Little Seeds Haven Manual

5 drawer dresser dove gray
Hide thumbs

Advertisement

Quick Links

Download this manual
B346833412COMS00SW
TM
inside for Assembly Manual
122023SW
Check us out!

Advertisement

loading
Need help?

Need help?

Do you have a question about the Haven and is the answer not in the manual?

Questions and answers

Related Manuals for Little Seeds Haven

Summary of Contents for Little Seeds Haven

  • Page 1 B346833412COMS00SW inside for Assembly Manual 122023SW Check us out!
  • Page 2 6833412COMS Haven 5 Drawer Dresser Dove Gray Keep this Assembly Manual for future reference Two Adults recommended for assembly This product is not intended for commercial use Do NOT return this product! For missing or broken parts - Call 1-800-489-3351...
  • Page 3 Do NOT return this product! Call us! 1-800-489-3351 Monday-Friday limited warranty valid in the U.S and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 60 MIN - Compression dowels are tapped in with a hammer - Make sure to always face the point on the top of the Cam Lock towards the outer edge - Use all the nails provided for the back panel and spread them out equally - Back Panel must be used to make sure your unit is sturdy...
  • Page 4 Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer to do so may result in stripping the screw, This Cam Lock Fastening System will be used throughout the assembly process.
  • Page 5 Before You Start Please Note: You may need to lightly tap the wood dowels with a hammer into the holes during your assembly process. Insert wood dowel completely into the hole. Not Actual Size Wood Dowel Actual Size Wood Dowel will extend out approximately 3/8”.
  • Page 6 Board Not actual size T6833412S010SW T6833412S020SW T6833412S030SW TOP PANEL BOTTOM PANEL LEFT SIDE PANEL T6833412S040SW T6833412S050SW T6833412S060SW RIGHT SIDE PANEL FRONT TOP RAIL BACK TOP RAIL T6833412S070SW T6833412S080SW T6833412S090SW BRACE DRAWER FACE LEFT DRAWER SIDE...
  • Page 7 Board Not actual size T6833412S110SW T6833412S100SW T6833412S120SW DRAWER BACK RIGHT DRAWER SIDE DRAWER BOTTOM T6833412S130SW T6833412S140SW DRAWER SUPPORT BACK PANEL...
  • Page 8 Hardware Bag Reference Number: 26833412COMS0SW Part List Actual Size For any replacement hardware, order using part #26833412COMS0SW TSW0001 TSW0002 Cam Bolt Cam Lock 15-10 TSW0004 TSW0005 TSW0007 TSW0008 DOWEL DOWEL SCREW SCREW M8 X 30 M6 X 30 CBS 3.5 x 14 CBS 4 x 38 TSW3006 TSW0015...
  • Page 9 Hardware Bag Reference Number: 26833412COMS0SW Part List Not Actual Size x5 SETS x1 SET TSW1004 TSW3001 TSW2004 DRAWER SLIDE HANDLE ANTI TIPPING KIT 350 MM...
  • Page 10 Step 1 Insert cam bolts (A) x 16, cam locks (B) x 4 and wood dowels (C) x 4 to the side panel (3) and side panel (4). Attach anti tipping kit (J) to side panel (4) and use (Jc) to tighten. “Note : This will be tightened in Step 19”. li leseedskids.com...
  • Page 11 Step 2 Attach drawer slides (K) CR x 5 to left side Attach drawer slides (K) CL x 5 to left side panel (4), use screws (E) x 15 to tighten. panel (3), use screws (E) x 15 to tighten. Slide CL , screw position on panel number (3) Slide CR , screw position on panel number (4) li leseedskids.com...
  • Page 12 Step 3 Insert cam bolts (A) x 4 to the top panel (1). Insert cam locks (B) x 12 and wood dowels (D) x 12 to the back top rail (6) and braces (7) x 5. * raw edges are shaded li leseedskids.com...
  • Page 13 Step 4 Attach front top rail (5) to top panel (1). Use screws (F) x 3 to tighten. (Follow arrow sticker marking for top rail placement) Important!, Please make sure bigger hole facing up side. * raw edges are shaded li leseedskids.com...
  • Page 14 Step 5 Insert cam locks (B) x 4 and wood dowels (C) x 4 to the bottom panel (2). * raw edges are shaded li leseedskids.com...
  • Page 15 Step 6 Attach front top rail (6) and braces (7) x 5 to side panel (3). Tighten the cam lock clockwise. Important!, Please make sure bigger hole facing down. Pro Tip : Second person is recomended for ease of assembly on this step li leseedskids.com...
  • Page 16 Step 7 Attach bottom panel (2) to side panel (3). Tighten the cam lock clockwise. FRONT RAIL Pro Tip : Second person is recomended for ease of assembly on this step * raw edges are shaded li leseedskids.com...
  • Page 17 Step 8 With a assistance of a second person, attach right side panel (4) to the braces (7) x 5, back top rail (6) and bottom panel (2). Fully tighten all the cam lock clockwise before proceed to next step. Pro Tip : Second person is recomended for ease of assembly on this step * raw edges are shaded li leseedskids.com...
  • Page 18 Step 9 With the assistance of a second person, carefully turn the unit up right. Attach top panel (1) to left side panel (3) and right side panel (4) allign with the wood dowels. Then fully tighten the cam locks clockwise. Use screws (F) x 3 to tighten the back to rail (6) to the top panel (1).
