Armoire side cabinet
Hide thumbs

Advertisement

Table of Contents

8393222COM
Armoire Side Cabinet
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
B348393222COM1
Tough

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8393222COM and is the answer not in the manual?

Questions and answers

Related Manuals for Ameriwood HOME 8393222COM

Summary of Contents for Ameriwood HOME 8393222COM

  • Page 1 Easy Tough Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit. - Put heavy items on lower shelves or drawers.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting.

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Parts are labeled on the surface or edge of the part Give yourself enough room for the assembly process Have the following tools: #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
  • Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels into the holes during your assembly process. ameriwoodhome.com...

  • Page 5: Board Identification

    Board Identification Not actual size (x2) Fixed Shelf 38393222030 Adjustable Shelf 38393222050 38393222040 Bottom Upper Back Panel (x2) 38393222060 38393000070 Stringer 38393000080 Left Panel Right Panel 38393222011 38393222021 Apron Valance Kick Door Molding Door Panel 38393222100 38393222090 38393222110 38393222130 38393222120 ameriwoodhome.com...
  • Page 6 Board Identification Not actual size (X3) (x3) (x3) Drawer Front Drawer Front Molding Drawer False Front 38393222140 38393222150 39991167047415F BACK SIDE SIDE (x3) (x3) (x3) Drawer Side Left Drawer Side Right Drawer Back 39991167340430L 39991167340430R 39991167047415B BACK (x3) Back Panel Drawer Bottom K839322200 39991324048420D...
  • Page 7 Board Identification Not actual size SIDE BACK BACK SIDE ameriwoodhome.com...

