Page 1 Operating Instructions Fronius Symo GEN24 6.0 / 6.0.Plus / 8.0 / 8.0 Plus 10.0 / 10.0 Plus EN-US Operating instructions 42,0426,0315,EA 032-14022025...
Page 3 Environmental conditions Qualified personnel Data on noise emission values EMC measures Backup power Data backup Copyright Equipment grounding (GND) General information Fronius Symo GEN24 Device concept Function overview Fronius UP Scope of supply Intended use Thermal concept Fronius Solar.web Local communication Different operating modes Operating modes –...
Page 4 Connection area Connection area divider Ground electrode terminal DC disconnector Data communication area Button functions and LED status indicator Schematic internal wiring of IOs Backup power variant - PV Point (OP) General Explanatory note - PV Point/PV Point Comfort PV Point (OP) PV Point Comfort Backup power variant - Full Backup General...
Page 5 Cable diameter of the DC cable Maximum alternating current fuse protection Connecting the inverter to the public grid (AC side) Safety Connecting the inverter to the public grid (AC side) Connecting solar module strings to the inverter General comments regarding PV modules Safety PV Generator, general Module array configuration6-10 kW...
Page 6 Setup wizard Restoring factory settings Event log Information License Manager Support Communication Network Modbus Cloud control Solar API Solar.web Internet services Safety and grid requirements Country setup Requesting inverter codes in Solar.SOS Feed-in limit Feed-in limit – examples Dynamic feed-in limit with multiple inverters I/O power management Connection diagram - 4 relays I/O power management settings - 4 relays...
Page 7 Circuit Diagrams Fronius Symo GEN24 and BYD Battery-Box Premium HV Circuit diagram Fronius Symo GEN24 with two BYD Battery-Box Premium HV connected in parallel Circuit diagram Fronius Symo GEN24 with three BYD Battery-Box Premium HV connected in parallel Circuit diagram...
Page 8 Circuit diagram Surge protection device (SPD) Circuit diagram Dimensions of the inverter Fronius Symo GEN24 6-10 kW Fronius Symo GEN24 6-10 kW...
Page 9 Safety rules Explanation of WARNING! safety instruc- tions Indicates a potentially dangerous situation. ▶ Death or serious injury may result if appropriate precautions are not taken. CAUTION! Indicates a potentially harmful situation. ▶ Minor injury or damage to property may result if appropriate precautions are not taken.
Page 10 Safety CAUTION! Danger from crushing due to the incorrect handling of attachments and con- nection parts. Injuries to limbs may result. ▶ Use the integrated grips when lifting up, putting down, and attaching the inverter. ▶ When fitting attachments, ensure that no limbs are located between the attachment and the inverter.
Page 11 Where an automatic backup power supply is installed, a backup power warning notice (https://www.fronius.com/en/search-page, item number: 42,0409,0275) must be fitted on the electrical distributor. Maintenance and installation work in the home network requires both disconnec- tion on the utility side and deactivation of the replacement power mode by open- ing the integrated DC disconnector on the inverter.
Page 12 Depending on the insolation conditions and the battery state of charge, the backup power supply is automatically deactivated and activated. This can cause the backup power supply to unexpectedly return from standby mode. Therefore, installation work can only be performed on the home network when the backup power supply is deactivated.
Page 13 Text and illustrations were accurate at the time of printing, subject to change. We are grateful for suggestions for improvement and information on any discrep- ancies in the operating instructions. Equipment Grounding a point in the device, system, or installation serves as a protective grounding (GND) measure against electric shock in the event of a fault.
Page 15 General information...
Page 17 Backup power variant - PV Point (OP) Available as an op- Battery connection* tion** Available as an op- Backup power variant - Full Backup tion** For suitable batteries, see chapter Suitable batteries. The functions are optionally available via Fronius UP (see chapter Fronius UP).
Page 18 Fronius UP With Fronius UP*, optionally available functions can be added to the inverter by the authorized specialist company (see chapter Function overview). The availability of Fronius UP is country-specific. Click here for further in- formation on availability. Scope of supply...
Page 19 These specifications do not provide an absolute guarantee of flawless op- eration. High error rates in the transmission, fluctuating receptions or mis- fires can have an adverse effect on data transfer. Fronius recommends on- site testing to ensure that the connections meet the minimum require- ments.
Page 20 The following data can be called up via mDNS: NominalPower Systemname DeviceSerialNumber SoftwareBundleVersion...
Page 21 Primary meter records the load curve of the system and makes the measured data available for energy profiling in Fronius Solar.web. The primary meter also regulates the dynamic feed-in control. Secondary meter records the load curve of individual loads (e.g., washing machine, lights, television, heat pump, etc.) in the load branch and makes the...
Page 22 Operating mode In order to be able to obtain the highest rate of self-consumption with your – Inverter with photovoltaic system, a battery can be used to store excess energy. The battery is battery coupled to the inverter on the direct current side. Multiple current conversion is therefore not required, and the efficiency is increased.
Page 23 Ohmpilot Operating mode IMPORTANT! – Inverter with In the fully equipped hybrid PV system with a Fronius Ohmpilot, the Ohmpilot battery, Ohmpi- cannot be operated in the event of a power failure for regulatory reasons. It is lot, and backup therefore sensible to install the Ohmpilot outside of the backup power branch.
Page 24 * Depending on the settings and local standards and regulations. Operating states Battery systems distinguish between different operating states. In each case, the (only for battery relevant current operating state is displayed on the user interface of the inverter systems) or in Fronius Solar.web.
Page 25 Operating state Description Normal operation Energy is stored or drawn, as required. Min. state of charge (SoC) The battery has reached the minimum SoC spe- reached cified by the manufacturer or the set minimum SoC. The battery cannot be discharged further. Energy saving mode The system has been put into energy-saving mode.
Page 26 Both the inverter and the battery automatically switch to energy sav- ing mode under certain conditions. The inverter switches to energy saving mode if the battery is flat and no PV power is available. Only the inverter's communication with the Fronius Smart Meter and Fronius Solar.web is maintained. Switch-off con-...
Page 27 Indication of en- During energy saving mode: ergy saving Operating LED for the inverter lights up orange (see Button functions and mode LED status indicator on page 36). The user interface of the inverter can be reached. All the available data are saved and transmitted to Solar.web. The real-time data can be seen on Solar.web.
Page 28 Fronius explicitly points out that the third-party batteries are not Fronius products. Fronius is not the manufacturer, distributor, or retailer of these batter- ies. Fronius accepts no liability and offers no service or guarantees for these bat- teries. Obsolete firmware/software states may lead to incompatibilities between the in- verter and the battery.
