BWINE F7GIM User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
14+
for age
User Manual
v1.0
F7GIM
CONTACT US FOR MORE TECH SUPPORT
+1 (619) 614-7960 Mon-Sun 7:00AM-1:00AM(PST)

Advertisement

loading
Need help?

Need help?

Do you have a question about the F7GIM and is the answer not in the manual?

Questions and answers

Related Manuals for BWINE F7GIM

Summary of Contents for BWINE F7GIM

  • Page 1 User Manual v1.0 F7GIM CONTACT US FOR MORE TECH SUPPORT +1 (619) 614-7960 Mon-Sun 7:00AM-1:00AM(PST)
  • Page 2 Grasp Fun, Enjoy Life. CONTACT US FOR MORE TECH SUPPORT +1 (619) 614-7960 Mon-Sun 7:00AM-1:00AM(PST) + 86 133 0274 4119 Bwinedrone@gmail.com...
  • Page 3 Content 1. Reading Tips 1.1 Symbols Explanation 1.2 Read Before the First Flight 1.3 Download App 1.4 Tutorial Videos 1.5 FAA Remote ID Registration Process 2. Product Profile 2.1 Introduction 2.2 Product List 2.3 Diagram 3. Aircraft 3.1 Speed Mode 3.2 Aircraft Status Indicator 3.3 TOF, Optical Flow Positioning 3.4 Propellers...
  • Page 4 5. Bwine Mini App 5.1 Home Screen 5.2 Control Interface 5.3 Parameter 5.4 Track 5.5 Other 6 FIight 6.1 Flight Environment Requirements 6.2 Pre-Flight Checklist 6.3 Pairing Remote Controller with Aircraft 6.4 Connect the Data Cable 6.5 Compass Calibration 6.6 Gyroscope Calibration 6.7 Starting/Stopping the Motor...
  • Page 5 1.3 Download the Bwine Mini App Please make sure to use Bwine Mini App during the flight. Scan the QR code to download the latest version of the app. Bwine Mini App supports Android 7.1 or higher, iOS 13.0 or higher.
  • Page 6 1.5 FAA Remote ID Registration Process 1.5.1 Find the Serial Number The F7GIM comes with a built-in FAA Remote ID module. You can obtain the unique Remote ID serial number through the app or on the aircraft itself. Please register according to your local regulations.
  • Page 7 ② Bwine Mini App: Successfully pair the aircraft with the remote controller --> Insert the data cable --> enter the “Bwine Mini” app --> enter CONTROL page --> Click the power icon in the upper right corner --> the RID information will pop.
  • Page 8 F 7GI M User Manual Copyright ©2025 Bwine All Rights Reserved.
  • Page 9 F 7 G I M User Manual Bwine F7GIM 1875BF7GM0000001 Copyright ©2025 Bwine All Rights Reserved.
  • Page 10 F 7GI M User Manual 1875BF7GM0000001 Bwine F7GIM Copyright ©2025 Bwine All Rights Reserved.
  • Page 11 F 7 G I M User Manual Bwine F7GIM 1875BF7GM0000001 The aircraft will start broadcasting the FAA remote ID signal when the aircraft's motors begin to spin. Copyright ©2025 Bwine All Rights Reserved.
  • Page 12 F 7GI M User Manual 2 Product Profile 2.1 Introduction The Bwine F7GIM features a foldable design and weighs about 357g. It offers stable hovering and flying capabilities outdoors with impressive shooting performance. Equipped with upgraded 5.8GHz Wi-Fi FPV real-time transmission, it includes a 75° FOV lens and a 90°...
  • Page 13 F 7 G I M User Manual 2.3 Diagram 2.3.1 Aircraft Diagram Propeller Optical Flow Sensor Motor Infrared TOF Sensor Smart Flight Battery Battery Buckle LED Light Power Button 3-Axis Brushless Aircraft Status Gimbal Camera Indicator Light SD Card Slot Copyright ©2025 Bwine All Rights Reserved.
