8844013COM/ 8844911COM/ 8844847COM
ALL In One Storage Cubbie
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B348844XXXCOM00GO
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
Tough
Advertisement
Table of Contents
Related Manuals for Ameriwood HOME 8844013COM
Summary of Contents for Ameriwood HOME 8844013COM
- Page 1 8844013COM/ 8844911COM/ 8844847COM ALL In One Storage Cubbie B348844XXXCOM00GO Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Call us! 1-800-489-3351 Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting. - Identify, sort and count the parts before attempting assembly. -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order. Separate and count all your parts and hardware. Give yourself enough room for the assembly process. Have the following tools: #2 Phillips Head Screwdriver and Hammer. Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. - Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels with a hammer into the holes during your assembly process. Wood Dowel Insertion: Insert wood dowel completely into the hole. Not Actual Size Wood dowel will extend out approximately 3/8".
-
Page 5: Board Identification
Board Identification Not Actual Size Upper Left Panel Upper Right Panel Upper Partition 1 PC 1 PC 1 PC Upper Solid Back Mid Solid Back Lower Solid Back 1 PC 1 PC 1 PC Rail Upper Bottom Upper Shelf 1 PC 2 PCS 1 PC Fixed Shelf... - Page 6 Board Identification Not Actual Size Lower Left Panel Lower Right Panel Lower Partition 1 PC 1 PC 2 PCS Large Back Panel Small Lower Back Panel Small Upper Back Panel 1 PC 1 PC 1 PC For any replacement part, see page 8. 3 PCS ameriwoodhome.com Tube...
- Page 7 Board Identification Not Actual Size ameriwoodhome.com Tube...
-
Page 8: Part Number Reference
Each part has a unique part number. Please refer to the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above. 8844013COM 8844911COM 8844847COM PART... - Page 9 Part List Actual Size For any replacement hardware, see page 10. (x26) (x59) Cam Bolt Wood Dowel Ø6x25 mm Ø6x30 mm (x2) (x2) (x26) (x36) Screw Screw Screw Screw Ø4x38mm Ø4.2x45 mm Ø5x38 mm Ø3x12 mm Not Actual Size (x2) (x26) Wall Anchor Cam Lock...
- Page 10 Each part has a unique part number. Please refer to the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above. 8844013COM 8844911COM 8844847COM MODEL#...
- Page 11 STEP Dowels extend out 3/8". For more details, please see (x34) page 4 (x2) Attach 2 Cam Bolts (1) to Mid Solid Back (E), Lower Solid Back (F) as illustrated. Do NOT over-tighten. Insert 34 Wood Dowels (2) into Boards (D), (E), (F), (G) and (H) x 2 as illustrated. ameriwoodhome.com Tube...
- Page 12 STEP Arrow to point towards end hole in edge of part End hole (x1) (x4) Attach Upper Bottom (H) to Upper Solid Back (D) with 4 Screws (3) as illustrated. Attach Mid Solid Back (E) to Upper Bottom (H) with Cam Lock (8) as illustrated. Finished Surface Finished...
- Page 13 STEP Arrow to point towards end hole in edge of part End hole (x1) (x4) Attach Upper Bottom (H) to Mid Solid Back (E) with 4 Screws (3) as illustrated. Attach Lower Solid Back (F) to Upper Bottom (H) with Cam Lock (8) as illustrated. Unfinished Surface Unfinished...
- Page 14 STEP Dowels extend out 3/8". For more details, please see (x5) page 4 (x10) Attach 10 Cam Bolts (1) to Upper Left Panel (A), Upper Right Panel (B) and Upper Partition (C) as illustrated. Do NOT over-tighten. Insert 5 Wood Dowels (2) into Upper Left Panel (A), Upper Right Panel (B), Upper Partition (C) and Upper Shelf (I) as illustrated.
- Page 15 STEP Arrow to point towards end hole in edge of part End hole (x3) Attach boards (D), (H), (E) and (F) to Upper Right Panel (B) with 3 Cam Locks (8) as illustrated. Unfinished Edge ameriwoodhome.com Tube...
- Page 16 STEP Insert Rail (G), Rod (S) X 3 into Upper Right Panel (B) as illustrated. Finished Edge Finished Edge ameriwoodhome.com Tube...
- Page 17 STEP Arrow to point towards end hole in edge of part End hole (x3) Attach Upper Partition (C) to boards (D), (E), (F), (G), (H) X 2 and Rod (S) x 3 with 3 Cam Locks (8) as illustrated. Unfinished Edge Unfinished Edge...
