SB20-013
5/21/20
Subject:
New Model MFS 2.5/3.5C Service Information
Applicable Model: MFS2.5/3.5C
〈Summary〉
New model MFS 2.5/3.5C launched the production.
This service bulletin provides with changes from the previous model MFS2.5/3.5B
Please add to the Parts Catalog and/or the Service Manual to conform to the change(s) shown
herein.
The newly designed bottom cowl allows the motor to store in 3 different positions as shown below.
*Please do not place the cylinder head down.
Starboard Side Down: The same way as the previous model.
Port Side Down：Turn the tiller handle down to the cylinder head side.
Boat Side Down：Turn the clamp bracket to the right/left. Support with the carrying handle.
A
B
C
Part
Engine
Part
Engine
Part
Engine
Old
Old
Old
Old
Old
Old
New
New
New
New
New
New
D
Part
Engine
1
Old
Old
Interchageable
as a set
New
New