  • Page 14 Hold down the recording button and Directional stick, used to control the then power on the remote controller aircraft’s flight direction (Short-press it then long-press the (forward/backward/left/right). For power button). more details, please refer to section 4.2.5. Copyright ©2025 Bwine All Rights Reserved.
  • Page 15 6.7-inch phone. Connecting the data cable here by mistake will result in a loss of video transmission. The correct data connection port is Copyright ©2025 Bwine All Rights Reserved.
  • Page 16 F7GI M User Manual 2.3.3 Remote Controller Display CONNECTING Speed Remote Controller Power Aircraft Connection Signal Flight Distance GPS Signal Flight Height Aircraft Power Status Display Copyright ©2025 Bwine All Rights Reserved.
  • Page 17 F 7 G I M User Manual 3. Aircraft F7GIM aircraft consists of a flight control system, a communication system, an image system, a power system and a smart flight battery. 3.1 Speed Mode F7GIM has two speed modes, Stable Mode and Sport Mode.
  • Page 18 F 7GI M User Manual 3.2 Aircraft Status Indicator The F7GIM status indicator light is located above the front landing gear and is used to display the current status of the flight. Please refer to the table below to understand what each flashing pattern indicates.
  • Page 19 F 7 G I M User Manual 3.3 TOF, Optical Flow Positioning The F7GIM is equipped with advanced infrared TOF (Time of Flight) sensing and a downward Optical Flow Positioning system, enhancing adaptability across various environments: Infrared TOF Sensor: This technology ensures precise distance measurement, providing stable low-altitude flight and smooth...
  • Page 20 GPS signal outdoors, it will automatically switch to GPS positioning mode. The TOF effectively at distances below 16.4ft (5m). However, it may not work properly over water surfaces or highly complex terrain. Copyright ©2025 Bwine All Rights Reserved.
  • Page 21 F 7 G I M User Manual 3.4 Propellers The propellers on the adjacent motors of the F7GIM are forward and reverse propellers. The two propellers on the same motor are the same, and the propellers are marked A and B respectively.
  • Page 22 F 7GI M User Manual 3.5 Smart Flight Battery The F7GIM smart flight battery has a capacity of 3200mAh, a rated voltage of 7.7V, and includes charge/discharge management features. This battery uses high-energy, large-capacity cells to provide strong support for the aircraft’ s flight time.
  • Page 23 Otherwise, the poor contact of the battery interface during the operation may cause the battery to short-circuit and burn the aircraft. The battery must be installed or removed with the battery power turned off. Copyright ©2025 Bwine All Rights Reserved.
  • Page 24 After charging is complete, please remove the charger in time. Charging time: 2.5 hours (using the Type-C fast charging cable that comes with the package). Copyright ©2025 Bwine All Rights Reserved.
  • Page 25 (such as the battery contacts have water, short-circuit caused by hair or foreign objects, etc.). If it exceeds 30 minutes, the protection board IC will fail and disconnect, and the battery cannot be used normally. Copyright ©2025 Bwine All Rights Reserved.
  • Page 26 field of vision for unforgettable moments. 3.6.1 3-Axis Brushless Gimbal The F7GIM is equipped with a three-axis mechanical stabilization gimbal, with roll, pitch, and yaw axes powered by brushless motors. This ensures stable and smooth image transmission.
  • Page 27 3.6.2 The aircraft adjustment angle is -90° to 0° 0° -90° 3.6.3 Image Storage The F7GIM is equipped with a micro-SD card slot for expanding storage capacity. (SD card is not included in package) ①Card speed: 10M/s. ②File format: Support FAT32 format.
  • Page 28 After powering on and connecting the aircraft, you can use the app to download photos or videos stored on the aircraft's memory card to your mobile device. Copyright ©2025 Bwine All Rights Reserved.