  • Page 8: Part List

    Note: Your unit may contain extra hardware. Part List Actual Size (x24) (x24) (x12) (x24) (x21) (x3) #A22620 #A22610 #A21670 #A23025 #A12810 #A22770 cam lock cam bolt wood dowel confirmat screw #8 x 1" screw quicklock (x40) (x10) (x4) (x8) #A12120 #A54710 #A13950...
  • Page 9 Note: Your unit may contain extra hardware. Part List Actual Size (x3) (x6) (x1) #A65685 #A11070 #A65690 hinge plate euro screw glissando soft close Not Actual Size (x3) (x3) (x1) #A65680 #A56100 #A81930 euro hinge slide wardrobe rail ameriwoodhome.com...
  • Page 10 Note: Your unit may contain extra hardware. Part List Not Actual Size Your unit comes with four (4) drawer slides. For each slide, extend the slide as shown and press the release lever to remove the inner slide. Set the inner slide aside for later. For Step 3 and 4, you will be attaching the slide to the panels at the rear of the slide.
  • Page 11 STEP 1 (x12) ameriwoodhome.com...
  • Page 12 STEP 2 (x9) (x3) ameriwoodhome.com...
  • Page 13 STEP 3 (x12) ameriwoodhome.com...
  • Page 14 STEP 4 (x9) (x3) ameriwoodhome.com...
  • Page 15 STEP 5 Quick Assembly Proper orientation of CAM LOCK (x12) (x6) (x6) ameriwoodhome.com...
  • Page 16 STEP 6 Turn clockwise to lock in place. ameriwoodhome.com...
  • Page 17 STEP 7 Quick Assembly Proper orientation of CAM LOCK (x12) (x6) ameriwoodhome.com...
  • Page 18 STEP 8 ameriwoodhome.com...
  • Page 19 STEP 9 ameriwoodhome.com...
  • Page 20 STEP 10 ameriwoodhome.com...
  • Page 21 STEP 11 Place your unit on its front. Slide back Panel into the grooves in the Left & Right Panels (A & B). BACK unfinished side ameriwoodhome.com...
  • Page 22 STEP 12 (x4) BACK Line up bottom of Back Panel with bottom edge of Bottom (F). ameriwoodhome.com...
  • Page 23 STEP 13 (x10) (x2) (x2) Slide the Wedges (10) into the groove against the back Panel, and secure with screw. Tap in T-Nut (14) with a hammer. Screw in Glides (13) all the way. ameriwoodhome.com...
  • Page 24 The next steps are to assemble your unit to the wall Assembled unit MUST be square on the height, width, and depth to function properly Assembled unit MUST be placed flat against the wall Assembled unit MUST be screwed into wall studs at the top and bottom for safety You need to locate at least 1 stud, but 2 is better DO NOT use wall anchors to fasten your unit to the wall...
  • Page 25 STEP 14 Place your unit FLUSH against the wall There are notches provided at the back of your unit. These notches are to fit around the baseboard on your wall. If your baseboard is higher or thicker than the notches provided on the unit, you will need to remove the baseboard, cut it down to fit on both sides of your...
  • Page 26 STEP 15 Assembled unit MUST be square on the height, width, and depth to function properly A ladder will be required. Do not lean against the top of the unit, it may cause sagging. If required, unscrew the Glides counter-clockwise as necessary until your unit is level.
  • Page 27 STEP 16 Locate the studs in the wall using a stud finder. Using a pencil, mark the stud locations at the top of the Upper Back Panel (G) and on the Stringer (H). Wall Studs You need to locate at least 1 wall stud, in the horizontal direction, but 2 is better.
  • Page 28 STEP 17 (x4) First, make sure that your unit is still level in all directions. Drill 1/8" (3mm) pilot holes through the Upper Back Panel (G) and through the Stringer (H) at the the stud locator marks. Fasten the unit to the studs in the wall with Screws (7).
  • Page 29 STEP 18 (x6) (x18) SIDE SIDE Inner Slide Use these holes ameriwoodhome.com...
  • Page 30 STEP 19 (x12) SIDE SIDE ameriwoodhome.com...
  • Page 31 STEP 20 (x12) BACK SIDE SIDE ameriwoodhome.com...
  • Page 32 STEP 21 (x18) ameriwoodhome.com...
  • Page 33 STEP 22 Install drawers by engaging the inner slides (attached to the Drawer Sides) with the outer slides (attached to the Left and Right Panel). Push in until the plastic lever snaps into the outer slide. Outer Slide Note: To adjust Drawer Fronts, loosen screws (5), make needed adjustments and retighten.
  • Page 34 STEP 23 (x8) ameriwoodhome.com...
  • Page 35 STEP 24 (x3) (x3) (x6) ameriwoodhome.com...
  • Page 36 STEP 25 (x2) (x2) (x3) Arrow faces front of unit. ameriwoodhome.com...
  • Page 37 STEP 26 Door is reversible. If you would like the door to open from other side, repeat steps 25 and 26 with the parts installed on the opposite side panel. hook Eccentric adjustment screw. Shifts the whole hinge up and down. Adjust the gaps between the door and the left and right panels (side to side)
  • Page 38 STEP 27 This step is optional... Place Glissando Soft Close (17) on the lower hinge of the door (L). ameriwoodhome.com...
  • Page 39 STEP 28 This step is optional... (x4) (x1) To use optional Wardrobe Rail. Remove adjustable shelves (D) and screw Wardrobe Rail (21) into bottom side of Top (C). ameriwoodhome.com...
  • Page 40 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 10 lbs (4.54 kg) Adjustable Shelf 30 lbs (13.63 kg) Fixed Shelf 40 lbs (18.18 kg) Drawers 25 lbs (11.36 kg) Warning: Risk of injury to persons - do not place a television on this furniture.
  • Page 41 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! ameriwoodhome.com...
  • Page 42 Espa ol Cubierta Delantera Este libro de instrucciones contiene informaci n IMPORTANTE de seguridad. Por favor lea y mant ngalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda.
  • Page 43 Espa ol P gina 5 - Identificaci n de la tabla P gina 8 - Lista de piezas No est a escala real Escala real Cerradura de leva (1) Panel izquierdo (A) Panel derecho (B) Perno de leva (2) Parte superior (C) Clavija de madera (3) Estante ajustable (D) Tornillo Confirmat (4)
  • Page 44 Espa ol P gina 16 - G rela en el sentido de las agujas del reloj para bloquearla P gina 17 - Orientaci n exterior de la cerradura de leva P gina 21 - Coloque la unidad boca abajo. *Deslice el panel tresero en las ranuras de los paneles izquierdo y derecho (A y B) *lado sin acabado P gina 22 - Alinee la parte inferior del panel trasero con el borde inferior de la parte de abajo (F) P gina 23 - Deslice las cu as (10) en la ranura contra el panel trasero y f jelas con tornillos.
  • Page 45 Espa ol P gina 27 - Para localizar los montantes en la pared, utiliza un buscador de montantes. Luego, marca las ubicaciones de los montantes en la parte superior del Panel Posterior Superior (G) y en el Travesa o (H). Los montantes deben estar al menos 1 en direcci n horizontal, pero 2 es preferible. Ser necesario usar una escaleraNo te apoyes en la parte superior de la unidad, ya que podr a provocar que se hunda P gina 28 - Necesitar una escalera.
  • Page 46 Espa ol P gina 40- weight limit page Esta unidad ha sido dise ada para soportar las cargas m ximas indicadas. Exceder estos l mites de carga podr a provocar hundimiento, inestabilidad, colapso del producto y/o lesiones graves. Advertencia: Riesgo de lesiones para las personas: no coloques un televisor sobre este mueble. Este mueble no est aprobado para su uso con un televisor P gina 41 Registre su producto para recibir lo siguiente:...
  • Page 47 Fran ais Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA S CURIT . VEUILLEZ LIRE ET GARDER POUR UNE R F RENCE FUTURE Ne retournez pas ce produit! Contactez notre quipe de service la client le amicale d'abord pour obtenir de l'aide.
  • Page 48 Fran ais Page 5 - Liste des pi ces Page 8 - Liste des pi ces Taille non r elle Taille r elle Panneau gauche (A) Serrure came (1) Panneau droit (B) Boulon came (2) Panneau sup rieur (C) Cheville en bois (3) Tablette r glable (D) Vis de contr le (4) tag re fixe (E)
  • Page 49 Fran ais Page 16 - Tournez dans le sens des aiguilles d'une montre pour verrouiller la bonne place. Page 17 - Orientation correcte de la serrure came Page 21 - Placez votre unit sur sa face avant. * Glissez le panneau arri re dans les rainures des panneaux gauche et droit (A et B). * C t inachev Page 22 - Alignez le bas du panneau arri re avec le bord inf rieur du fond (F).
  • Page 50 Fran ais Page 27 - Pour localiser les montants dans le mur, utilisez un d tecteur de montants. Ensuite, marquez les emplacements des montants en haut du panneau arri re sup rieur (G) et sur le traverse (H). Les montants doivent tre au moins 1 dans la direction horizontale, mais 2 sont pr f rables. Une chelle sera n cessaire.
  • Page 51 Fran ais Page 40 - weight limit step Cette unit a t con ue pour supporter les charges maximales indiqu es. D passer ces limites de charge pourrait entra ner un affaissement, une instabilit , l effondrement du produit et/ou des blessures graves.