- Page 18 STEP Arrow to point towards end hole in edge of part End hole (x2) Attach Upper Shelf (I) to Upper Partition (C) with 2 Cam Locks (8) as illustrated. Finished Edge ameriwoodhome.com Tube...
- Page 19 STEP Arrow to point towards end hole in edge of part End hole (x2) Attach Upper Left Panel (A) to Upper Shelf (I) with 2 Cam Locks (8) as illustrated. Finished Edge ameriwoodhome.com Tube...
- Page 20 STEP (x8) Attach 8 Cam Bolts (1) to Fixed Shelf (J) as illustrated. Do NOT over-tighten. Finished Edge Unfinished Edge Finished Edge ameriwoodhome.com Tube...
- Page 21 STEP (x14) Attach Fixed Shelf (J) to (A), (B), (C), (F) and (G) with 14 Screws (3) as illustrated. Finished Edge ameriwoodhome.com Tube...
- Page 22 STEP Dowels extend out 3/8". For more details, please see page 4 (x20) (x6) Attach 6 Cam Bolts (1) to Lower Left Panel (M), Lower Right Panel (N) as illustrated. Do NOT over-tighten. Insert 16 Wood Dowels (2) into Lower Left Panel (M), Lower Right Panel (N), Bottom Panel (K), Front Panel (L) and Lower Partition (O) x 2 as illustrated.
- Page 23 STEP (x4) Attach Lower Partition (O) x 2 to Bottom Panel (K) with 4 Screws (3) as illustrated. Finished Edge Unfinished Edge Unfinished 4 Edge Unfinished Surface ameriwoodhome.com Tube...
- Page 24 STEP Arrow to point towards end hole in edge of part End hole (x2) Attach Lower Left Panel (M) to Bottom Panel (K) with 2 Cam Locks (8) as illustrated. Finished Edge ameriwoodhome.com Tube...
- Page 25 STEP Arrow to point towards end hole in edge of part End hole (x1) Attach Front Panel (L) to Lower Left Panel (M) with 1 Cam Locks (8) as illustrated. Finished Edge ameriwoodhome.com Tube...
- Page 26 STEP Arrow to point towards end hole in edge of part End hole (x3) Attach Lower Right Panel (N) to Bottom Panel (K), Front Panel (L) with 3 Cam Locks (8) as illustrated. Finished Edge ameriwoodhome.com Tube...
- Page 27 STEP (x2) Attach Front Panel (L) to Lower Partition (O) x 2 with 2 Screws (5) as illustrated ameriwoodhome.com Tube...
- Page 28 STEP Arrow to point towards end hole in edge of part End hole (x8) Attach boards (M), (N), (O) to Fixed Shelf (J) with 8 Cam Locks (8) as illustrated. ameriwoodhome.com Tube...
- Page 29 STEP (x36) With the assistance of a second person, carefully turn the unit over so that the back is accessible. Attach the Back Panel (P),(Q) and (R) to boards (M),(N),(J),(A),(C),(I) and (K) as shown.Verify that the unit is square before connecting with 36 Screws (6).
- Page 30 STEP For Masonry, Concrete, or other wall materials: Consult your local hardware store for appropriate anchors to securely (x2) attach the safety bracket. (x2) THESE INSTRUCTIONS TO INSTALL THE ANTI‐TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT. hole 7 X 2 stud OPTION 2 WARNING...
- Page 31 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 20 lbs/ 9 kgs 25 lbs/ 13 kgs 25 lbs/ 13 kgs 25 lbs/ 13 kgs 25 lbs/ 13 kgs...
- Page 32 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com Tube...
- Page 33 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 34 Español Página 5,6 & 7: Identificación de la Junta Página 9: Lista de No es la talla actual Tamaño real PANEL SUPERIOR IZQUIERDO PANEL SUPERIOR DERECHO Perno de leva PARTICIÓN SUPERIOR Pasador de madera RESPALDO SÓLIDO SUPERIOR Tornillo RESPALDO SÓLIDO MEDIO Tornillo RESPALDO SÓLIDO INFERIOR Tornillo...
- Page 35 Español ameriwoodhome.com Tube...
- Page 36 Español ameriwoodhome.com Tube...
- Page 37 Español ameriwoodhome.com Tube...
- Page 38 Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) - Visitez: www.ameriwoodhome.com ATTENTION Le meuble peut basculer et causer des blessures graves ou la mort.
- Page 39 ameriwoodhome.com Tube...
- Page 40 ameriwoodhome.com Tube...
- Page 41 ameriwoodhome.com Tube...
- Page 42 ameriwoodhome.com Tube...