  • Page 29 F 7 G I M User Manual 4 Remote Controller 4.1 Introduction Bwine remote controller uses the 5.8 GHz frequency band. The retractable handle can securely hold a phone and supports devices up to 6.7 inches in size. Remote controller built-in 3600mAh 3.7V capacity battery, charging time is 3.5 hours, and the longest working time is about 4 hours.
  • Page 30 Connect the remote controller Type-C port to the charger to charge it. (Not included in package) 4.2.4 Controlling the Camera Record Button: Short press it to start/stop recording. Shutter Button: Short press it to take a photo. Camera Button Recording Button Copyright ©2025 Bwine All Rights Reserved.
  • Page 31 Japanese stick mode for controlling the aircraft is as follows: Left Joystick Right Joystick How to Switch Press and hold the record button to turn on the remote controller, it will be Japanese stick mode after turning on. Copyright ©2025 Bwine All Rights Reserved.
  • Page 32 The amount you push the stick controls the flight speed; the greater the push, the larger the tilt angle and the faster the flight. The forward direction of the aircraft is based on the direction of the nose. Copyright ©2025 Bwine All Rights Reserved.
  • Page 33 During flight, aim the phone mount directly at the aircraft to achieve the strongest signal transmission. User can refer to the aircraft flight direction from the Attitude Indicator in the app. Remote controller position Aircraft orientation Copyright ©2025 Bwine All Rights Reserved.
  • Page 34 When using the remote controller with a mounted device, make sure the device is securely clamped to prevent it from slipping. Store the remote controller with a battery level of around 3.8-3.9V. Charge the battery approximately every month to maintain its health. Copyright ©2025 Bwine All Rights Reserved.
  • Page 35 Tap to view the User Manual, Flight Guide, and Safety Disclaimer, as well as to access the flight instruction videos. Free call Tap to Call Bwine Customer Service Support. Support Tap to access the support ticket page (warranty and support), where you can send text, photos, or videos to receive technical assistance.
  • Page 36 Attitude Indicator ID Information Controller Battery Level More Features System Settings SD Card Auto Takeoff/Landing Flight height Speed of vertical flight D N/A H N/A H.S N/A V.S N/A Speed of horizontal flight Flight distance Copyright ©2025 Bwine All Rights Reserved.
  • Page 37 flight, while 1 or 2 bars indicate a weak GPS signal, requiring a change in takeoff location. Aircraft battery level Display the current smart flight battery power, and the power progress bar displays. Tap the battery icon to view Remote ID information. 1875BF7GM0000001 Copyright ©2025 Bwine All Rights Reserved.
  • Page 38 After unlocking the motors, tap this icon to make the aircraft take off automatically; tap it again, and the aircraft will land automatically. You can cancel the descent by push up the throttle stick. Back Tap to return to the homepage. Copyright ©2025 Bwine All Rights Reserved.
  • Page 39 Night Mode feature at night or in low-light conditions. Zoom Optional 5x zoom. Filter Select a filter for your photo or video. Switch the image to vertical to take photos and Vertical Screen videos. Copyright ©2025 Bwine All Rights Reserved.
  • Page 40 Storage settings: Option to store video recordings of different resolutions on the SD card. Photo Scale: Optional picture shoots with different specifications. Auxiliary grid: Different auxiliary lines can be selected to assist in composing the shot. Copyright ©2025 Bwine All Rights Reserved.
  • Page 41 Find drone: Shows the last known location when the aircraft lost video transmission. Open the map to locate the position where the aircraft disconnected from the app. Export Flight Log: Allows you to export flight data. Copyright ©2025 Bwine All Rights Reserved.
  • Page 42 (3) Grant permissions for other functions such as photo album access and recording. When using the Bwine Mini App on your phone, keep your device running smoothly by closing any unnecessary background apps. The maps used in the map interface need to be downloaded from the internet.