Page 29 Switch on the battery. Set the DC disconnector to the "on" switch position. Turn on the automatic circuit breaker. LG FLEX LG FLEX 12.9 17.2 Number of battery modules Fronius Symo GEN24* Fronius Symo GEN24 Plus Battery support optionally available.
Page 30 Switching on the battery Pull off the cover to the right. Pull off the cover of the DC discon- nector to the front. Set the DC discon- nector to the "on" switch position. To assemble the battery, perform the steps listed above in reverse order.
Page 31 Notification of Status codes about the inactive state of the battery are displayed on the user in- system shut- terface of the inverter. A notification via e-mail can be activated in Fronius Sol- down ar.web. Manual battery As soon as energy is available again, the inverter starts operation automatically;...
Page 32 Protection of people and equipment Central grid and The inverter offers the option to use the integrated AC relays as section switches system protec- in conjunction with a central grid and system protection unit (in accordance with tion VDE-AR-N 4105:2018:11 §6.4.1). For this purpose, the central trigger device (switch) must be integrated into the WSD chain as described in chapter (wired shutdown) on page 32.
Page 33 Operating controls and connections Connection area 2 x 4-pin DC push-in terminal Push-in WSD (wired shutdown) terminal Push-in terminals in the data communication area (Modbus, digital inputs and outputs) 3-pin push-in terminal for PV Point (OP) 5-pin AC push-in terminal Cable bushing/cable gland AC 6-pin ground electrode terminal Cable bushing/cable gland in the data communication area...
Page 34 Connection area divider (10) 10x DC cable bushings (11) Optional cable bushing (M16) (12) Optional cable bushing (M16-M20) (13) Optional cable bushing (M16-M32) (14) Optional cable bushing (M16-M25) Connection area The connection area divider separates the high-voltage conductors (DC and AC) divider from the signal lines.
Page 35 DC disconnector The DC disconnector has three switch settings: Locked/off (turned to the left) IMPORTANT! In switch settings (1) and (3), the in- verter can be secured to prevent it from being switched on/off using a standard padlock. The national guidelines must be complied with in this respect.
Page 36 The operating status LED dis- and LED status plays the status of the inverter. indicator In case of faults, follow the in- dividual steps in the Fronius Solar.start app. The optical sensor is actuated WLAN access point by touching it with a finger.
Page 37 Sensor functions = WLAN access point (AP) is opened. Flashes blue = WLAN protected setup (WPS) is activated. Flashes green 3 seconds (max. 6 seconds) = The service message dis- appears. Flashes white (quickly) LED status indicator The inverter is operating correctly. Lights up green The inverter is performing the grid checks required by the applicable standards for grid power feed operation.
Page 38 LED status indicator A network error is displayed, the inverter is operating correctly. Lights up red The network connection is active. Lights up blue The inverter is performing an update. Flash blue There is a service message. Lights up white Schematic in- The V+/GND pin provides the possibility of feeding in a voltage in the range of ternal wiring of...
Page 39 Backup power variant - PV Point (OP)
Page 41 General Explanatory note IMPORTANT! - PV Point/PV If several backup power variants are available, please note that only one backup Point Comfort power variant may be installed and configured. The inverter can provide 220‑240 V at the PV Point/PV Point Comfort. A corres- ponding configuration must be set up during commissioning.
Page 42 Installation Instructions, see Connecting backup power - PV Point (OP) on page PV Point Com- With PV Point Comfort, 1-phase elec- fort trical devices are continuously sup- plied up to a maximum power of 3 kW. Switching between grid-connected and backup power mode takes place auto- matically.
Page 43 Backup power variant - Full Backup...
Page 45 The inverter is operating in backup power mode. from backup The public grid is functioning correctly again. power mode to The Fronius Smart Meter monitors the grid parameters on the public grid grid power feed and passes this information to the inverter. operation The stability of the restored public grid is determined by checking the meas- ured values of the Fronius Smart Meter.
Page 46 If the battery and inverter are in energy saving mode, the system is reactivated by the following: Enough energy is available from the PV modules. The public grid is functioning again. The battery is switched off and on.
Page 47 Public grid available again. grid power feed The Fronius Smart Meter monitors the grid parameters on the public grid operation and passes this information to the inverter. The stability of the restored public grid is determined by checking the meas- ured values of the Fronius Smart Meter.
Page 48 Transitioning The public grid is monitored by the inverter's internal grid and system pro- from grid power tection unit and by the Fronius Smart Meter connected to it. feed operation to Failure of the public grid. backup power The inverter carries out the necessary measures according to the country mode standard and then switches off.
Page 49 Public grid available again. grid power feed The Fronius Smart Meter monitors the grid parameters on the public grid operation and passes this information to the inverter. The stability of the restored public grid is determined by checking the meas- ured values of the Fronius Smart Meter.
Page 50 Italy Functions Measuring and transferring the required parameters for energy management and Solar.web by the Fronius Smart Meter. Monitoring of the voltage and frequency grid parameters by the inverter. Disconnecting from the public grid to enable operation in backup power mode if the grid parameters are outside the country-specific standards.
Page 51 Public grid available again. grid power feed The Fronius Smart Meter monitors the grid parameters on the public grid operation and passes this information to the inverter. The stability of the restored public grid is determined by checking the meas- ured values of the Fronius Smart Meter.
Page 52 0. This causes the inverter to shut down immedi- ately. This behavior is ensured via 2 contacts. Communication between the inverter and Fronius Smart Meter is optionally interrupted via a contact. The suspended communication prevents automatic termination of backup power mode when the public grid returns, so that the inverter remains in backup power mode until it is manually switched back.
Page 53 The inverter is again connected to the entire home network and to the public grid. Communication between the inverter and Fronius Smart Meter is re-estab- lished. The inverter can start grid power feed operation again after performing the...
Page 55 Installation...
Page 57 General Quick-fastener A quick-fastener system (3) is used to system mount the connection area cover and front cover. The system is opened and closed with a half-rotation (180°) of the captive screw (1) into the quick- fastener spring (2). The system is independent of torque. NOTE! Danger when using a drill driver.
Page 58 UKCA marking – confirms compliance with applicable UK directives and regulations. WEEE marking – waste electrical and electronic equipment must be collected separately and recycled in an environmentally sound manner in accordance with the European Directive and national law. RCM marking – tested according to the requirements of Australia and New Zealand.
