MODEL# 1411015HD
ASSEMBLY INSTRUCTIONS GUIDE
17" CLOSET TOWER
w/ DRAWERS
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Phone Number: 1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually
create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing StyleWell!
Advertisement
Related Manuals for StyleWell 1411015HD
Summary of Contents for StyleWell 1411015HD
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement...
- Page 2 Pre-assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. TOOLS REQUIRED Phillips Claw hammer Drill screwdriver...
- Page 3 Pre-assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. TOOLS REQUIRED Phillips Claw hammer Drill screwdriver...
- Page 4 Disassembling slides (A56100): Extend each section as shown. Press the black lever upward and separate the two parts of the slide. Lever Outer slide section will attach to the Left Side (A) and Right Side (B). Use holes marked with arrows to fasten. Inner slide section will attach to the drawer sides.
- Page 5 ITEM# MODEL# 1411xxxHD Pre-assembly (continued) PACKAGE CONTENTS PART CODE PART NUMBER DESCRIPTION 37764015010 LEFT PANEL - LOWER 37764015020 RIGHT PANEL - LOWER 37764015030 LEFT PANEL - UPPER 37764015040 RIGHT PANEL - UPPER 36903015050 TOP SHELF 36903015060 BOTTOM SHELF 36903015070 MIDDLE SHELF ADJUSTABLE SHELF 36903015080 36903015090...
- Page 6 ITEM# MODEL# 1411xxxHD Pre-assembly (continued) PACKAGE CONTENTS SIDE SIDE BACK HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 7 Assembly Arrange Left Panel (A) and Right Panel (B) as shown. In the unfinished edge, insert the nuts (5) into the holes with a hammer. Thread adjustable leveling feet into the nuts. 2 - x4 3 - x4 4 - x4 Insert wood dowels and connectors as shown.
- Page 8 Assembly Arrange one Left Panel (C) and one Right Panel (D) as shown. In the unfinished edge insert insert wood dowels as shown. Insert four connectors as shown. 2 - x4 3 - x8 Lightly tap with hammer if necessary C - x1 D - x1 finished edge...
- Page 9 Assembly Install connectors into holes of Bottom Shelf (F). Be sure all connectors are fully seated and placed correctly. Insert wood dowels into the holes on the unfinished edge. You may need to tap connectors and dowels with a hammer to fully insert. 3 - x4 2 - x4 F - x1...
- Page 10 Assembly Install connectors into holes of both Back Panels (I & J). Be sure all connectors are fully seated and placed correctly. Insert wood dowels into the holes on the unfinished edges. You may need to tap connector and dowels with a hammer to fully insert.
- Page 11 Assembly Connect Back Panel (I) to Bottom Shelf (F) by inserting dowels and connector as shown. Turn connector screw clockwise to lock in place. Lock Unfinished finished edge Surface With Back Panel (I) and Bottom Shelf (F) connected, carefully insert dowels and connectors as shown.
- Page 12 Assembly Attach Right Panel (B) by carefully inserting dowels and connectors as shown. Turn three connector screws clockwise to lock in place. Lock Unfinished Surface Attach Left and Right Panel (C & D) to Back Panel (J) by inserting the connectors as shown. Enlist a helper to hold the panels in position until the next step.
- Page 13 Assembly Attach Middle Shelf (G) to Left and Right Panels (C & D) by inserting dowels and connectors as shown. Secure the Middle Shelf using two screws as shown. 1 - x2 Attach Top Shelf (E) by inserting dowels and connectors as shown. Turn four connector screws clockwise to lock in place.
- Page 14 Assembly With a helper, attach the lower section to the upper section by carefully inserting dowels and connectors as shown. Turn four connector screws clockwise to lock in place. Lock With a helper, position the unit upright. Turn one connector screw clockwise to lock in place. Lock HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 15 Assembly Warning All units MUST be fastened to the wall. Place unit inside closet (allow 30" to 48" on each side for clothing rod). Use a level and adjust adjustable leveling feet to be sure it is square. Place L-bracket on top of the unit with bracket screw using existing hole location. Mark hole location on wall.
- Page 16 Assembly Position the Left Drawer Side and Right RIGHT DWR LEFT DWR Drawer Side as shown. 3 - x6 2 - x12 SIDE- x3 SIDE- x3 Insert two connectors (2) into each Drawer Side as shown. Insert one dowel (3) into each Drawer Side as shown.
- Page 17 Assembly Make sure the orientation of the parts are as RIGHT DWR DRAWER LEFT DWR shown (Groove towards bottom). SIDE- x3 BACK - x3 SIDE- x3 Engage the connector on Drawer back to the Left and Right Drawer sides. Turn the screw on connectors (2) clockwise to lock in place.
- Page 18 Assembly Engage the connector on Left and Right Drawer side guided by the dowels into the the Drawer front. Z- x3 Turn the screw on connectors clockwise to lock in place. SIDE BACK SIDE Verify connector is fully seated and straight. Install the Inner slide using Screw (13) as shown.
- Page 19 Assembly Insert Drawers so inner slides (12b) engage the outer slide (12a). Push firmly in. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 20 Assembly Once the unit is secured to the wall you can install the Adjustable Shelves (H). Place the shelf supports in the desired hole locations, ensuring they are level from side to side. Insert shelves. H - x2 6 - x8 HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 21 Assembly Choose "double hang" and "single hang" side. If the pre-drilled hole locations are not suitable for your needs, you can mark and drill pilot holes at your desired location. Please use a 1/16" drill bit and be careful not to drill too deep. Note: the pre-drilled holes for the closet rod locations are shown on the outside of...
- Page 22 Assembly Secure each Adjustable Rod with two screws. 9 - x6 11 - x3 HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 23 Assembly Extend rod to the wall and hold in place. Be sure rod is level and mark hole locations on wall. Repeat for all bracket locations. Screw in wall anchors at marked locations and secure each rod to the wall with screws. 8 - x6 10 - x6 wall...
- Page 24 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday PHONE NUMBER : 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