  • Page 43 When GPS is active, the aircraft can achieve stable hovering, smart return-to-home, and smart flight functions. Without GPS, these functions will not work, and the aircraft may drift with the wind and fail to hover. Copyright ©2025 Bwine All Rights Reserved.
  • Page 44 Using non-original parts can pose a risk to the safe operation of the aircraft. For details on supported accessories, refer to the accessories support page in the appendix of the user manual. 6.3 Pairing Remote Controller with Aircraft Please refer to section 4.4.4. Copyright ©2025 Bwine All Rights Reserved.
  • Page 45 Use the data cable to connect the remote controller to the mobile device. Open the Bwine Mini App and allow popup permission requests. Enter the operating interface. If you see the aircraft’ s live video feed, the connection is successful.
  • Page 46 Developer Mode varies by phone model; you can find specific instructions by searching Google). The remote controller does not support fast charging for mobile devices. Please check the battery level of your mobile device before use. Copyright ©2025 Bwine All Rights Reserved.
  • Page 47 Short press the compass calibration button on the remote controller; the aircraft's lights will start flashing quickly. Open the app to see the calibration guide animation. Short press to enter compass calibration Horizontal Calibration Copyright ©2025 Bwine All Rights Reserved.
  • Page 48 (refer to the compass calibration steps for guidance). When calibrating the aircraft, extend the arms and ensure the aircraft is at a height of 3.3ft (1m) above the ground to avoid magnetic interference. Copyright ©2025 Bwine All Rights Reserved.
  • Page 49 If the aircraft shows tilt or instability during flight, land the aircraft on a level surface to perform gyroscope calibration. When resetting the gyroscope calibration, make sure the aircraft is placed on a flat, level surface. Copyright ©2025 Bwine All Rights Reserved.
  • Page 50 When the motors are not running, press and hold the takeoff/landing button on the remote controller to start them. 6.7.2 Stopping the Motors Push the throttle stick to the lowest position and do not release it until the motor stops. Copyright ©2025 Bwine All Rights Reserved.
  • Page 51 4.9ft (1.5m) from the ground. Method 2: Tap one-key takeoff icon in App, then swipe right in the pop-up window. The aircraft will take off automatically and hover at a distance of 4.9ft (1.5m) from the ground. Copyright ©2025 Bwine All Rights Reserved.
  • Page 52 App, then swipe right in the pop-up window. The aircraft will land to the ground and stop the motors. During the aircraft's descent, pushing the throttle stick up on the remote controller will cancel the automatic landing. Copyright ©2025 Bwine All Rights Reserved.
  • Page 53 F 7 G I M User Manual 6.9 Return to Home (RTH) The F7GIM aircraft features a Return to Home (RTH) function in GPS mode when it has a strong GPS signal. This function returns the aircraft to the last recorded home point and lands it automatically.
  • Page 54 2. The aircraft is not equipped with obstacle avoidance function, please make reasonable judgments of the flight conditions during the flight, avoid obstacles in time, and set the appropriate flight and return altitude according to the flight environment. Copyright ©2025 Bwine All Rights Reserved.
  • Page 55 The remaining power after returning is related to the return distance, wind speed, and wind direction. When the aircraft is low on battery and is returning home, you cannot cancel the return. You can use the remote controller stick to avoid obstacles. Copyright ©2025 Bwine All Rights Reserved.
  • Page 56 (4) The aircraft automatically flies to the Home Point, then starts to land, and completes the return. Signal Loss When out of control, the aircraft cannot avoid obstacles. When the GPS signal is weak, the aircraft cannot return to home automatically. Copyright ©2025 Bwine All Rights Reserved.
  • Page 57 (2) Connect your phone to the remote controller with the data cable, and enter into the App operation interface. (3) Make sure the map is loaded on the Bwine Mini App before taking off the aircraft. (4) Take off the aircraft in GPS mode and ensure flight height is higher than the nearby obstructions.