Page 59 For more detailed information on in- 0 - 100% verter dimensions, refer to the chapter headed Fronius Symo GEN24 6-10 kW on page 231. When installing the inverter on the outer walls of cattle sheds, it is important to maintain a minimum clearance of 2 m between all sides of the inverter and the ventilation and building openings.
Page 60 The inverter should be installed in a protected location, e.g., near the PV modules or under an overhanging roof. The inverter must not be installed or operated at more than 4000 m above sea level. Do not install the inverter: Where it may be exposed to ammonia, corrosive gases, acids, or salts (e.g., fertilizer storage areas, vent openings for livestock stables, chemical plants, tanneries)
Page 61 Installation posi- The inverter is suitable for vertical installation on a vertical wall tion of inverter or column. The inverter is suitable for a horizontal installation position. The inverter is suitable for installation on a sloping surface. Do not install the inverter on a sloping surface with its connec- tion sockets at the top.
Page 62 Do not install the inverter overhanging with the connection sockets at the bottom. Do not install the inverter on the ceiling.
Page 63 Installing the mounting bracket and attaching the inverter Selecting the Use the corresponding fixing materials depending on the subsurface and observe mounting mater- the screw dimension recommendations for the mounting bracket. The installer is responsible for selecting the right type of fixing. Properties of the The mounting bracket (illustration) is mounting brack-...
Page 64 Installing the When installing the inverter on a mast mounting brack- or beam, Fronius recommends using et on a mast or the "Pole clamp" (order no. SZ beam 2584.000) mounting kit from Rittal GmbH. The "Pole clamp" kit covers the follow-...
Page 65 Attaching the IMPORTANT! mounting brack- The mounting bracket must be affixed et to mounting at a minimum of four points. rails Attaching the in- There are integrated grips on the side verter to the of the inverter which facilitate lifting/ mounting brack- attaching.
Page 66 Requirements for connecting the inverter Different cable Fine-stran- Fine-stran- types ded with fer- ded with fer- rule and col- rule without Multi-stran- Fine-stran- Single-core collar Permissible Round copper conductors can be connected to the terminals of the inverter as cables for the described below.
Page 67 AWG 26 - 16 AWG 26 - 16 LAN connections Fronius recommends using at least CAT 5 STP (shielded twisted pair) cables and a maximum dis- tance of 100 m (109 yd). Cable diameter For a standard M32 cable gland with a reducer:...
Page 68 For this reason, in ac- cordance with national legislation, Fronius recommends that a residual current circuit breaker with a trip- ping current of at least 100 mA suit- able for frequency converters be used.
Page 69 Recom- Phase AC out- Maximum mended Inverter fuse rating fuse rating Fronius Symo GEN24 6 kW 6,000 W 32 A 16 A Fronius Symo GEN24 8 kW 8,000 W 32 A 25 A Fronius Symo GEN24 10 kW 10,000 W...
Page 70 Connecting the inverter to the public grid (AC side) Safety WARNING! Danger from incorrect operation and work that is not carried out properly. This can result in severe personal injury and damage to property. ▶ Read the Installation Instructions and Operating Instructions before in- stalling and commissioning the equipment.
Page 71 Turn off the automatic circuit breaker. Set the DC disconnector to the "Off" switch position. Loosen the 5 screws of the connection area cover by rotating them 180° to the left using a screwdriver (TX20). Remove the connection area cover from the device.
Page 72 Strip the insulation of the single con- ductors by 12 mm. Select the cable cross-section in accordance with the instructions in Permissible cables for the electrical connection on page 66. Lift to open the terminal's operating lever and insert the stripped single conductor into the slot provided as far as it will go.
Page 73 This can result in severe personal injury and damage to property. ▶ The commissioning, maintenance, and service work in the inverter's power stage set may only be carried out by Fronius-trained service personnel in accordance with the technical specifications. ▶...
Page 74 WARNING! Danger from mains voltage and DC voltage from PV modules that are exposed to light. This can result in severe personal injury and damage to property. ▶ All connection, maintenance, and service work should only be carried out when the AC and DC sides have been disconnected from the inverter and are de-energized.
Page 75 Module array settings: PV 1: ON PV 2: OFF Combined solar module strings with total cur- rent less than or equal to 25 A (I dcmax ). Module array settings: PV 1: ON PV 2: OFF PV 1 + PV 2 (connected in parallel): IMPORTANT! The maximum current load of a single terminal is 25 A.
Page 76 Connecting solar module strings to the inverter Push the DC cables through the DC bushings by hand. IMPORTANT! Push the cables through the DC bush- ing before stripping them in order to avoid twisting/bending single wires.
Page 77 PUSH Select the cable cross-section in ac- cordance with the instructions in Per- missible cables for the electrical con- nection from page 66. Strip the insulation of the single con- ductors by 12 mm. Lift to open the ter- minal's operating lever and insert the stripped single conductor into the slot provided, in each case as far as it will go.
Page 78 Use a suitable measuring instrument to check the voltage and polarity of the DC cabling. Remove both DC ter- minals from the slots. CAUTION! Danger due to polarity reversal at the terminals. This may result in severe damage to the inverter. ▶...
Page 79 Insert the DC terminals into the re- spective slot until they engage. Fasten "click" the screws of the strain-relief device to the housing using a screwdriver (TX20) and a torque of 1.3 - 1.5 Nm. NOTE! Risk due to overtorque at the strain- relief device.
Page 80 Connecting the battery to the inverter Safety WARNING! Danger due to incorrect operation and incorrectly performed work. This can result in serious injury and damage to property. ▶ Commissioning as well as maintenance and service work on the inverter and battery must only be carried out by service personnel trained by the respective inverter or battery manufacturer and only within the scope of the respective technical regulations.
Page 81 Push the battery cables through the DC bushings by hand. * The battery ground conductor must be connected externally (e.g., switch BAT+ cabinet). When connecting an LG FLEX BAT- battery, the battery ground conductor BAT PE can be connected in the inverter (see chapter Connecting the LG FLEX ground conductor...
Page 82 Select the cable cross-section in ac- cordance with the instructions in Per- missible cables for the electrical con- nection from page 66. Strip the insulation of the single con- ductors by 12 mm. Lift to open the ter- minal's operating lever and insert the stripped single conductor into the slot provided, in each case as far as it will go.
Page 83 CAUTION! Danger due to overvoltage when us- ing other slots on the terminal. This may result in damage to the battery and/or the PV modules due to discharge. ▶ Only use the slots labelled 'BAT' for connecting the battery. CAUTION! Danger due to polarity reversal at the terminals.