  • Page 19 Step 10 IMPORTANT ! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. With the assistance of a second person, carefully lay the unit face down. Attach back panel (14) with nails (H) x 20. Ensure that the unit is square. Distance from corner to corner must be equal. Pro Tip : Second person is recomended for ease of assembly on this step * raw edges are shaded li leseedskids.com...
  • Page 20 Step 11 Insert cam locks (B) x 15 into panels (9) x 5, panels (10) x 5 and panels (13) x 5. * raw edges are shaded li leseedskids.com...
  • Page 21 Step 12 Insert cam bolts (A) x 5 into drawer faces (8) as illustrated x5. * raw edges are shaded...
  • Page 22 Step 13 Attach panel (9) and panel (10) to the panel (8), then tighten the cam locks clockwise. Pro Tip : Second person is recomended for ease of assembly on this step * raw edges are shaded...
  • Page 23 Step 14 Attach panel (13) to the panel (8). Then fully tighten the cam lock clockwise. * raw edges are shaded...
  • Page 24 Step 15 Attach panel (12) into the groove of drawer (9) and drawer (10) as illustrated x5. Pro Tip : Second person is recomended for ease of assembly on this step * raw edges are shaded...
  • Page 25 Step 16 Line up the groove of panel (11) with panel (12), secure panel using screws (F) x 5 as illustrated x5. Pro Tip : Second person is recomended for ease of assembly on this step * raw edges are shaded leseedskids.com...
  • Page 26 Step 17 x5 SETS Attach drawer slide (K) DL to panel (9), and use screws (E) x 3 to tighten as illustrated x5. Attach drawer slide (K) DR to panel (10), and use screws (E) x 3 to tighten as illustrated x5. Use these holes : Use these holes : (DL)
  • Page 27 Step 18 Attach handle (I) onto panel (8), secure the handle with screws (G) x 2 as illustrated x 5. * raw edges are shaded leseedskids.com...
  • Page 28 Step 19 For Masonry, Concrete, or other wall materials: Consult your local hardware store for appropriate anchors to securely IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT.
  • Page 29 Step 20 Carefully insert drawers into the unit as illustrated. * raw edges are shaded litt leseedskids.com...
  • Page 30 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 50 lbs. 23 kg 35 lbs. 16 kg Each drawers Warning: Risk of serious injury to person - do not place a television on this furniture. This furniture is not approved for use with a television.
  • Page 31 Register your product to receive the following: * New trend details -sneak peek on what's new * Surveys -have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit l i l l e s e e d s k i d s .
  • Page 32 No Regrese este producto! Para piezas perdidas o rotas. Visitar: littleseedskids.com Llamenos al: 1-800-489-3351 (Gratis) Seguir little seeds en tilizarlo para evitar levantar y moverlo menos - Identificar, ordenar y contar las piezas antes de intentar ensamblar - Las clavijas de compresión se golpean con un martillo - Las diapositivas están marcadas con una R (derecha) y L (izquierda) para la colocación correcta...
  • Page 33 Español Página 24 Para mampostería, hormigón u otros materiales de pared: Consulte en su ferretería local los anclajes apropiados para sujetar de forma segura el soporte de seguridad. IMPORTANTE: ESTA UNIDAD DEBE ESTAR SEGURA EN LA PARED PARA AYUDAR A PREVENIR AL TIPOVER. SIGA ESTAS INSTRUCCIONES PARA INSTALAR EL SOPORTE DE SEGURIDAD ANTIDISCIPLINADOR PROPORCIONADO CON ESTE PRODUCTO.
  • Page 34 Español Página 28 Registre su producto para recibir lo siguiente: * Nuevos detalles sobre las tendencias - Sneek echa un vistazo a lo nuevo * Encuestas - tener una voz dentro de nuestra comunidad * Ofertas exclusivas y códigos de descuento Servicio de piezas de repuesto rápido y fácil Para registrar su producto, visite Ameriwoodhome.com 5 estrellas...
  • Page 35 Français Capot Avant Regardez à l’intérieur du manuel d’assemblage Búsquenos! Page 2 Gardez ce manuel d’assemblage pour référence ultérieure. Deux adultes sont recommandés pour l’assemblage. Ce produit n’est pas dest né à un usage commercial. Non Retournez ce produit! Pour les pièces perdues ou cassées. Visiter: littleseedskids.com Appelez-nous: 1-800-489-3351 (sans frais) Suivre les petites graines sur...
  • Page 36 Français page 25 Pour la maçonnerie, le béton ou d’autres matériaux muraux: Consultez votre quincaillier local pour obtenir les ancrages appropriés af n de f xer solidement le support de sécurité. IMPORTANT: CET APPAREIL DOIT ÊTRE SÉCURISÉ AU MUR POUR AIDER À PRÉVENIR TIPOVER. SUIVEZ CES INSTRUCTIONS POUR INSTALLER LE SUPPORT DE SÉCURITÉ...
  • Page 37 Français Page 28 Enregistrez votre produit pour recevoir les éléments suivants: * De nouveaux détails sur les tendances - Sneek vérif er la nouvelle * Sondages - ont une voix dans notre communauté t on Service de pièces de rechange rapide et facile Pour enregistrer votre produit, visitez Ameriwoodhome.com 5 étoiles Visitez le site Web de votre distributeur local, classez votre produit acheté...