  • Page 58 flight. If the current flight altitude of the aircraft is lower than 49ft (15m), Route Planning cannot be started. How to Exit Push the right joystick to cancel the waypoint flight function. Copyright ©2025 Bwine All Rights Reserved.
  • Page 59 Aircraft will lock onto the user and can track the user's movement as he moves. How to Start Make sure that the Bwine Mini App has been downloaded and installed on the phone. Connect your phone to the remote controller with the data cable, and enter into the App operation interface.
  • Page 60 The aircraft will fly around the target center point with a radius. How to Start (1) Make sure that the Bwine Mini App has been downloaded and installed on the phone. (2) Connect your phone to the remote controller with the data cable, and enter into the App operation interface.
  • Page 61 The larger the radius, the faster the flight speed. 6.10.4 Cruise Control The aircraft automatically flies at a constant speed according to the current flight action. This function requires the use of GPS mode with a strong GPS signal. Copyright ©2025 Bwine All Rights Reserved.
  • Page 62 (4) During cruise control, you can continue to use the joystick to adjust the aircraft's direction and altitude. Repeat steps 2 and 3, and the aircraft will automatically fly based on your last joystick input. Copyright ©2025 Bwine All Rights Reserved.
  • Page 63 When the remote controller signal is lost, it will automatically exit this function. The aircraft doesn't have obstacle avoidance functionality. Ensure flight safety by ensuring no obstacles in front of the aircraft to avoid collisions and damage. Copyright ©2025 Bwine All Rights Reserved.
  • Page 64 Once pairing is complete, connect the phone to the remote controller using a data cable. Open the Bwine Mini app and enter the operating interface. Wait for the GPS signal search to complete; the aircraft's indicator light will be solid green.
  • Page 65 32°F - 104°F (0°C - 40°C） Gimbal Stabilization Tilt axis: approximately -100° to +70° Mechanical range of gimbal Roll axis: approximately -35° to stabilization +35° Yaw axis: approximately -20° to +20° Camera angle adjustment Approximately -90°TO+0° range Copyright ©2025 Bwine All Rights Reserved.
  • Page 66 16GB to 128GB 5.8G Transmission Working frequency 5.725-5.825 GHz Supported Transmission Protocols 802.11a；802.11n20；802.11n40 App / Live View Mobile App Bwine Mini Live view quality 1280x720@30fps Mobile Compatibility Android 7.1 and above, iOS 13.0 and above Copyright ©2025 Bwine All Rights Reserved.
  • Page 67 3200 mAh Voltage 7.7V Battery type Li-polymer Energy 24.64Wh Net weight About 126.5 g / 4.46 oz Charging time About 2.5 hours (using PD fast charging) Charging temperature range 32°F to 104°F (0°C to 40°C) Copyright ©2025 Bwine All Rights Reserved.
  • Page 68 All of the above accessories can be purchased by searching on Amazon and visiting the Bwine store. Be sure to use only original manufacturer parts. Using non-original parts may pose a risk to the safe operation of the aircraft.
  • Page 69 Please make on its own, abnormal noise Compass interference sure to fly away from the buildings, trees, power lines, and signal towers. The propellers become Replace the propellers with new ones. deformed and incomplete Copyright ©2025 Bwine All Rights Reserved.
  • Page 70 Weak GPS signal Please stay away from obstacles for more Under the tree, next to the than 32.81 feet(10 meters), and search for building, in an obstructed place GPS signals in an open area Copyright ©2025 Bwine All Rights Reserved.
  • Page 71 This User Manual is subject to updates without notice. For the latest version of the User Manual, please visit the official Bwine website. www.bwine.net If you have any questions or suggestions about the User Manual, please contact us via the following email: bwinedrone@gmail.com...
  • Page 72 Grasp Fun, Enjoy Life. CONTACT US FOR MORE TECH SUPPORT +1 (619) 614-7960 Mon-Sun 7:00AM - 1:00AM (PST) + 86 133 0274 4119 Bwinedrone@gmail.com...