Page 84 Fasten the screws of the cable guide to the housing using a screwdriver (TX20) and a torque of 1.3 - 1.5 Nm. NOTE! Risk due to overtorque at the strain- relief device. Damage to the strain-relief device may result. ▶ Do not use a drill driver.
Page 85 This can result in serious injury and damage to property. ▶ Installing and connecting an option must only be carried out by service personnel trained by Fronius and only within the scope of the respective technical regulations. ▶ Follow the safety rules.
Page 86 Switch off the automatic circuit break- er and DC disconnector. Turn the DC disconnector to the "off" switch set- ting. Loosen the 5 screws of the connection area cover by rotating them 180° to the left using a screwdriver (TX20). Remove the connection area cover from the device.
Page 87 Drill out the optional cable guide with a step drill. Insert the cable gland into the bore and fasten it using the torque specified by the manufacturer. Guide the mains cable through the cable gland from below. Remove the OP terminal.
Page 88 Strip the insulation of the single con- ductors by 12 mm. The cable cross-section must be between 1.5 mm and 10 mm . Lift to open the terminal's operating lever and insert the stripped single conductor in- to the slot provided, all the way up to the stop.
Page 89 During ongoing operation (recommendation: at least once a year) For test mode, a battery charge of min. 30% is recommended. A description on how to run test mode can be found in the backup power check- list (https://www.fronius.com/en/search-page, item number: 42,0426,0365).
Page 90 Connecting backup power - Full Backup Safety WARNING! Danger from incorrect installation, commissioning, operation, or incorrect use. This can result in severe personal injury/damage to property. ▶ Only trained and qualified personnel are authorized to install and commis- sion the system, and only within the scope of the technical regulations. ▶...
Page 91 The supply voltage for contactor K1 is provided by the public grid and must be connected to phase 1 (L1) downstream of the Fronius Smart Meter and fused accordingly. An NC contact for relay K3 interrupts the supply voltage to contactor K1.
Page 92 The supply voltage for contactor K1 is provided by the public grid and must be connected to phase 1 (L1) downstream of the Fronius Smart Meter and fused accordingly. To ensure residual current circuit breakers function in backup power mode, the connection between the neutral conductor and the ground conductor must be implemented in accordance with the respective circuit diagram.
Page 93 The supply voltage for contactors K1 and K2 is provided by the public grid and must be connected to phase 1 (L1) downstream of the Fronius Smart Meter and fused accordingly.
Page 94 The protective measure must be tested regularly; if this is not regulated by law, it must be performed annually. Data transfer between the Fronius Smart Meter and the inverter may be in- terrupted in backup power mode (switch position 2). This is optionally en- sured via a NO contact of the auxiliary contact.
Page 95 A description on how to run test mode can be found in the backup power check- list (https://www.fronius.com/en/search-page, item number: 42,0426,0365).
Page 96 If the Inverter Control via Modbus function is activated in the Commu- nication > Modbus menu area, no Modbus participants are possible. It is not pos- sible to send and receive data at the same time. Example 1: Fronius Number of Number of sec- Input...
Page 97 IMPORTANT! Should the blanking plugs be missing or improperly fitted, then safety class IP66 cannot be guaranteed. Undo the cable gland union nut and push out the sealing ring and the blanking plug from the inside of the device. Open up the sealing ring at the loca- tion where the blanking plug is to be removed.
Page 98 Insert the sealing ring between the union nut and the housing opening. Press the data cables into the seal's cable guide. Then press in the seal un- til it reaches the underside of the cable gland. Tighten the union nut for the cable gland to a torque of min.
Page 99 "SHIELD" slot. IMPORTANT! Improperly fitted shielding can cause data communication problems. For the wiring proposal recommended by Fronius, see page 207. Terminating res- It may be possible for the system to function without terminating resistors. istors However, owing to interference, the use of terminating resistors according to the following overview is recommended for trouble-free operation.
Page 100 OPTION 2 M0 / M1 Manufacturer manual Manufacturer manual Modbus 0 / 1 Modbus 0 / 1 (min. CAT 5) (min. CAT 5 STP) OPTION 3 M0 / M1 Manufacturer manual Manufacturer manual Modbus 0 / 1 Modbus 0 / 1 (min.
Page 101 IN (+) OUT (+) IN (+) OUT (+) IN (+) OUT (+) IN (-) OUT (-) IN (-) OUT (-) IN (-) OUT (-) CAT 5/6/7 * Floating contact of the trigger device (e.g., central grid and system protection). If several floating contacts are used in a WSD chain, these must be connected in series.
Page 102 Closing and commissioning the inverter Closing the in- NOTE! verter's connec- tion area/hous- The housing cover is fitted with a lock for safety reasons, which allows the ing cover, and housing cover on the inverter to be pivoted only when the DC disconnector is commissioning switched off.
Page 103 Installation with The Fronius Solar.start app is required for installation. Depending on the mobile the app device used to perform the installation, the app is available on the relevant plat- form.
Page 104 The installation wizard opens. Follow the installation wizard and complete the installation in the individual areas. Add the system components in Fronius Solar.web and commission the PV system. The network wizard and product setup can be performed independently. A net- work connection is required for the Fronius Solar.web installation wizard.
Page 105 De-energizing the inverter and switching it back De-energizing Turn off the automatic circuit the inverter and breaker. switching it back Turn the DC disconnector to the "off" switch setting. To start up the inverter again, follow the steps listed above in reverse order. IMPORTANT! Wait for the capacitors of the inverter to discharge!
Page 107 Settings – User interface of the in- verter...
Page 109 User settings User login Open the user interface of the inverter in the browser. In the Login menu area, log in with username and password, or, in the User > User Login menu area, log in with username and password. IMPORTANT! Depending on the authorization of the user, settings can be made in the individu- al menu areas.
Page 110 Primary meter For problem-free operation with further energy generators and in Full Backup power mode, it is important to install the Fronius Smart Meter at the feed-in point. The inverter and further producers must be connected to the public grid via the Fronius Smart Meter.
Page 111 Functions and Backup Power I/Os In backup power mode, it is possible to select between Off, PV Point, and Full Backup. The backup power mode Full Backup can only be activated once the required I/O assignments for backup power have been configured. In addition, a meter must be installed and configured at the feed-in point for the backup power mode Full Backup.
