FULL MOTION TV WALL MOUNT
INSTRUCTION MANUAL
PGLF11
MODEL
Thank you for choosing this Perlegear product. We strive to provide you with the best quality
products and service in the industry. If you have any installation questions or issues with the product,
please contact us at the number below.
1-800-456-5231 (US/CA) Mon–Fri, 8am–8pm (CST)
44-808-196-4165 (UK) Mon–Fri, 2pm–10pm (UTC)
Rev00
support@perlegear.com
www.perlegear.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PGLF11 and is the answer not in the manual?

Questions and answers

Related Manuals for Perlegear PGLF11

Summary of Contents for Perlegear PGLF11

  • Page 1 PGLF11 MODEL Thank you for choosing this Perlegear product. We strive to provide you with the best quality products and service in the industry. If you have any installation questions or issues with the product, please contact us at the number below.
  • Page 2 BEFORE GETTING STARTED, LET'S MAKE SURE THIS MOUNT IS COMPATIBLE Compatible VESA Patterns: Max: 200 x 100mm 200 x 400mm 400 x 200mm 23.6 ″ 600mm 200 x 200mm 300 x 200mm 400 x 300mm Max: 200 x 300mm 300 x 300mm 400 x 400mm 15.7 ″...
  • Page 3 TV Bracket Bolt Wall Plate Template Bolt Level Arm Assembly / Wall Plate Power Outlet...
  • Page 4 Supplied Parts and Hardware for Step 1 Not all hardware included in this package will be used. M4/M5 M6/M8 L2.5mm L10mm L22mm Washer Washer Spacer Spacer Spacer TV Bracket 01 x 2 B1 x 4 B2 x 4 F1 x 8 F2 x 4 F3 x 4 M4 x 12mm...
  • Page 5 Supplied Parts and Hardware for Step 4 M4 x 10mm Power Outlet Bolt 05 x 1 G1 x 2 Supplied Parts and Hardware for Step 5 M5 x 14mm Bolt G2 x 2 Supplied Parts and Hardware for Step 6 Level 03 x 1...

  • Page 6: Installation

    INSTALLATION STEP 1 Attach the TV Brackets to Your TV 1-1 Select TV Bolts The correct bolt diameter will thread smoothly into your TV. The depth of the top and bottom holes may differ. 1-2 Position the TV Brackets Arrow Up...
  • Page 7 1-3 Secure the TV Brackets For Flat-Back TV, go to Option A on this page. For Bump, Curved TV, Recessed Holes and Cables, go to Option B on next page. WARNING: • DO NOT turn the bolt past the bottom of the hole. •...
  • Page 8 Washer B1 | B2 them to choose the right spacer combination. Spacer F1 | F2 | F3 Note: There are many possible spacer combinations that can be used. 1-800-456-5231 (US/CA) 44-808-196-4165 (UK) support@perlegear.com...
  • Page 9 STEP 2 Mount the Arm Assembly / Wall Plate on the Wall For mounting on wood stud walls, go to Option A on page 09 to 10. For mounting on solid concrete, go to Option B on page 11 to 12. Option A For Wood Stud Installation Max: 5/8″...
  • Page 10 Mark 4 Hole Positions Drill 4 Holes Note: Be sure to use the specified drill bit. 2 3/4″ 2 3/4″ (70mm) (70mm) ø7/32″ ø7/32″ (5.5mm) (5.5mm) Secure the Wall Plate HEAVY! You may need assistance with this step. A1 x 4 A1 x 4 1/2″...
  • Page 11 Option B For Solid Concrete Installation Min: 8″ (203mm) Tools Needed (Not Included) 3/8″ (10mm) 1/2″ (13mm) Electric Drill Pencil Tape Measure Hammer Concrete Drill Bit Socket Wrench WARNING: [A1] • Avoid the risk of personal injury or property damage! Tighten the lag screws only until they are pulled firmly against the wall plate (DO NOT overtighten).
  • Page 12 Drill 4 Holes Note: Be sure to use the specified drill bit. 3″ (75mm) 3″ (75mm) ø3/8″ ø3/8″ (10mm) (10mm) Tap Wall Anchors In A2 x 4 A2 x 4 Secure the Wall Plate HEAVY! You may need assistance with this step. A1 x 4 A1 x 4 1/2″...
  • Page 13 STEP 3 Verify Wall Plate is Firmly Mounted Pull Down...

  • Page 14: Mounting Options

    STEP 4 Attach the Power Outlet G1 x 2 G1 x 2 6 Mounting Options [05] If needed, the power outlet can be tilted.
  • Page 15 STEP 5 Hang TV on the Front Support HEAVY! You may need assistance with this step. G2 x 2 G2 x 2...

  • Page 16: Level Adjustment

    STEP 6 Level Adjustment Note: Please DO NOT overtighten or overloosen the nuts [L]. Level 3/8″ (10mm) Level the TV using the included level [03]. If it is difficult to level the TV, slightly loosen the 4 leveling nuts [L], then level the TV. Retighten the leveling nuts to hold the TV in position.

  • Page 17: Tilt Adjustment

    STEP 7 Tilt Adjustment Note: Please DO NOT overtighten or overloosen the lever [T1]. Tilt Tilt Slightly loosen the lever [T1]. Tilt the TV to the desired angle. [T1] Retighten the lever to hold the TV in position. Note: Please DO NOT overtighten or overloosen the nut [T2].

  • Page 18: Frequently Asked Questions

    If you find that a part is missing, please call technical support or email customer service. 1-800-456-5231 (US/CA) Mon–Fri, 8am–8pm (CST) 44-808-196-4165 (UK) Mon–Fri, 2pm–10pm (UTC) support@perlegear.com QUESTION 3 What if the faceplate is NOT level when unboxed? Please refer to Step 6 Level Adjustment.
  • Page 19 How can I raise/lower the TV if the TV Wall Mount is QUESTION 4 already fixed on the wall? 1. Remove the TV from the TV Wall Mount. 2. Remove the TV brackets from the TV and reattach according to instructions A or B in the picture below (A for lifting up the TV or B for lowering the TV).
  • Page 20 THANK YOU FOR CHOOSING THIS PERLEGEAR PRODUCT 1-800-456-5231 (US/CA) Mon–Fri, 8am–8pm (CST) support@perlegear.com 44-808-196-4165 (UK) Mon–Fri, 2pm–10pm (UTC) www.perlegear.com 860-02848-00 Rev00...
