name After finishing installation work, please check items below and hand this sheet to user to Check date keep it in a safe place together with Installation and Owner’s Manual Checked by Note : Please put a mark “ ”...
OWNER’S MANUAL INDOOR UNIT DISPLAY AIR FLOW DIRECTION Operation mode (White) Timer (White) Press : Move the louver in the desired vertical direction. • Display brightness can be adjusted, follow procedure on Press : Swing the air PREPARATION BEFORE USE automatically and press again to stop.
Page 19
ECO OPERATION TEMPORARY OPERATION To automatically control room temperature to save energy In case of the misplaced or discharged remote controller. (except in DRY and FAN ONLY mode) • Pressing the RESET button, the unit can start or stop without using the remote control.
TROUBLESHOOTING (CHECK POINT) The unit does not operate Cooling or Heating is abnormally low • The power main switch is • The filters are blocked with dust. turned off. • The temperature has been set • The circuit breaker is improperly.