Page 112 Mode Description Information DRM Pin DRM1 Import P ≤ 0% currently not supported DRM 1/5 without disconnec- tion from grid DRM2 Import P ≤ 50% currently not supported DRM 2/6 DRM3 Import P ≤ 75% currently not supported DRM 3/7 &...
Page 113 Nevertheless, false alarms can be triggered for the type A residual current cir- cuit breaker in individual cases and depending on local conditions. For this reason, Fronius recommends using a residual current circuit breaker suitable for frequency inverters with a release current of least 100 mA, taking into ac- count national provisions.
Page 114 (see Technical data) by the offset value. The default value is +3 Hz. Connec- ted loads (e.g., Fronius Ohmpilot) detect active backup power mode based on the changed frequency and react accordingly (e.g., activation of energy-saving mode). IMPORTANT!
Page 115 Parameter Value range Description Backup Over- 0 ‑ 2 %V This set value represents the limit value voltage Protec- for shutting down backup power mode tion Limit e.g., set value 1.1 = 110% of the nominal U> [pu] voltage. Backup Over- 0.04 ‑...
Page 116 The setting Allow battery charging from other generators in the home network activates/deactivates charging of the battery from other generators. The power consumption of the Fronius inverter can be restricted by specifying a value in the Max. Charging Power from AC field. As a maximum, a power con- sumption equal to the AC rated power of the Fronius inverter is possible.
Page 117 Battery Management is influenced, for example, by the following settings: Permitted battery charging from the public grid Power limit of the inverter, energy storage device, or overall system Control specifications via Modbus Self-consumption optimization IMPORTANT! The defined regulations for battery control have the second lowest priority after Self-Consumption Optimization.
Page 118 Power into the battery 500 W Power output (AC) of the inverter 500 W Set target value at feed-in point Infeed into the public grid Consumption in home 500 W Battery system without photovoltaics, including second generator in the house 2000 W 1500 W TARGET: 0 W...
Page 119 Set target value at feed-in point Infeed into the public grid Consumption in home 500 W Battery system including second generator in the house (with AC max. limitation) 1000 W 2000 W AC max: 1000 W 500 W 1000 W TARGET: 0 W 2000 W 500 W...
Page 120 Specify charging range It is possible to define a charging range using a min. and max. charging limit. In this case, it is not possible to discharge the battery. Limit Min. charging Max. charging Limit discharge power power 500 W power 3800 W charging power Min.
Page 121 IMPORTANT! If there is a Fronius Wattpilot in the photovoltaic system, it is considered to be a load. The priority for the load management of the Fronius Wattpilot must be configured in the Fronius Solar.wattpilot app.
Page 122 I/Os controlled by the produced power are always prioritized over a battery and Fronius Ohmpilot. That is to say that an I/O can switch on and result in the bat- tery no longer being charged or the Fronius Ohmpilot no longer being activated.
Page 123 Click Save. ü System name, time zone, and time zone location are saved. Update All available updates are provided on the product page and in the "Fronius Down- load Search" area at www.fronius.com Update Drag the firmware file into the Drag & drop file here field, or select via Browse file.
Page 124 If the inverter, power stage set, or data communication area is replaced, the li- cense file must also be replaced. Licensing - online (recommended) This requires an Internet connection and a completed Fronius Solar.web config- uration. Finish all installation work (refer to the chapter headed...
Page 125 Remote access is activated for Fronius Support. IMPORTANT! The remote access exclusively enables Fronius Technical Support to access the inverter via a secure connection. In this case, diagnostics data are transmitted, which are used for troubleshooting. The remote access can be activated only...
Page 126 Activate WPS on the WLAN router (see WLAN router documentation). Click on the Start button. The connection is established automatically. Log in to the user interface of the inverter. Check the network details and connection to Fronius Solar.web.
Page 127 It is possible to operate a connection via WLAN and via the access point at the same time. Modbus The inverter communicates with system components (e.g., Fronius Smart Meter) and other inverters via Modbus. The primary device (Modbus Client) sends con- trol commands to the secondary device (Modbus Server). The control commands are executed by the secondary device.
Page 128 SunSpec Model Type There are two different settings, depending on the SunSpec model. float: SunSpec Inverter Model 111, 112, 113 or 211, 212, 213. int + SF: SunSpec Inverter Model 101, 102, 103 or 201, 202, 203. Meter Address The value entered is the identification number (unit ID) assigned to the meter, which can be found on the user interface of the inverter in the Com- munication >...
Page 129 (e.g., EV charger, smart home solutions, etc.) or the Fronius Wattpilot. For monitoring, Fronius recommends using Fronius Solar.web, which provides se- cure access to inverter status and production information. In the event of a firmware update to version 1.14.x, the Solar API setting is ap- plied.
Page 130 Internet services Information regarding connections and the current connection status is dis- played in this menu. If there are problems with the connection, a short descrip- tion of the error is displayed.
Page 131 The Country Setup menu area is intended exclusively for installers/service tech- verter codes in nicians from authorized specialist companies. The inverter access code required Solar.SOS for this menu area can be requested in the Fronius Solar.SOS portal. Requesting inverter codes in Fronius Solar.SOS: Open solar-sos.fronius.com...
Page 132 The inverter ensures that the PV power that cannot be fed into the public grid is used by the Fronius Ohmpilot so that it does not go to waste. The feed-in limit only becomes active if the power of feeding in is higher than the set power re- duction.
Page 133 Total DC power of the Entire System Input field for the total DC power of the entire system in Wp. This value is used if the Maximum grid feed-in power is specified in %. Export Limit Control (Soft Limit) If this value is exceeded, the inverter readjusts down to the set value. Export Limit Protection (Hard Limit Trip) If this value is exceeded, the inverter switches off within max.
Page 134 Limit per phase – asymmetric generation (feed-in limit 0 kW per phase) – asymmetric 1 kW 0 kW 10 kW 2 kW 0 kW 3 kW 0 kW = 0 kW = 6 kW Explanation The load requirement in the home network per phase is determined and supplied. Limit per phase –...
Page 135 Fronius Tauro Fronius GEN24, Fronius Verto, Fronius Tauro, Fronius SnapINverter with Fronius Datamanager 2.0* * Up to four additional Fronius SnapINverters can be connected to each Fronius SnapINverter with Fronius Datamanager 2.0. Primary meter The Fronius Smart Meter acts as the only primary meter and is connected dir-...
Page 136 all inverters into the grid and passes this information to the primary device via Modbus. Primary device The export limitation is configured on the user interface of the inverter: In the Safety and Grid Regulations > Export Limitation menu area, activate the Power Control function and select Total Power Limit.
Page 137 Enable the Reduce inverter power to 0% if meter connection has been lost function User interface secondary device Fronius Datamanager 2.0 Select the user Admin and enter the password for the user Admin. In the Settings – Modbus menu area, activate the Exporting data via Modbus and Inverter control via Modbus functions.
Page 138 DNO feedback If the rule is activated, the DNO feedback output (pin 1 recommended) must be configured (e.g., for operating a signal device). The data format *.fpc is supported for Import and Export. Controlling Priorities Used to set controlling priorities for I/O power management (DRM or ripple con- trol receiver), the export limitation, and control via Modbus.
Page 139 Use pre-configured file for 4-relay operation: Download the file (.fpc) under 4-relay operation to the mobile device. Upload the file (.fpc) in the I/O Power Management menu area by clicking the Import button. Click Save. ü The settings for 4-relay operation are saved.
Page 140 I/O power man- I/O Power Management agement set- V+/GND tings - 4 relays None None None None None DNO Feedback None not used None None DNO Rules IO control IO control Rule 1 IO control IO control Active Power Power Factor (cos φ) DNO Feedback Rule 2 Active Power...
Page 141 Connection dia- The ripple control signal receivers and the I/O terminals of the inverter can be gram - 3 relays connected to one another as shown in the connection diagram. For distances of over 10 m between the inverter and the ripple control signal re- ceiver, a CAT 5 STP cable is recommended as a minimum and the shielding must be connected on one side at the push-in terminal of the data communication area (SHIELD).
Page 142 I/O power man- I/O Power Management agement set- V+/GND tings - 3 relays None None None None None DNO Feedback None not used None None DNO Rules IO control IO control Rule 1 IO control None Active Power Power Factor (cos φ) DNO Feedback Rule 2 Active Power...
Page 143 Connection dia- The ripple control signal receivers and the I/O terminals of the inverter can be gram - 2 relays connected to one another as shown in the connection diagram. For distances of over 10 m between the inverter and the ripple control signal re- ceiver, a CAT 5 STP cable is recommended as a minimum and the shielding must be connected on one side at the push-in terminal of the data communication area (SHIELD).
Page 144 I/O power man- I/O Power Management agement set- V+/GND tings - 2 relays None None None None None DNO Feedback None not used None None DNO Rules IO control IO control Rule 1 None None Active Power Power Factor (cos φ) DNO Feedback Rule 2 Active Power...
Page 145 Connection dia- The ripple control signal receivers and the I/O terminals of the inverter can be gram - 1 relay connected to one another as shown in the connection diagram. For distances of over 10 m between the inverter and the ripple control signal re- ceiver, a CAT 5 STP cable is recommended as a minimum and the shielding must be connected on one side at the push-in terminal of the data communication area (SHIELD).
Page 146 I/O power man- I/O Power Management agement set- V+/GND tings - 1 relay None None None None None DNO Feedback None not used None None DNO Rules IO control None Rule 1 None None Active Power Power Factor (cos φ) DNO Feedback Rule 2 Active Power...
Page 147 The Country Setup menu area is intended exclusively for installers/service tech- nicians from authorized specialist companies. The inverter access code required for this menu area can be requested in the Fronius Solar.SOS portal (see chapter Requesting inverter codes in Solar.SOS...
Page 149 Options...
Page 151 36). The error code 1030 WSD Open is displayed on the user interface of the inverter in the System > Event Log menu area or in the user menu under No- tifications and in Fronius Solar.web. In this case, the inverter must be repaired by an authorized specialist company.
Page 152 PC board 4 pcs TX20 screws Ground conductor 2-pin signal cable PV- cable PV+ cable User information De-energizing Turn off the automatic circuit breaker. the inverter Set the DC disconnector to the "off" switch position. Disconnect connections from the solar module strings (+/-).
Page 153 Installation CAUTION! Danger due to insufficiently dimensioned ground conductor. Damage to the inverter due to thermal overload can result. ▶ The national standards and guidelines must be observed for dimensioning the ground conductor. Loosen the two screws on the under- side of the housing cover by rotating them 180°...
Page 154 Remove the DC push-in terminals from the slots and disconnect them from the cables (only necessary if the in- stallation already exists). Connect the supplied PV+/PV- cables to the respective connections. IMPORTANT! Note the labeling of the cables when connecting. Connect the supplied cables to the re- spective connections on the PC board.
Page 155 Insert the PC board into the inverter and secure with the four screws (TX20) supplied at a torque of 1.0‑1.2 Nm. IMPORTANT! max. Depending on national standards and Ø10mm guidelines, a larger cross-section of the ground conductor may be required. 1,5 Nm TX 20 Dimension the cable cross-section of...
Page 156 Strip the insulation on the single con- ductors by 12 mm and secure to the corresponding slot of the terminal on the PC board with a torque of 1.2-1.5 IMPORTANT! The cable cross-section must be selec- ted according to the specifications for the respective inverter power category (see chapter Permissible cables for...
Page 157 Remove the factory installed bypass on the push-in WSD terminal. Connect the signal cable to the push- in WSD terminal on the IN- and IN+ slots, observing the labeling. Check whether the WSD switch is in position 1, adjust if necessary (factory setting: position 1).
Page 158 Place the cover on the connection area. Tighten the five screws by rotat- ing them 180° to the right in the indic- ated order using a screwdriver (TX20). Clip the housing cover onto the invert- er from above. Press on the lower part of the housing cover and tighten the two screws by rotating them 180°...
Page 159 Set the DC disconnector to the "on" switch position. Turn on the automatic circuit breaker.
Page 160 This can result in severe personal injury and damage to property. ▶ The commissioning, maintenance, and service work in the inverter's power stage set may only be carried out by Fronius-trained service personnel in accordance with the technical specifications. ▶...
Page 161 WARNING! Danger from mains voltage and DC voltage from PV modules that are exposed to light. This can result in severe personal injury and damage to property. ▶ All connection, maintenance, and service work should only be carried out when the AC and DC sides have been disconnected from the inverter and are de-energized.
Page 162 De-energizing Turn off the automatic circuit breaker. the inverter Set the DC disconnector to the "off" switch position. Disconnect connections from the solar module strings (+/-). Switch off the battery connected to the inverter. Wait for the capacitors of the inverter to discharge (2 minutes).
Page 163 Loosen the two screws on the under- side of the housing cover by rotating them 180° to the left using a screw- driver (TX20). Then lift the housing cover away from the inverter at the bottom and detach from above. Loosen the 5 screws of the connection area cover by rotating them 180°...
Page 164 Manually push the DC cables through the DC bushings. Press the lock on the back of the ter- minal and remove the DC terminals. Strip the insulation of the single con- ductors by 18-20 mm. Select the cable cross-section in ac- cordance with the instructions in Per- missible cables for the electrical con-...
Page 165 Connect the solar module strings (+/-). Use a suitable measuring instrument to check the voltage and polarity of the DC cabling. CAUTION! Danger due to polarity reversal at the terminals. This may result in severe damage to the inverter. ▶ Check the voltage (max.
Page 166 Place the cover on the connection area. Tighten the 5 screws by rotating them 180° to the right in the indicated order using a screwdriver (TX20). Clip the housing cover onto the invert- er from above. Press on the lower part of the housing cover and tighten the 2 screws by ro- tating them 180°...
Page 167 Set the DC disconnector to the "on" switch position. Turn on the automatic circuit breaker.
Page 168 This can result in serious injury and damage to property. ▶ Installing and connecting an option must only be carried out by service personnel trained by Fronius and only within the scope of the respective technical regulations. ▶ Follow the safety rules.
Page 169 Scope of supply The PV Point Comfort is available as an option and can be retrofitted to the in- verter. For technical data, see chapter Technical data on page 189. Insulation film PV Point Comfort PEN connection Phase/neutral conductors 4 pcs TX20 screws Cable gland User information De-energizing...
Page 170 Installation CAUTION! Danger due to insufficiently dimensioned ground conductor. Damage to the inverter due to thermal overload can result. ▶ The national standards and guidelines must be observed for dimensioning the ground conductor. Loosen the 2 screws on the underside of the housing cover by rotating them 180°...
Page 171 Disconnect the single conductors from the AC terminal (only necessary if the installation already exists). Take the ferrite core off and remove the mains cable from the inverter. Drill out the optional cable bushing with a step drill.
Page 172 Insert the cable gland into the hole and tighten to a torque of 6 Nm. Insert the insulating film on the right side of the ground electrode terminal. Insert the PC board into the inverter.
Page 173 Fasten the PC board with the 4 screws (TX20) supplied and tighten to a torque of 1.2 Nm. Strip the insulation of the single conductors by 12 mm. Lift to open the AC ter- minal's operating lever and insert the stripped single conductor into the slot provided, all the way up to the stop.
Page 174 Strip the insulation of the single con- ductors by 12 mm. The cable cross-section must be selec- ted according to the specifications for the respective inverter power category (see chapter Permissible cables for the electrical connection on page 66). The residual current circuit breaker and automatic circuit breaker must be designed according to the national provisions.
Page 175 Insert the terminals into the respect- ive slot until they engage. Fasten the union nuts of the cable glands to a torque of 4 Nm. Place the cover on the connection area. Tighten the 5 screws by rotating them 180° to the right in the indicated order using a screwdriver (TX20).
Page 176 Starting up the Connect the solar module strings (+/-). inverter Switch on the battery connected to the inverter. Set the DC disconnector to the "on" switch position. Turn on the automatic circuit breaker. Configuring the Firmware version 1.25.2 or higher is required to commission the PV Point Com- PV Point Com- fort.
Page 177 During ongoing operation (recommendation: at least once a year) For test mode, a battery charge of min. 30% is recommended. A description on how to run test mode can be found in the backup power check- list (https://www.fronius.com/en/search-page, item number: 42,0426,0365).
Page 179 Appendix...
Page 181 Nevertheless, a few points must be considered during operation to ensure that the inverter works perfectly. Maintenance Maintenance and service work may only be carried out by Fronius-trained service technicians. Cleaning Wipe the inverter, if necessary, with a damp cloth.
Page 182 Switch off power to the inverter and wait for the capacitors to discharge (2 minutes) and the fan to shut down. Turn the DC disconnector to the "off" switch setting. Loosen the screws on the underside of the housing cover by rotating them 180°...
Page 183 used device promotes sustainable recycling of resources and prevents negative effects on health and the environment. Packaging materials Collect separately Observe local regulations Crush cardboard boxes...
Page 184 Warranty provisions Fronius manu- Detailed, country-specific warranty conditions are available at www.fronius.com/ facturer's war- solar/warranty. ranty To obtain the full warranty period for your newly installed Fronius product, please register at www.solarweb.com.
Page 185 Backup backup power Fronius Smart Meter 63A-3 43,0001,1473 changeover Fronius Smart Meter 50kA-3 43,0001,1478 Fronius Smart Meter TS 65A-3 43,0001,0044 Fronius Smart Meter TS 5kA-3 43,0001,0046 Fronius Smart Meter WR 43,0001,3591 Grid and system protection unit (fuse protection: 3-pin, 6 A)
Page 186 3 kA (make contacts) rent Test standard IEC 60947-4-1 Examples of contact- ISKRA IKA225-02 ors and relays Components for Product Item number manual backup Fronius Smart Meter 63A-3 43,0001,1473 power changeover to Fronius Smart Meter TS 65A-3 43,0001,0044 Full Backup...
Page 187 Product Item number Fronius Backup Switch 1P/3P-63A 4,050,221 Fronius Backup Switch 1PN/3PN-63A 4,050,220...
Page 188 Status codes and remedy Display Status codes are displayed on the user interface of the inverter in the System > Event Log menu area or in the user menu under Notifications and in Fronius Sol- ar.web*. If configured accordingly, see chapter Fronius Solar.web...
Page 189 Technical data Fronius Symo DC input data GEN24 6.0 / 6.0 MPP voltage range 174 - 800 V Plus (at rated power) Max. connected load (P PV max 9000 Wp Total 7500 Wp PV 1 6500 Wp PV 2 Max. processable PV power...
Page 190 DC input data Adjustable range of continuous resid- 30 - 300 mA ual current monitoring Cyclic repetition of the insulation res- 24 h istance test (on delivery) Adjustable range for cyclic repetition of the insulation resistance test DC input data battery Max.
Page 191 AC output data PV Point / PV Point Comfort Nominal mains voltage 1 ~ NPE 220 V / 230 V / 240 V Nominal frequency 53 / 63 Hz Switching time ~ 15 s 0 - 1 Power factor cos phi AC output data Full Backup Max.
Page 192 Power per digital output 1 A at >12.5 V - 24 V (with external supply) (max. 3 A in total) Datalogger/web server Integrated Fronius Symo DC input data GEN24 8.0 / 8.0 MPP voltage range 224 - 800 V Plus (at rated power) Max.
Page 193 DC input data Feed-in start-up input voltage in grid 80 V operation Max. input current PV 1 25.0 A PV 2 12.5 A Max. short circuit current for module array (I SC PV 40 A PV 1 20 A PV 2 Max.
Page 194 AC input/output data Rated power (P 8000 W Max. output power 8000 W Rated apparent power 8000 VA Nominal mains voltage 3 ~ NPE 220 V / 380 V 3 ~ NPE 230 V / 400 V Min. mains voltage 154 V Max.
Page 195 AC output data Full Backup Nominal frequency for Full Backup 53 / 63 Hz Switching time ~ 10 s 0 - 1 Power factor cos phi General data Max. efficiency 98.2 % Europ. efficiency (U 97.8 % mpp nom Europ. efficiency (U 97.5 % mpp max Europ.
Page 196 Power per digital output 1 A at >12.5 V - 24 V (with external supply) (max. 3 A in total) Datalogger/web server Integrated Fronius Symo DC input data GEN24 10.0 / MPP voltage range 278 - 800 V 10.0 Plus (at rated power) Max.
Page 197 DC input data Max. inverter backfeed current to the array 40 A PV 1 20 A PV 2 Number of inputs - PV 1 Number of inputs - PV 2 Max. capacity of the PV generator 2000 nF against earth Limit value of the insulation resist- 100 kΩ...
Page 198 AC input/output data Rated output current 14.5 A (at 230 V) 9.9 A / 4 ms Current (inrush) Nominal frequency 50 / 60 Hz Initial symmetrical short-circuit cur- 16.4 A rent / phase I " Nominal frequency for Full Backup 53 / 63 Hz Total harmonic distortion <...
Page 199 General data Europ. efficiency (U 97.1 % mpp min Self-consumption at night ≤ 10 W Cooling Controlled forced-air ventilation Protection class IP 66 Dimensions H × W × D 595 × 529 × 180 mm Weight 23.4 kg Inverter topology Non-insulated, no transformer Permitted ambient temperature -25 °C - +60 °C...
Page 200 Power per digital output 1 A at >12.5 V - 24 V (with external supply) (max. 3 A in total) Datalogger/web server Integrated Fronius Symo DC input data GEN24 10.0 / MPP voltage range 278 - 800 V 10.0 Plus...
Page 201 DC input data Limit value and trip time of sudden 30 / 300 mA / ms residual fault current monitoring (on 60 / 150 mA / ms delivery) 90 / 40 mA / ms Limit value and trip time of continu- 300 / 300 mA / ms ous residual fault current monitoring (on delivery)
Page 202 AC output data PV Point / PV Point Comfort Max. output power 4133 W (for 5 s) Rated power 3000 W Rated output current 13 A Nominal mains voltage 1 ~ NPE 220 V / 230 V / 240 V Nominal frequency 53 / 63 Hz Switching time...
Page 203 General data Sound pressure level 47 dB(A) (ref. 20µPA) Safety class (according to IEC 62103) Protection devices DC isolation measurement Warning/shutdown at R < 100 kOHM Overload performance Operating point shift, power limitation DC disconnector Integrated RCMU Integrated RCMU classification The software class of the safety plat- form(s) is defined as a class B control function (single-channel with periodic...
Page 204 For backup power mode (PV Point) without a battery, a min. voltage of 150 V is required. Peak current when turning on the inverter. The total nominal output power per phase must not exceed the nominal output power of the inverter. Valid for Fronius inverter with battery support.
Page 205 The values provided are standard values. These values must be adjusted according to requirements and PV output. The value provided is a max. value. If this value is exceeded, this may im- pair the function. Integrated DC General data disconnector Product name Benedict LS32 E 7905 Rated insulation voltage...
Page 206 Rated operating current and rated breaking capacity Rated operating Rated operating Rated operating (make) (make) voltage (U current (I current (I (break) (break) 300 V 27 A 108 A 47 A 188 A 400 V 20 A 80 A 45 A 180 A 500 V 14 A...
Page 207 Circuit Diagrams...
Page 209 Fronius Symo GEN24 and BYD Battery-Box Premium HV Circuit diagram...
Page 210 Fronius Symo GEN24 with two BYD Battery-Box Premium HV connected in parallel Circuit diagram...
Page 211 Fronius Symo GEN24 with three BYD Battery-Box Premium HV connected in parallel Circuit diagram...
Page 212 Fronius Symo GEN24 and LG FLEX Circuit diagram...
Page 213 Emergency power terminal—PV Point (OP) Circuit diagram...
Page 214 Circuit diagram - PV Point (OP) Australia Circuit diagram...
Page 215 Backup power terminal - PV Point (OP) with bat- tery only for France Circuit diagram...
Page 216 Backup power terminal - PV Point (OP) manual changeover Circuit diagram...
Page 217 PV Point Comfort Circuit diagram...
Page 218 Automatic switch to backup power 3-pin single FRT-capable separation - e.g., Austria Circuit diagram...
Page 219 Automatic switch to backup power 3-pin single separation - e.g., Australia Circuit diagram...
Page 220 Automatic switch to backup power 3-pin double separation with ext. grid and system protection Circuit diagram...
Page 221 Automatic switch to backup power 4-pin single separation - e.g., Germany Circuit diagram...
Page 222 Automatic switch to backup power 4-pin single FRT-capable separation Circuit diagram...
Page 223 Automatic switch to backup power 4-pin single separation - e.g., France Circuit diagram...
Page 224 Automatic switch to backup power 4-pin single separation - e.g., Spain Circuit diagram...
Page 225 Automatic switch to backup power 4-pin double separation with ext. grid and system protection - e.g., Italy Circuit diagram...
Page 226 Manual switch to backup power 3-pin separation, e.g., Austria Circuit diagram...
Page 227 Manual switch to backup power 4-pin separation, e.g., Germany Circuit diagram...
Page 228 Surge protection device (SPD) Circuit diagram...
Page 229 Dimensions of the inverter...
Page 231 Fronius Symo GEN24 6-10 kW Fronius Symo GEN24 6-10 kW...

This manual is also suitable for:

Symo gen24 6.0.plus Symo gen24 8.0 Symo gen24 8.0 plus Symo gen24 10.0 Symo gen24 10.0 plus

Fronius Symo GEN24 6.0 Operating Instructions Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Fronius Symo GEN24 6.0

Summary of Contents for Fronius Symo GEN24 6.0

This manual is also suitable for:
