Page 1 INVERTER FR-E800 Instruction Manual (Connection) Compact, high functionality inverters FR-E820-0008(0.1K) to 0900(22K) FR-E840-0016(0.4K) to 0440(22K) FR-E820S-0008(0.1K) to 0110(2.2K) FR-E810W-0008(0.1K) to 0050(0.75K) FR-E820-0008(0.1K) to 0900(22K)E FR-E840-0016(0.4K) to 0440(22K)E FR-E820S-0008(0.1K) to 0110(2.2K)E FR-E810W-0008(0.1K) to 0050(0.75K)E FR-E820-0008(0.1K) to 0900(22K)SCE FR-E840-0016(0.4K) to 0440(22K)SCE FR-E820S-0008(0.1K) to 0110(2.2K)SCE FR-E810W-0008(0.1K) to 0050(0.75K)SCE...
Page 2 Safety Instructions ..............4 Chapter 1 Introduction .
Page 3 2.7.5 Wiring of control circuit ................86 2.7.6 Safety stop function (Standard model / Ethernet model) .
Page 4 Motor rating ............. . 160 4.2.1 Mitsubishi Electric high-performance energy-saving motor with encoder SF-PR-SC ......160 4.2.2 Mitsubishi Electric Vector control dedicated motor SF-V5RU .
Page 5 • A person who possesses a certification in regard with electric appliance handling, or person took a proper engineering training. Such training may be available at your local Mitsubishi Electric office. Contact your local sales office for schedules and locations.
Page 6 Electric shock prevention WARNING  Do not remove the front cover or the wiring cover while the power of this product is ON, and do not run this product with the front cover or the wiring cover removed as the exposed high voltage terminals or the charging part of the circuitry can be touched.
Page 7 Injury prevention CAUTION • The voltage applied to each terminal must be as specified in the Instruction Manual. Otherwise an explosion or damage may occur. • The cables must be connected to the correct terminals. Otherwise an explosion or damage may occur. •...
Page 8 Additional instructions The following instructions must be also followed. If this product is handled incorrectly, it may cause unexpected fault, an injury, or an electric shock. CAUTION Transportation and installation • To prevent injury, wear cut-resistant gloves when opening packaging with sharp tools. •...
Page 9 WARNING Usage • Stay away from the equipment after using the retry function in this product as the equipment will restart suddenly after the output shutoff of this product. • Access to the motor is allowed only after it is fully confirmed that the motor does not start running. •...
Page 10 CAUTION Usage • When installing the MC on the output side of the inverter, turn it ON/OFF while both the inverter and motor are at a stop. • The electronic thermal O/L relay function may not be enough for protection of a motor from overheating. It is recommended to install an external thermal relay or a PTC thermistor for overheat protection.
Page 11 CAUTION Emergency stop • A safety backup such as an emergency brake must be provided for devices or equipment in a system to prevent hazardous conditions in case of failure of this product or an external device controlling this product. •...
Page 12 To avoid an electric shock hazard, verify that the voltage on the bus capacitors has discharged before wiring or inspection of the motor. Measure the DC bus voltage between terminals P/+ and N/- or other measurement points to verify zero voltage. (For the measurement points and the capacitor discharge time, refer to the FR-E800 Instruction Manual (Maintenance).) CAUTION •...
Page 13 Application of caution labels Caution labels are used to ensure safety during use of Mitsubishi Electric inverters. Apply the following labels to the inverter if the "retry function" and/or "automatic restart after instantaneous power failure" have been enabled. • For the retry function...
Page 14 CHAPTER 1 Introduction Product checking and accessories .........................15 Component names ..............................18 Operation steps ..............................22 Related manuals..............................25...
Page 15 (FR-PA07) Parameter unit (FR-PU07), LCD operation panel (FR-LU08), and enclosure surface operation panel Parameter unit (FR-PA07) Inverter Mitsubishi Electric inverter FR-E800 series E800 Standard model (RS-485 + SIL2/PLd functional safety) E800-E Ethernet model (Ethernet + SIL2/PLd functional safety)
Page 16 Product checking and accessories Unpack the product and check the rating plate and the capacity plate of the inverter to ensure that the model agrees with the order and the product is intact.  Inverter model 0008 FR-E8 Rating plate Inverter model MODEL :FR-E820-0008-1 INPUT :XXXXX...
Page 17 • F: The output specification for monitoring and the rated frequency are shown for the standard model, and the communication protocol group is shown for the Ethernet model, safety communication model, and IP67 model. The control logic is fixed to the source logic for the safety communication model and IP67 model. Rated Control logic frequency...
Page 18  How to read the SERIAL number The SERIAL consists of two symbols, three characters indicating the production year Rating plate example and month, and six characters indicating the control number. The last two digits of the production year are indicated as the Year, and the Month is Symbol Year Month Control number indicated by 1 to 9, X (October), Y (November), or Z (December).
Page 19 FR-E820S-0080(1.5K) or higher) Instruction Earth plate Connects the option and the inverter for earthing (grounding). Manual of each option Refer to the FR-E800 Instruction Manual (Function). Refer to the FR-E800 Instruction Manual (Maintenance). 1. Introduction 1.2 Component names...
Page 20 FR-E820S-0080(1.5K) or higher) Instruction Earth plate Connects the option and the inverter for earthing (grounding). Manual of each option Refer to the FR-E800 Instruction Manual (Function). Refer to the FR-E800 Instruction Manual (Maintenance). 1. Introduction 1.2 Component names...
Page 21 0040(1.5K)SCE or higher, and FR-E820S-0080(1.5K)SCE or higher) Instruction Earth plate Connects the option and the inverter for earthing (grounding). Manual of each option Refer to the FR-E800 Instruction Manual (Function). Refer to the FR-E800 Instruction Manual (Maintenance). 1. Introduction 1.2 Component names...
Page 22 Not used. If the cap is removed, always reinstall the cap with a hand tool Large resin cap such as a screwdriver. (Tightening torque: 1.5 N·m) Refer to the FR-E800 Instruction Manual (Function). Refer to the FR-E800 Instruction Manual (Maintenance). 1. Introduction...
Page 23 Operation steps  Standard model, Ethernet model, and safety communication model : Initial setting Step of operation Frequency command Installation/mounting Inverter output Wiring of the power frequency supply and motor Time (Hz) Start command Control mode selection Start command via the PU/Ethernet connector of the inverter and plug-in to give a start to give a start...
Page 24 Symbol Overview Refer to page Install the inverter. Perform wiring for the power supply and the motor. Select the control method (V/F control, Advanced magnetic flux vector control, Real sensorless vector control, Instruction Manual Vector control, and PM sensorless vector control). (Function) Instruction Manual Give the start command via communication.
Page 25  IP67 model : Initial setting Step of operation Frequency command Installation/mounting Inverter output Wiring of the power frequency supply and motor Time (Hz) Start command Control mode selection Start command via the Ethernet to give a start to give a start to give a start connector of the inverter (Communication) command?
Page 26 When using this inverter for the first time, prepare the following manuals as required and use the inverter safely. The latest version of e-Manual Viewer and the latest PDF manuals can be downloaded from the Mitsubishi Electric FA Global Website.
Page 27 MEMO 1. Introduction 1.4 Related manuals...
Page 28 CHAPTER 2 Installation and Wiring Peripheral devices ..............................28 Removal and reinstallation of the front cover ......................35 Installation of the inverter and enclosure design ....................41 Terminal connection diagrams..........................51 Main circuit terminals (standard model / Ethernet model / safety communication model)........62 Main circuit terminals (IP67 model) ........................72 Control circuit (standard model / Ethernet model / safety communication model)..........77 Control circuit (IP67 model) ............................95 Connection to a motor with encoder (Vector control) ...................104...
Page 29 Installation and Wiring This chapter explains the installation and the wiring of this product. Always read the instructions before use. Peripheral devices 2.1.1 Inverter and peripheral devices (b) Three-phase AC power supply (a) Inverter (c) Molded case circuit breaker (n) USB power supply (MCCB) or earth leakage USB device current breaker (ELB), fuse...
Page 30 The surrounding air temperature should be as low as possible within the permissible range. This must be noted especially when the inverter is Inverter (FR-E800) installed in an enclosure. Incorrect wiring may lead to damage of the inverter. The control signal lines must be kept fully away from the main circuit lines to protect them from noise.
Page 31 NOTE • To prevent an electric shock, always earth (ground) the motor and inverter. • Do not install a power factor correction capacitor, surge suppressor, or capacitor type filter on the inverter's output side. Doing so will cause the inverter shut off or damage the capacitor or surge suppressor. If any of the above devices is connected, immediately remove it.
Page 32 2.1.2 Peripheral devices (standard model / Ethernet model / safety communication model) Check the model of the inverter you purchased. Appropriate peripheral devices must be selected according to the capacity. Refer to the following table for right selection.  Molded case circuit breaker / earth leakage circuit breaker •...
Page 33 • For the use in the United States or Canada, refer to "Instructions for UL and cUL" in the document enclosed with the product and select appropriate fuses. • When the inverter capacity is larger than the motor capacity, select an MCCB and a magnetic contactor according to the inverter model, and select cables and reactors according to the motor output.
Page 34 NOTE • The matrix shows the magnetic contactor selected according to the standards of Japan Electrical Manufacturers' Association (JEM standards) for AC-1 class. The electrical durability of magnetic contactor is 500,000 times. When the MC is used for emergency stops during motor driving, the electrical durability is 25 times. If using the MC for emergency stop during motor driving, select the MC for the inverter input current according to the rated current against JEM 1038 standards for AC-3 class.
Page 35  Magnetic contactor at the inverter's input line • This is a matrix showing the model name of the Mitsubishi magnetic contactor to be installed at the inverter's input line according to the selected inverter and rating. Without AC reactor With AC reactor Voltage Inverter model...
Page 36 Removal and reinstallation of the front cover  Removal of the front cover • Example of FR-E820-0008(0.1K) Loosen Loosen Loosen Loosen the screw on the front cover. (This screw cannot be removed.) Put a finger on the recess for the screw of the front cover and pull out the cover using its lower side as a support. With the cover removed, the control circuit terminals can be wired and the plug-in option can be installed.
Page 37  Reinstallation of the front cover • Example of FR-E820-0008(0.1K) Rear of the cover Rear of the cover Rear of the cover Tighten Tighten Tighten Hooks Hooks Hooks Hooks Hooks Hooks 本体 Sockets of the wiring cover Sockets of the wiring cover Sockets of the wiring cover Check the position of the hooks on the rear of the cover.
Page 38  Removal of the lower front cover • FR-E820-0240(5.5K) or higher and FR-E840-0230(11K) or higher Loosen Loosen Loosen Loosen the screws on the lower front cover. (These screws cannot be removed.) While holding the areas around the installation hooks on the sides of the lower front cover, pull out the cover using its upper side as a support.
Page 39  Removal of the wiring cover • FR-E820-0050(0.75K) or lower, FR-E820S-0030(0.4K) or lower, FR-E810W-0030(0.4K) or lower Guides Guides Guides Hooks Hooks Hooks Pull out the cover along the guides in the direction shown by the arrow in the figure above. •...
Page 40 • FR-E840-0120(5.5K) and FR-E840-0170(7.5K) Guides Guides Guides Screwdriver Screwdriver Screwdriver Insert a tool such as a flathead screwdriver into the half-hole above the "PUSH" mark on the wiring cover to push the stopper behind the wiring cover approx. 3 mm. Pull out the cover along the guides in the direction shown by the arrow in the figure above.
Page 41 • FR-E820-0080(1.5K) to FR-E820-0175(3.7K), FR-E840-0016(0.4K) to FR-E840-0095(3.7K), FR-E820S-0050(0.75K) or higher, and FR-E810W-0050(0.75K) Hook Hook Hook Guides Guides Guides Fit the cover to the inverter along the guides, and push the hook into the socket. • FR-E820-0240(5.5K) to FR-E820-0600(15K), FR-E840-0230(11K), and FR-E840-0300(15K) Guides Wiring cover Fit the cover to the inverter along the guides.
Page 42 Installation of the inverter and enclosure design 2.3.1 Inverter installation environment The following table lists the standard specifications of the inverter installation environment. Using the inverter in an environment that does not satisfy the conditions deteriorates the performance, shortens the life, and causes a failure. Refer to the following points, and take adequate measures.
Page 43  Humidity Operate the inverter within the ambient air humidity of usually 45 to 90% (up to 95% with circuit board coating). Too high humidity will pose problems of reduced insulation and metal corrosion. On the other hand, too low humidity may cause a spatial electrical breakdown.
Page 44  Countermeasure • Provide the enclosure with rubber vibration isolators. • Strengthen the structure to prevent the enclosure from resonance. • Install the enclosure away from the sources of the vibration. 2.3.2 Amount of heat generated by the inverter (standard model / Ethernet model / safety communication model) ...
Page 45  Installing the heat sink outside the enclosure When the heat sink is installed outside the enclosure, the amount of heat generated by the inverter unit is shown in the following table. Amount of heat generated (W) Ethernet model / Safety communication Standard model model Voltage...
Page 46 2.3.4 Output current reduction when the surrounding air temperature is between 50°C and 60°C (standard model / Ethernet model / safety communication model) When the surrounding air temperature is between 50°C and 60°C, reduce the rated output current as shown in the following table.
Page 47 2.3.5 Output current reduction when the surrounding air temperature is between 40°C and 50°C (IP67 model) When the surrounding air temperature is between 40°C and 50°C, reduce the rated output current as shown in the following table. Output current reduction ratio (%/°C) Output current reduction ratio (%/°C) (carrier frequency: 1 kHz) (carrier frequency: 2 to 14.5 kHz)
Page 48 2.3.7 Standby power consumption by the inverter (IP67 model) The following table shows the standby power consumption during a stop. Standby power consumption (W) Voltage Inverter model Light duty Heavy duty FR-E846-0026(0.75K) 14.2 Three- FR-E846-0040(1.5K) 16.1 phase 400 V FR-E846-0060(2.2K) 17.3 class FR-E846-0095(3.7K)
Page 49 2.3.9 Inverter installation  Inverter placement or higher FR-E820-0008(0.1K) to 0050(0.75K) FR-E820-0080(1.5K) to 0175(3.7K) FR-E820-0240(5.5K) FR-E820S-0008(0.1K) to 0030(0.4K) FR-E840-0016(0.4K) to 0170(7.5K) or higher FR-E840-0230(11K) FR-E810W-0008(0.1K) to 0030(0.4K) FR-E820S-0050(0.75K) to 0110(2.2K) FR-E810W-0050(0.75K) Front cover Front cover Front cover (lower side) Comb-shaped wiring cover Comb-shaped wiring cover Comb-shaped wiring cover or higher...
Page 50 <IP67 model> Clearances (front) Clearances (side) 10 cm or more 1 cm 1 cm 15 cm or more or more or more Allow clearance. Vertical 20 cm or more • When tightening screws into the upper mounting holes, tilt the screwdriver seven to ten degrees (FR-E820-0050(0.75K) or lower, FR-E820S-0030(0.4K) or lower, and FR-E810W-0030(0.4K) or lower).
Page 51  Arrangement of the ventilation fan and inverter Heat generated in the inverter is blown up from the bottom of the unit as warm air by the cooling fan. When installing a ventilation fan for that heat, determine the place of ventilation fan installation after fully considering an air flow. (Air passes through areas of low resistance.
Page 52 Remove the jumper between P1 and P/+ to connect the DC reactor. (Single-phase 100 V power input model is not compatible with the DC reactor.) The function of these terminals can be changed using the Input terminal function selection (Pr.178 to Pr.184). (Refer to the FR-E800 Instruction Manual (Function).) The initial setting varies depending on the specification.
Page 53 Terminal input specifications can be changed by analog input specification switchover (Pr.73, Pr.267). To input voltage, set the voltage/current input selection switch to "V". To input current, set the switch to "I". The initial setting varies depending on the specification. (Refer to the FR-E800 Instruction Manual (Function).)
Page 54 Terminal input specifications can be changed by analog input specification switchover (Pr.73, Pr.267). To input voltage, set the voltage/current input selection switch to "V". To input current, set the switch to "I". The initial setting varies depending on the specification. (Refer to the FR-E800 Instruction Manual (Function).)
Page 55 The function of these terminals can be changed using the Pr.192 ABC terminal function selection. *10 The function of these terminals can be changed using the Output terminal function selection (Pr.190 or Pr.191). (Refer to the FR-E800 Instruction Manual (Function).) *11 Not required when calibrating the scale with the operation panel.
Page 56 Terminal input specifications can be changed by analog input specification switchover (Pr.73, Pr.267). To input voltage, set the voltage/current input selection switch to "V". To input current, set the switch to "I". The initial setting varies depending on the specification. (Refer to the FR-E800 Instruction Manual (Function).)
Page 57 Brake resistor (FR-ABR, MRS, MYS) Install a thermal relay to prevent overheating and damage of brake resistors. (A brake resistor cannot be connected to the FR-E820-0008(0.1K), FR-E820-0015(0.2K), FR-E820S-0008(0.1K), FR-E820S-0015(0.2K), FR-E810W-0008(0.1K), and FR-E810W-0015(0.2K).) (Refer to page 117.) The function of these terminals can be changed using the Pr.192 ABC terminal function selection. *10 On a basic level, the shield of the Ethernet cable should be earthed (grounded) for inverters that have the Ethernet connector with the earth plate.
Page 58 Terminal input specifications can be changed by analog input specification switchover (Pr.73, Pr.267). To input voltage, set the voltage/current input selection switch to "V". To input current, set the switch to "I". The initial setting varies depending on the specification. (Refer to the FR-E800 Instruction Manual (Function).)
Page 59 Brake resistor (FR-ABR, MRS, MYS) Install a thermal relay to prevent overheating and damage of brake resistors. (A brake resistor cannot be connected to the FR-E820-0008(0.1K), FR-E820-0015(0.2K), FR-E820S-0008(0.1K), FR-E820S-0015(0.2K), FR-E810W-0008(0.1K), and FR-E810W-0015(0.2K).) (Refer to page 117.) The function of these terminals can be changed using the Pr.192 ABC terminal function selection. *10 On a basic level, the shield of the Ethernet cable should be earthed (grounded) for inverters that have the Ethernet connector with the earth plate.
Page 60 Terminal input specifications can be changed by analog input specification switchover (Pr.73, Pr.267). To input voltage, set the voltage/current input selection switch to "V". To input current, set the switch to "I". (Refer to the FR-E800 Instruction Manual (Function).) It is recommended to use 2 W 1 kΩ when the frequency setting signal is changed frequently.
Page 61 NOTE • To prevent a malfunction due to noise, keep the signal cables 10 cm or more away from the power cables. Also, keep the cables of the main circuit for input and output separated. • After wiring, wire offcuts must not be left in the inverter. Wire offcuts can cause a fault, failure or malfunction.
Page 62 Option connector option connection The function of these terminals can be changed using the Input terminal function selection (Pr.178, Pr.179). (Refer to the FR-E800 Instruction Manual (Function).) The function of these terminals can be changed using the Output terminal function selection (Pr.192, Pr.197). (Refer to the FR-E800 Instruction Manual (Function).)
Page 63 Main circuit terminals (standard model / Ethernet model / safety communication model) 2.5.1 Details on the main circuit terminals Refer to Terminal symbol Terminal name Terminal function description page AC power input Connect these terminals to the commercial power supply. —...
Page 64 FR-E820-0240(5.5K), 0330(7.5K) FR-E840-0120(5.5K), 0170(7.5K) Jumper R/L1 S/L2 T/L3 R/L1 S/L2 T/L3 P/+ PR Earthing (grounding) Earthing (grounding) terminal terminal Power supply Motor Jumper Earthing (grounding) terminal Power supply Motor FR-E820-0470(11K), 0600(15K) FR-E840-0230(11K), 0300(15K) R/L1 S/L2 T/L3 Jumper R/L1 S/L2 T/L3 P/+ PR Jumper Power supply...
Page 65  Single-phase 200 V class FR-E820S-0008(0.1K) to 0030(0.4K) FR-E820S-0050(0.75K) to 0110(2.2K) Jumper N/- P/+ Jumper R/L1 S/L2 R/L1 S/L2 Earthing (grounding) terminal Power supply Motor Earthing (grounding) terminal Power supply Motor  Single-phase 100 V class FR-E810W-0008(0.1K) to FR-E810W-0030(0.4K) FR-E810W-0050(0.75K) N/- P/+ R/L1 S/L2 R/L1...
Page 66 NOTE • Cut off the same number of lugs as wires. If parts where no wire is put through have been cut off (10 mm or more), protective structure (IEC 60529) becomes an open type (IP00). 2.5.3 Applicable cables and wiring length ...
Page 67 • Three-phase 400 V class (440 V input power supply, without a power factor improving AC or DC reactor) Cable gauge Crimp terminal Applicable Terminal Tightening HIV cables, etc. (mm AWG/MCM PVC cables, etc. (mm inverter model screw torque R/L1, R/L1, Earthing R/L1,...
Page 68 • Single-phase 100 V class (110 V input power supply, with a power factor improving AC reactor) Cable gauge Crimp terminal Applicable Terminal Tightening HIV cables, etc. (mm AWG/MCM PVC cables, etc. (mm inverter model screw torque Earthing Earthing FR-E810W-[] size (N·m) R/L1,...
Page 69 • Three-phase 200 V class (220 V input power supply, with a power factor improving AC or DC reactor) Cable gauge Crimp terminal Applicable Terminal Tightening HIV cables, etc. (mm AWG/MCM PVC cables, etc. (mm inverter model screw torque R/L1, R/L1, Earthing R/L1,...
Page 70 The gauge is 0.75 mm (19 AWG or 18 AWG) for the MM-GKR motor power supply cable (MR-PWS1CBL[]M-A[]-[]). When the wiring length of the power supply cable for the MM-GKR motor exceeds 10 m, extend the cable using the MR-PWS2CBL03M-A_-L and an HIV wire of 1.25 mm (16 AWG).
Page 71 • Refer to page 146 to drive a 400 V class motor by an inverter. • The carrier frequency is limited during Real sensorless vector control and PM sensorless vector control. (Refer to the FR-E800 Instruction Manual (Function).) 2. Installation and Wiring...
Page 72 2.5.4 Earthing (grounding) precautions Always earth (ground) the motor and inverter.  Purpose of earthing (grounding) Generally, an electrical apparatus has an earth (ground) terminal, which must be connected to the ground before use. An electrical circuit is usually insulated by an insulating material and encased. However, it is impossible to manufacture an insulating material that can shut off a leakage current completely, and actually, a slight current flows into the case.
Page 73 Main circuit terminals (IP67 model) 2.6.1 Details on the main circuit terminals Refer to Type Terminal symbol Terminal name Terminal function description page Connect these terminals to the commercial power R/L1, S/L2, T/L3 AC power input — supply. Power supply For earthing (grounding) the inverter chassis.
Page 74 Name Description Power ON/OFF switch Clockwise: ON (|) Counterclockwise: OFF (○) Terminal Terminal Connector (inverter side) Connector (inverter side) symbol symbol M23, 6-pole (male) R/L1 M23, 6-pole (female) S/L1 Main Main circuit circuit connector connector — — for power for motor supply T/L1 —...
Page 75 2.6.3 Applicable cables and wiring length  For the ND rating • Three-phase 400 V class (440 V input power supply, without an AC reactor) Cable gauge Applicable HIV cables, etc. (mm AWG/MCM PVC cables, etc. (mm inverter model Earthing Earthing FR-E846-[] R/L1, S/...
Page 76 • Refer to page 146 to drive a 400 V class motor by an inverter. • The carrier frequency is limited during Real sensorless vector control and PM sensorless vector control. (Refer to the FR-E800 Instruction Manual (Function).) 2. Installation and Wiring...
Page 77 2.6.4 Earthing (grounding) precautions Always earth (ground) the motor and inverter.  Purpose of earthing (grounding) Generally, an electrical apparatus has an earth (ground) terminal, which must be connected to the ground before use. An electrical circuit is usually insulated by an insulating material and encased. However, it is impossible to manufacture an insulating material that can shut off a leakage current completely, and actually, a slight current flows into the case.
Page 78 Set the voltage/current input switch to the "V" position to select voltage input (0 to 5 V / 0 to 10 The terminal function can be selected by Pr.178 to Pr.184 (Input terminal function selection). (Refer to the FR-E800 Instruction Manual (Function).) 2.
Page 79 12 bits The terminal function can be selected by Pr.190 to Pr.192 (Output terminal function selection). (Refer to the FR-E800 Instruction Manual (Function).) The open collector transistor is ON (conductive) in LOW state. The transistor is OFF (not conductive) in HIGH state.
Page 80 Common terminal for terminals RUN and FU. — — common Safety monitor output — Common terminal for terminal SO. — terminal common Refer to the FR-E800 Instruction Manual (Function).  Communication Terminal Refer Type Terminal name Terminal function description symbol to page...
Page 81 (0 to 5 V / 0 to 10 V). The terminal function can be selected by Pr.178 or Pr.179 (Input terminal function selection). (Refer to the FR-E800 Instruction Manual (Function).) Refer to the FR-E800 Instruction Manual (Function).
Page 82 0.1 A (conductive) in LOW state. The transistor is OFF (not (open collector output) (The voltage drop is conductive) in HIGH state.) Refer to the FR-E800 3.4 V at maximum Instruction Manual (Functional Safety) (BCN-A23488- while the signal is ON.) 000) when the signal is switched to HIGH while both terminals S1 and S2 are open.
Page 83 Set the voltage/current input switch to the "V" position to select voltage input (0 to 5 V / 0 to 10 V). Refer to the FR-E800 Instruction Manual (Function). 2. Installation and Wiring 2.7 Control circuit (standard model / Ethernet model / safety communication model)
Page 84 A and C), Normal: continuity across B and VDC 1 A C (discontinuity across A and C) The terminal function can be selected by Pr.192 (Output terminal function selection). (Refer to the FR-E800 Instruction Manual (Function).) Refer to the FR-E800 Instruction Manual (Function).  Safety input/output signal...
Page 85  Communication Terminal Refer Type Terminal name Terminal function description symbol to page Communication can be made via Ethernet. Category: 100BASE-TX/10BASE-T Transmission method: Baseband Data transmission speed: 100 Mbps (100BASE-TX) / 10 Mbps (10BASE-T) Ethernet connector (2 Maximum segment length: 100 m between the hub and the inverter —...
Page 86 • In the source logic, a signal turns ON when a current enters into the corresponding signal input terminal. Terminal PC is common to the contact input signals. Terminal SE is common to the open collector output signals. Current flow concerning the input/output signal Current flow concerning the input/output signal when sink logic is selected when source logic is selected...
Page 87 2.7.5 Wiring of control circuit  Control circuit terminal layout  Standard model (FM type inverter) • Recommended cable gauge: 0.3 to 0.75 mm S1 S2 PC RUN FU SE MRS RES SD STF RL RM RH SD SO SOC ...
Page 88  Ethernet model • Recommended cable gauge: 0.3 to 0.75 mm S1 S2 PC DI0 DI1 SD SO SOC  Safety communication model • Recommended cable gauge: 0.3 to 0.75 mm SX1 SX2 PC SD  Wiring method  Wiring connection Use crimp terminals and stripped wire for the control circuit wiring.
Page 89 Crimp the terminals on the wire. Insert the wire into a crimp terminal, making sure that 0 to 0.5 mm of the wire protrudes from the end of the sleeve. Check the condition of the crimp terminals after crimping. Do not use the crimp terminals of which the crimping is inappropriate, or the face is damaged.
Page 90  Wire removal Pull the wire while pushing the open/close button all the way down firmly with a flathead screwdriver. Open/close button Flathead screwdriver NOTE • Pulling out the wire forcefully without pushing the open/close button all the way down may damage the terminal block. •...
Page 91 • Terminal 5 is a common terminal for the frequency setting terminal (2 or 4) and the analog output terminals (AM ). It should be protected from external noise using a shielded or twisted cable. • Terminal SE is a common terminal for the open collector output terminals (RUN and FU). The contact input circuit is isolated from the internal control circuit by photocoupler.
Page 92 SO cannot be used to input a safety stop signal to other devices.  Connection diagram To prevent restart at fault occurrence, connect terminals SO and SOC to the reset button, which are the feedback input terminals of the safety relay module. ∗1 FR-E800(-E) R/L1 S/L2 T/L3 Logic IGBTs Gate...
Page 93 SAFE2 *10 The use of the SAFE signal and SAFE2 signal has not been certified for compliance with safety standards. For details, refer to the FR-E800 Instruction Manual (Functional Safety). 2. Installation and Wiring 2.7 Control circuit (standard model / Ethernet model / safety communication model)
Page 94 This function is not available for the standard model and the Ethernet model.  Outline Mitsubishi Electric FR-E800-SCE general-purpose inverters have safety functions to stop the output to motors. By connecting the inverter with a safety programmable controller with an Ethernet cable, signal input via communication is enabled.
Page 95 SAFE2 The use of the SAFE signal and SAFE2 signal has not been certified for compliance with safety standards. For details, refer to the FR-E800-SCE Instruction Manual (Functional Safety). 2. Installation and Wiring 2.7 Control circuit (standard model / Ethernet model / safety communication model)
Page 96 Before the operation is switched, a reset is performed in the inverter. The terminal function can be selected by Pr.178 or Pr.179 (Input terminal function selection). (Refer to the FR-E800 Instruction Manual (Function).) Refer to the FR-E800 Instruction Manual (Function).
Page 97 ON.) less than the preset detection frequency. The terminal function can be selected by Pr.190 to Pr.192, and Pr.197 (Output terminal function selection). (Refer to the FR-E800 Instruction Manual (Function).) The open collector transistor is ON (conductive) in LOW state. The transistor is OFF (not conductive) in HIGH state.
Page 98  Communication Terminal Refer Type Terminal name Terminal function description symbol to page Communication can be made via Ethernet. Category: 100BASE-TX/10BASE-T Transmission method: Baseband Data transmission speed: 100 Mbps (100BASE-TX) / 10 Mbps (10BASE-T) Ethernet connector (2 Maximum segment length: 100 m between the hub and the inverter —...
Page 99 Terminal Terminal Symbol Connector (inverter side) Symbol Connector (inverter side) symbol symbol M12, 5-pole (female) M12, 5-pole (female) DI0/DI1 DO0/DO1 M12, 5-pole (male) M12, 5-pole (female) +24V +24V AI0/AI1 M12, 4-pole (female) M12, 4-pole (female) M12, 4-pole (female) M12, 4-pole (female) 2.
Page 100  Wiring method • Prepare cables with suitable connectors for the control circuit terminals on the inverter. To meet the UL/cUL standards, purchase cables shown in the following table. Manufacturer: Tyco Electronics Cable type Cable length Model 1-2421478-1 10 m Unshielded 2-2421478-1 15 m...
Page 101 • To suppress EMI, use shielded or twisted cables for the control circuit terminals and run them away from the main and power circuits (including the 200 V relay sequence circuit). For the cables connected to the control circuit terminals, connect their shields to the common terminal of the connected control circuit terminal.
Page 102 Safety communication function  Outline Mitsubishi Electric FR-E806 general-purpose inverters have safety functions to stop the output to motors. By connecting the inverter with a safety programmable controller with an Ethernet cable, signal input via communication is enabled.  Wiring Terminals (physical terminals) related to safety sub-functions are not provided.
Page 103  Connection diagram FR-E806 R/L1 S/L2 T/L3 Ethernet Ethernet connector connector IGBTs Gate Driver Emergency CPU stop button Gate Driver Safety programmable controller U V W To avoid an electric shock hazard during wiring or inspection, install a magnetic contactor (MC) at the input side of the inverter. ...
Page 104 Negative logic SAFE SAFE2 The use of the SAFE signal and SAFE2 signal has not been certified for compliance with safety standards. For details, refer to the FR-E800-SCE Instruction Manual (Functional Safety). 2. Installation and Wiring 2.8 Control circuit (IP67 model)
Page 105 Connection to a motor with encoder (Vector control) Using encoder-equipped motors together with a Vector control compatible option (FR-A8AP E kit) enables orientation control, encoder feedback control, and speed, torque, and position control operations under full-scale vector control. Plug-in options are not available for the IP67 model.
Page 106 (SW3) selection switches (SW1) specification Mitsubishi Electric high- performance energy-saving motor SF-PR-SC Complementary 12 to 24 V with encoder Mitsubishi Electric Vector control SF-V5RU Complementary 12 V dedicated motor Mitsubishi Electric inverter-driven GM-DZ geared motor for encoder feedback Differential...
Page 107 H level: 2.4 V or more, Output voltage L level: 3 V or less L level: 0.5 V or less  Encoder cable  SF-PR-SC/SF-V5RU with encoder FR-E800 (FR-A8AP) Positioning keyway F-DPEVSB 12P 0.2 mm D/MS3057-12A Approx. 140 mm Earth cable...
Page 108  GM-DZ/GM-DP/SF-JR/SF-HR/SF-JRCA/SF-HRCA with encoder FR-E800 F-DPEVSB 12P 0.2 mm D/MS3057-12A (FR-A8AP) Approx. 140 mm Earth cable 60 mm Positioning keyway D/MS3106B20-29S D/MS3106B20-29S (As viewed from wiring side) 2 mm Model Length L (m) FR-JCBL5 FR-JCBL15 FR-JCBL30 • When using an encoder cable (FR-JCBL, FR-V5CBL, etc.) dedicated to the conventional motor, the cables need to be treated as the terminal block of the FR-A8AP is an insertion type.
Page 109 • Connection terminal compatibility table GM-DZ, GM-DP, SF-JR, SF-HR, SF-JRCA, Motor SF-PR-SC, SF-V5RU SF-HRCA (with encoder) Encoder cable FR-V7CBL FR-JCBL Do not connect anything to this. Do not connect anything to this. FR-A8AP terminal Do not connect anything to this. ...
Page 110 To use a terminal as terminal OH, assign the OH (External thermal relay input) signal to an input terminal. (Set "7" in any of Pr.178 to Pr.184. For details, refer to the FR-E800 Instruction Manual (Function).) When OH signal is assigned to terminal RH (Pr.182 = “7”)
Page 111 To protect the cables from noise, run them away from any source of noise (such as the main circuit and power supply voltage). Example of parallel connection with two cables (with complementary encoder output) FR-E800 (FR-A8AP) Encoder 2 mm Wiring length...
Page 112 Communication can be performed with the Mitsubishi inverter protocol (computer link operation) or the MODBUS RTU protocol. For details, refer to the FR-E800 Instruction Manual (Communication). 2. Installation and Wiring 2.10 Communication connectors and terminals...
Page 113 2.10.2 Ethernet connector (Ethernet model / Safety communication model)  Ethernet communication specifications Item Description Category 100BASE-TX/10BASE-T Data transmission speed 100 Mbps (100BASE-TX) / 10 Mbps (10BASE-T) Transmission method Baseband Maximum segment length 100 m between the hub and the inverter Number of cascade connection Up to 2 (100BASE-TX) / up to 4 (10BASE-T) stages...
Page 114 FA or other computer by a communication cable, a user program can run to monitor the inverter or read and write parameters. For details, refer to the FR-E800 Instruction Manual (Communication). 2. Installation and Wiring...
Page 115 2.10.3 Ethernet connector (IP67 model)  Ethernet communication specifications Item Description Category 100BASE-TX/10BASE-T Data transmission speed 100 Mbps (100BASE-TX) / 10 Mbps (10BASE-T) Transmission method Baseband Maximum segment length 100 m between the hub and the inverter Number of cascade connection Up to 2 (100BASE-TX) / up to 4 (10BASE-T) stages Topology...
Page 116 FA or other computer by a communication cable, a user program can run to monitor the inverter or read and write parameters. For details, refer to the FR-E800 Instruction Manual (Communication). 2.10.4 USB connector ...
Page 117 — NOTE • Availability of each parameter depends on the inverter model. For details, refer to the FR-E800 Instruction Manual (Function). • Note that Ethernet communication may be disabled in the Ethernet model, safety communication model, or IP67 model when turning OFF and turning ON the power supply is repeated while Ethernet communication and USB bus power connection are used at the same time.
Page 118 2.11 Connection of stand-alone option units (standard model, Ethernet model, and safety communication model) The inverter accepts a variety of stand-alone option units as required. Incorrect connection will cause inverter damage or accident. Connect and operate the option unit carefully in accordance with the Instruction Manual of the corresponding option unit.
Page 119 FR-E820-0240(5.5K), FR-E820-0330(7.5K) FR-E840-0120(5.5K) and FR-E840-0170(7.5K) Connect a brake resistor across terminals P/+ and PR. Connect a brake resistor across terminals P/+ and PR. Jumper Terminal P/+ Terminal P/+ Terminal PR Jumper Brake resistor Terminal PR Brake resistor FR-E820-0470(11K), FR-E820-0600(15K) FR-E840-0230(11K), FR-E840-0300(15K) Connect a brake resistor across terminals P/+ and PR.
Page 120 110 VDC: 0.2 A, 220 VDC: 0.1 A (DC13 MYS220W50 TH-T25-5A class) (two in parallel) Thermal relay Power High-duty brake model supply Rated operating current resistor (Mitsubishi electric voltage product) FR-ABR-0.4K TH-T25-0.7A FR-ABR-0.75K TH-T25-1.3A FR-ABR-2.2K TH-T25-2.1A FR-ABR-3.7K TH-T25-3.6A 100/200 V FR-ABR-5.5K...
Page 121 • Set Pr.70 Special regenerative brake duty according to the amount and frequency of the regenerative driving, and make sure that the resistor can consume the regenerative power properly. (Refer to the FR-E800 Instruction Manual (Function).) 2. Installation and Wiring...
Page 122 • When the regenerative brake transistor is damaged, install a thermal relay as shown in the following sequence to prevent overheat and burnout of the brake resistor. Properly select a thermal relay according to the regenerative driving frequency or the rated power or resistance of the brake resistor. <Example 1>...
Page 123 NOTE • Set "1" in Pr.0 Brake mode selection in the FR-BU2 to use a GRZG type discharging resistor. • Do not remove the jumper across terminals P/+ and P1 except when connecting a DC reactor (FR-HEL).  Connection example with the FR-BR(-H) resistor unit ∗2 FR-BR MCCB...
Page 124 Do not install an MCCB across terminals P/+ and N/- (between terminals P and P/+ or between terminals N and N/-). Connecting the opposite polarity of terminals N/- and P/+ will damage the inverter. Use Pr.178 to Pr.182 (Input terminal function selection) to assign the terminals used for the X10 and RES signals. (Refer to the FR-E800 Instruction Manual (Function).) Always connect terminal RDY on the FR-HC2 to a terminal where the X10 signal or MRS signal is assigned on the inverter.
Page 125 "0 (initial value) or 100" or "2 or 102" (when the automatic restart after instantaneous power failure is selected) in Pr.30 Regenerative function selection, and set "0" in Pr.70 Special regenerative brake duty. (Refer to the FR-E800 Instruction Manual (Function).) ...
Page 126 Do not install an MCCB across terminals P/+ and N/- (between terminals P/L+ and P/+ or between N/L- and N/-). Connecting the opposite polarity of terminals N/- and P/+ will damage the inverter. Use Pr.178 to Pr.182 (Input terminal function selection) to assign the terminals used for the X10 signal. (Refer to the FR-E800 Instruction Manual (Function).) Be sure to connect the power supply and terminals R/L11, S/L21, and T/MC1.
Page 127 2.11.6 Connection of the AC reactor (FR-HAL) • Keep the surrounding air temperature within the permissible range (-10°C to +50°C). Keep enough clearance around the reactor because it heats up. (Take 10 cm or more clearance on top and bottom and 5 cm or more on left and right regardless of the installation direction.) 10 cm or more...
Page 128 2.11.7 Connection of the DC reactor (FR-HEL) • Keep the surrounding air temperature within the permissible range (-10°C to +50°C). Keep enough clearance around the reactor because it heats up. (Take 10 cm or more clearance on top and bottom and 5 cm or more on left and right regardless of the installation direction.) 10 cm or more 5 cm or...
Page 129 • Set Pr.70 Special regenerative brake duty according to the amount and frequency of the regenerative driving, and make sure that the resistor can consume the regenerative power properly. (Refer to the FR-E800 Instruction Manual (Function).) • When the regenerative brake transistor is damaged, install a thermal relay as shown in the following sequence to prevent overheat and burnout of the brake resistor.
Page 130 CAUTION • If the resistor selection is incorrect, overcurrent may damage the inverter built-in brake transistor. Besides, the resistor may be burned due to overheat. • If the selection of the thermal relay is incorrect, the resistor may be burned due to overheat. 2.12.2 Connection of the brake unit (FR-BU2) Connect the brake unit (FR-BU2(-H)) as follows to improve the braking capability during deceleration.
Page 131  Connection example with the FR-BR-(H) resistor unit FR-BR MCCB Motor R/L1 Three phase AC S/L2 power supply T/L3 FR-BU2 Inverter 10 m or less When wiring, make sure to match the terminal symbols (P/+, N/-) on the inverter and on the brake unit (FR-BU2). (Incorrect connection will damage the inverter and brake unit.) Install a stepdown transformer.
Page 132 2.12.3 Connection of the AC reactor (FR-HAL) • Connect the option using the main circuit connector for power supply of the inverter. Use a connector cable, referring to page 72 for the connector specifications and terminals layout. • Keep the surrounding air temperature within the permissible range (-10°C to +50°C). Keep enough clearance around the reactor because it heats up.
Page 133 MEMO 2. Installation and Wiring 2.12 Connection of stand-alone option units (IP67 model)
Page 134 CHAPTER 3 Precautions for Use of the Inverter Electro-magnetic interference (EMI) and leakage currents ..................134 Power supply harmonics............................139 Installation of a reactor ............................143 Power shutdown and magnetic contactor (MC)....................144 Countermeasures against deterioration of the 400 V class motor insulation............146 Checklist before starting operation ........................147 Failsafe system which uses the inverter .......................150...
Page 135 Precautions for Use of the Inverter This chapter explains the precautions for use of this product. Always read the instructions before use. Electro-magnetic interference (EMI) and leakage currents 3.1.1 Leakage currents and countermeasures Capacitance exists between the inverter I/O cables, other cables and earth and in the motor, through which a leakage current flows.
Page 136 MCCB Thermal relay Motor Power Inverter supply Line-to-line static capacitance Line-to-line leakage currents path  Precautions • Use Pr.9 Electronic thermal O/L relay. • If the carrier frequency setting is high, decrease the Pr.72 PWM frequency selection setting. Note that motor noise increases. Selecting Pr.240 Soft-PWM operation selection makes the sound inoffensive. To ensure that the motor is protected against line-to-line leakage currents, it is recommended to use a temperature sensor to directly detect motor temperature.
Page 137 NOTE • Install the earth leakage circuit breaker (ELB) on the input side of the inverter. • In the connection earthed-neutral system, the sensitivity current is less responsive to a ground fault on the inverter output side. Earthing (Grounding) must conform to the requirements of national and local safety regulations and electrical codes. (NEC section 250, IEC 61140 class 1 and other applicable standards) •...
Page 138  EMI measures to reduce electromagnetic noises that are radiated by the inverter to cause the peripheral devices to malfunction Inverter-generated noises are largely classified into those radiated by the inverter itself and by the I/O cables connected to its main circuit, those electromagnetically and electrostatically induced to the signal cables of the peripheral devices close to the power cable connected to the inverter main circuit, and those transmitted through the power cables.
Page 139 • Specification example (ZCAT3035-1330 by TDK) Item Description 10 to 100 MHz Impedance (Ω) 100 to 500 MHz 39 1 Cable fixing band mount 34 1 Outline dimension drawings (mm) Product name Lot number The impedance values above are reference values, and not guaranteed values. ...
Page 140 Power supply harmonics 3.2.1 Power supply harmonics The inverter may generate power supply harmonics from its converter circuit to affect the power generator, power factor correction capacitor etc. Power supply harmonics are different from noise and leakage currents in source, frequency band and transmission path.
Page 141 The three-phase 200 V input specifications 3.7 kW or lower (or single-phase 200 V input specifications 2.2 kW or lower and single-phase 100 V input specifications 0.75 kW or lower) were previously covered by the Harmonic Suppression Guidelines for Household Appliances and General-purpose Products and other models were covered by the Harmonic Suppression Guidelines for Consumers Who Receive High Voltage or Special High Voltage.
Page 142  Equivalent capacity limit Received power voltage Reference capacity 6.6 kV 50 kVA 22/33 kV 300 kVA 66 kV or more 2000 kVA  Harmonic content (when the fundamental current is considered as 100%) Reactor 11th 13th 17th 19th 23rd 25th Not used Used (AC side)
Page 143 A DC reactor (FR-HEL) cannot be connected to the single-phase 100 V power input models and the IP67 model. The safety communication model (FR-E800-SCE) and the IP67 model (FR-E806) are not intended for the use with the high power factor converter (FR-HC2) or multifunction regeneration converter (FR-XC in common bus regeneration mode).
Page 144 Installation of a reactor When the inverter is connected near a large-capacity power transformer (500 kVA or more) or when a power factor correction capacitor is to be switched over, an excessive peak current may flow in the power input circuit, damaging the converter circuit. To prevent this, always install an AC reactor (FR-HAL), which is available as an option.
Page 145 Power shutdown and magnetic contactor (MC)  Inverter input side magnetic contactor (MC) On the inverter input side, it is recommended to provide an MC for the following purposes. (Refer to page 31 for selection.) • To disconnect the inverter from the power supply at activation of a protective function or at malfunctioning of the driving system (emergency stop, etc.).
Page 146 NOTE • Before wiring or inspection for a PM motor, confirm that the PM motor is stopped. In an application, such as fan and blower, where the motor is driven by the load, a low-voltage manual contactor must be connected at the inverter's output side, and wiring and inspection must be performed while the contactor is open.
Page 147 Countermeasures against deterioration of the 400 V class motor insulation In the PWM type inverter, a surge voltage attributable to wiring constants is generated at the motor terminals. Especially in a 400 V class motor, the surge voltage may deteriorate the insulation. When the 400 V class motor is driven by the inverter, consider the following countermeasures: ...
Page 148 Checklist before starting operation The FR-E800 series inverter is a highly reliable product, but incorrect peripheral circuit making or operation/handling method may shorten the product life or damage the product. Before starting operation, always recheck the following points. Refer to...
Page 149 Refer to Check by Checkpoint Countermeasure page user When using a switching circuit as shown below, chattering due to misconfigured sequence or arc generated at switching may allow undesirable current to flow in and damage the inverter. Miswiring may also damage the inverter. (Note that a PM motor cannot be driven by the commercial power supply.) When using the electronic bypass Interlock...
Page 150 Refer to Check by Checkpoint Countermeasure page user When a motor is driven by the inverter, axial voltage is generated on the motor shaft, which may cause electrical corrosion of the bearing in rare cases depending on the wiring, load, operating conditions of the motor or specific Countermeasures are taken inverter settings (high carrier frequency).
Page 151  Interlock method which uses the inverter status output signals By combining the inverter output signals to provide an interlock as shown below, an inverter failure can be detected. (For details of each signal, refer to the FR-E800 Instruction Manual (Function).) Interlock method...
Page 152  Checking the inverter operating status by using the start signal input to the inverter and the Inverter running signal output from the inverter ... (c) The Inverter running (RUN2) signal is output when the inverter is running. Check if the RUN2 signal is output while a start signal (the STF/STR signal for forward/reverse rotation command) is input to the inverter.
Page 153  Backup method which does not use the inverter Even if the interlock is provided by the inverter status signal, enough failsafe is not ensured depending on the failure status of the inverter itself. For example, if an inverter CPU fails in a system interlocked with the inverter's Fault, start, and RUN signals, no Fault signals will be output and the RUN signal will be kept ON because the inverter CPU is down.
Page 154 CHAPTER 4 Specifications Inverter rating................................154 Motor rating................................160 Common specifications............................172 Outline dimension drawings..........................175...
Page 155 The applicable motor capacity indicated is the maximum capacity applicable for use of the Mitsubishi Electric standard 4-pole motor. To drive a Mitsubishi Electric high-performance energy-saving motor, use the 0.75K inverter for a 1.1 kW motor, or 2.2K inverter for a 3 kW motor.
Page 156 · Powering ON produces up to four times as large current as the inverter rated current. Prepare a DC power supply resistant to the inrush current at power ON, although an inrush current limit circuit is provided in the FR-E800 series inverter.
Page 157 11.0 11.0 The applicable motor capacity indicated is the maximum capacity applicable for use of the Mitsubishi Electric standard 4-pole motor. To drive a Mitsubishi Electric high-performance energy-saving motor, use the 2.2K inverter for a 3 kW motor. The rated output capacity is the value with respect to 440 V output voltage.
Page 158 Forced air Approx. mass (kg) The applicable motor capacity indicated is the maximum capacity applicable for use of the Mitsubishi Electric standard 4-pole motor. The rated output capacity is the value with respect to 230 V output voltage. The percentage of the overload current rating is the ratio of the overload current to the inverter's rated output current. For repeated duty, allow time for the inverter and motor to return to or below the temperatures under 100% load.
Page 159 Natural Approx. mass (kg) The applicable motor capacity indicated is the maximum capacity applicable for use of the Mitsubishi Electric standard 4-pole motor. The rated output capacity is the value with respect to 230 V output voltage. The percentage of the overload current rating is the ratio of the overload current to the inverter's rated output current. For repeated duty, allow time for the inverter and motor to return to or below the temperatures under 100% load.
Page 160 The applicable motor capacity indicated is the maximum capacity applicable for use of the Mitsubishi Electric standard 4-pole motor. To drive a Mitsubishi Electric high-performance energy-saving motor, use the 2.2K inverter for a 3 kW motor. The rated output capacity is the value with respect to 440 V output voltage.
Page 161 Motor rating 4.2.1 Mitsubishi Electric high-performance energy- saving motor with encoder SF-PR-SC  Motor specifications (SF-PR-SC)  200 V class SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- Motor model SC-11K- SC-15K- SC-18K- SC-22K- SC-30K- SC-1K-4P SC-2K-4P SC-3K-4P...
Page 162  400 V class SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- SF-PR- Motor model SC-1K- SC-2K- SC-3K- SC-5K- SC-7K- SC-11K- SC-15K- SC-18K- SC-22K- SC-30K- FR-E840- Applicable inverter model (ND FR-E840- FR-E840- FR-E840- FR-E840- FR-E840- FR-E840- FR-E840- FR-E840- FR-E840- 22K (LD 1.5K 2.2K...
Page 163 4.2.2 Mitsubishi Electric Vector control dedicated motor SF-V5RU  Motor specifications (SF-V5RU)  200 V class Motor model: SF-V5RU[]K Applicable inverter model: 18.5 FR-E820-[]K (ND rating) Rated output power (kW) 18.5 Rated current (A) 11.5 17.6 28.5 37.5 72.8 Rated torque (N·m) 9.55...
Page 164 Power (current) at 50/60 Hz. Since a brake motor has a window for gap check, the protection rating of both the cooling fan section and brake section of the motor is IP20. The letter S in IP23S is an additional code indicating that a cooling fan was checked for water protection while it is stationary. The value shown is applicable to the motor at high carrier frequency (Pr.72 = 6 and Pr.240 = 0).
Page 165 4.2.3 PM motor MM-GKR  Motor specifications C D E F • A: Rated output power Symbol Rated output power (kW) 0.75 Electromagnetic brake equipped model is not applicable. • B: Rated speed Symbol Rated speed (r/min) 3000 • C: Electromagnetic brake Symbol Electromagnetic brake...
Page 166  Motor specifications (standard) Motor model MM-GKR13 MM-GKR23 MM-GKR43 MM-GKR73 FR-E820(S)-0.1K FR-E820(S)-0.2K FR-E820(S)-0.4K FR-E820(S)-0.75K Applicable inverter model FR-E810W-0.1K FR-E810W-0.2K FR-E810W-0.4K FR-E810W-0.75K Power supply capacity (kVA) Rated output power 0.75 Continuous (kW) characteristics 0.32 0.64 Rated torque (N·m) Maximum torque (N·m) 0.64 4.84 3000...
Page 167 *10 By setting Pr.80, a motor with one rank lower capacity than the inverter capacity can be used. To use such a motor, set Pr.80 Motor capacity before performing PM parameter initialization. (Refer to the FR-E800 Instruction Manual (Function).)  Electromagnetic brake motor specifications...
Page 168 The manual release is not available. Apply 24 VDC power to release the electromagnetic brake electrically. Separate power source for the electromagnetic brake. The brake gap cannot be adjusted though it widens as the brake lining wears with each braking. The life expectancy of brake therefore refers to a period of time during which the brake can be used without adjustment.
Page 169  Motor torque characteristic MM-GKR13 MM-GKR23 to 73 Torque Torque 200% 200% Short time operation range(3s) Short time operation range(3s) 100% 100% Continuous Continuous operation range operation range 750r/min 3000r/min 3000r/min Motor rotation speed Motor rotation speed • When the input voltage is low, the torque may be reduced. •...
Page 170 By setting Pr.80, a motor with one rank lower capacity than the inverter capacity can be used. To use such a motor, set Pr.80 Motor capacity before performing PM parameter initialization. (Refer to the FR-E800 Instruction Manual (Function).) To drive a machine that produces unbalanced torque, such as a lift axis, the unbalanced torque is recommended to be equal to or less than the 90% of the rated torque (or to be equal to or less than the rated torque for 0.75 kW).
Page 171 By setting Pr.80, a motor with one rank lower capacity than the inverter capacity can be used. To use such a motor, set Pr.80 Motor capacity before performing PM parameter initialization. (Refer to the FR-E800 Instruction Manual (Function).) To drive a machine that produces unbalanced torque, such as a lift axis, the unbalanced torque is recommended to be equal to or less than the 90% of the rated torque.
Page 172  Motor torque Torque Short time operation range(3s) 200% 150% Continuous operation range 100% 3000 4000 Motor rotation speed(r/min) • When the input voltage is low, the torque may be reduced. • The continuous operation torque is 90% at 10 r/min or less (for 1.5 kW or higher EM-A motor). •...
Page 173 Common specifications Control method Soft-PWM control / High carrier frequency PWM control Selectable among V/F control, Advanced magnetic flux vector control, Real sensorless vector control, Induction motor and Vector control PM motor PM sensorless vector control 0.2 to 590 Hz (The upper-limit frequency is 400 Hz under Advanced magnetic flux vector control, Real Induction Output motor...
Page 174 Analog input Terminals 2 and 4: 0 to 10 V / 0 to 5 V / 4 to 20 mA (0 to 20 mA) Frequency Input using the operation panel. setting Input of four-digit BCD (binary-coded decimal) or 16-bit binary (when the option FR-A8AX E kit is Digital input signal installed...
Page 175 Available for the three-phase power input model. Activated in the IP67 model only. Not activated in the inverter in the initial state. Applicable to conditions for a short time, for example, in transit. *10 For the installation at an altitude above 1000 m, consider a 3% reduction in the rated current per 500 m increase in altitude. 4.
Page 176 Outline dimension drawings The standard model has a setting dial on the operation panel. The Ethernet model and the safety communication model have UP and DOWN keys on the operation panel. 4.4.1 Inverter outline dimension drawings (Standard model) FR-E820-0008(0.1K), FR-E820-0015(0.2K), FR-E820-0030(0.4K), FR-E820-0050(0.75K) FR-E820S-0008(0.1K), FR-E820S-0015(0.2K), FR-E820S-0030(0.4K) FR-E810W-0008(0.1K), FR-E810W-0015(0.2K), FR-E810W-0030(0.4K) Inverter model...
Page 177 FR-E820-0080(1.5K), FR-E820-0110(2.2K) FR-E840-0016(0.4K), FR-E840-0026(0.75K), FR-E840-0040(1.5K) FR-E820S-0050(0.75K), FR-E820S-0080(1.5K) Inverter model FR-E820-0080(1.5K) 135.5 FR-E820-0110(2.2K) FR-E840-0016(0.4K) 129.5 FR-E840-0026(0.75K) FR-E840-0040(1.5K) FR-E820S-0050(0.75K) 45.5 FR-E820S-0080(1.5K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 178 FR-E810W-0050(0.75K) Inverter model FR-E810W-0050(0.75K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 179 FR-E820-0175(3.7K) FR-E820S-0110(2.2K) Inverter model FR-E820-0175(3.7K) 142.5 52.5 FR-E820S-0110(2.2K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 180 FR-E840-0060(2.2K), FR-E840-0095(3.7K) Inverter model FR-E840-0060(2.2K) 43.5 FR-E840-0095(3.7K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 181 FR-E820-0240(5.5K), FR-E820-0330(7.5K) Inverter model FR-E820-0240(5.5K) 71.5 FR-E820-0330(7.5K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 182 FR-E840-0120(5.5K), FR-E840-0170(7.5K) ５６（６） Inverter model FR-E840-0120(5.5K) FR-E840-0170(7.5K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 183 FR-E820-0470(11K), FR-E820-0600(15K) FR-E840-0230(11K), FR-E840-0300(15K) 10.6 12.5 (12.5) Inverter model FR-E820-0470(11K) FR-E820-0600(15K) 84.7 FR-E840-0230(11K) FR-E840-0300(15K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 184 FR-E820-0760(18.5K), FR-E820-0900(22K) FR-E840-0380(18.5K), FR-E840-0440(22K) (10) Inverter model FR-E820-0760(18.5K) FR-E820-0900(22K) 84.7 FR-E840-0380(18.5K) FR-E840-0440(22K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 185 4.4.2 Inverter outline dimension drawings (Ethernet model / Safety communication model) FR-E820-0008(0.1K)E, FR-E820-0015(0.2K)E, FR-E820-0030(0.4K)E, FR-E820-0050(0.75K)E FR-E820S-0008(0.1K)E, FR-E820S-0015(0.2K)E, FR-E820S-0030(0.4K)E FR-E810W-0008(0.1K)E, FR-E810W-0015(0.2K)E, FR-E810W-0030(0.4K)E FR-E820-0008(0.1K)SCE, FR-E820-0015(0.2K)SCE, FR-E820-0030(0.4K)SCE, FR-E820-0050(0.75K)SCE FR-E820S-0008(0.1K)SCE, FR-E820S-0015(0.2K)SCE, FR-E820S-0030(0.4K)SCE FR-E810W-0008(0.1K)SCE, FR-E810W-0015(0.2K)SCE, FR-E810W-0030(0.4K)SCE Inverter model FR-E820-0008(0.1K)E FR-E820-0015(0.2K)E 80.5 FR-E820-0008(0.1K)SCE FR-E820-0015(0.2K)SCE FR-E820-0030(0.4K)E 112.5 FR-E820-0030(0.4K)SCE FR-E820-0050(0.75K)E 132.5...
Page 186 FR-E820-0080(1.5K)E, FR-E820-0110(2.2K)E FR-E840-0016(0.4K)E, FR-E840-0026(0.75K)E, FR-E840-0040(1.5K)E FR-E820S-0050(0.75K)E, FR-E820S-0080(1.5K)E FR-E820-0080(1.5K)SCE, FR-E820-0110(2.2K)SCE FR-E840-0016(0.4K)SCE, FR-E840-0026(0.75K)SCE, FR-E840-0040(1.5K)SCE FR-E820S-0050(0.75K)SCE, FR-E820S-0080(1.5K)SCE Inverter model FR-E820-0080(1.5K)E FR-E820-0110(2.2K)E 135.5 FR-E820-0080(1.5K)SCE FR-E820-0110(2.2K)SCE FR-E840-0016(0.4K)E FR-E840-0026(0.75K)E 129.5 FR-E840-0016(0.4K)SCE FR-E840-0026(0.75K)SCE FR-E840-0040(1.5K)E FR-E840-0040(1.5K)SCE FR-E820S-0050(0.75K)E 45.5 FR-E820S-0050(0.75K)SCE FR-E820S-0080(1.5K)E FR-E820S-0080(1.5K)SCE (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 187 FR-E810W-0050(0.75K)E FR-E810W-0050(0.75K)SCE Inverter model FR-E810W-0050(0.75K)E FR-E810W-0050(0.75K)SCE (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 188 FR-E820-0175(3.7K)E FR-E820S-0110(2.2K)E FR-E820-0175(3.7K)SCE FR-E820S-0110(2.2K)SCE Inverter model FR-E820-0175(3.7K)E FR-E820-0175(3.7K)SCE 142.5 52.5 FR-E820S-0110(2.2K)E FR-E820S-0110(2.2K)SCE (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 189 FR-E840-0060(2.2K)E, FR-E840-0095(3.7K)SCE FR-E840-0060(2.2K)SCE, FR-E840-0095(3.7K)SCE Inverter model FR-E840-0060(2.2K)E FR-E840-0095(3.7K)E 43.5 FR-E840-0060(2.2K)SCE FR-E840-0095(3.7K)SCE (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 190 FR-E820-0240(5.5K)E, FR-E820-0330(7.5K)E FR-E820-0240(5.5K)SCE, FR-E820-0330(7.5K)SCE Inverter model FR-E820-0240(5.5K)E FR-E820-0330(7.5K)E 71.5 FR-E820-0240(5.5K)SCE FR-E820-0330(7.5K)SCE (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 191 FR-E840-0120(5.5K)E, FR-E840-0170(7.5K)E FR-E840-0120(5.5K)SCE, FR-E840-0170(7.5K)SCE ５６（６） Inverter model FR-E840-0120(5.5K)E FR-E840-0170(7.5K)E FR-E840-0120(5.5K)SCE FR-E840-0170(7.5K)SCE (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 192 FR-E820-0470(11K)E, FR-E820-0600(15K)E FR-E840-0230(11K)E, FR-E840-0300(15K)E FR-E820-0470(11K)SCE, FR-E820-0600(15K)SCE FR-E840-0230(11K)SCE, FR-E840-0300(15K)SCE 10.6 12.5 (12.5) Inverter model FR-E820-0470(11K)E FR-E820-0600(15K)E FR-E840-0230(11K)E FR-E840-0300(15K)E 84.7 FR-E820-0470(11K)SCE FR-E820-0600(15K)SCE FR-E840-0230(11K)SCE FR-E840-0300(15K)SCE (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 193 FR-E820-0760(18.5K)E, FR-E820-0900(22K)E FR-E840-0380(18.5K)E, FR-E840-0440(22K)E FR-E820-0760(18.5K)SCE, FR-E820-0900(22K)SCE FR-E840-0380(18.5K)SCE, FR-E840-0440(22K)SCE (10) Inverter model FR-E820-0760(18.5K)E FR-E820-0900(22K)E FR-E840-0380(18.5K)E FR-E840-0440(22K)E 84.7 FR-E820-0760(18.5K)SCE FR-E820-0900(22K)SCE FR-E840-0380(18.5K)SCE FR-E840-0440(22K)SCE (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 194 4.4.3 Inverter outline dimension drawings (IP67 model)  With the power ON/OFF switch FR-E846-0026(0.75K), FR-E846-0040(1.5K), FR-E846-0060(2.2K), FR-E846-0095(3.7K) Inverter model FR-E846-0026(0.75K) FR-E846-0040(1.5K) FR-E846-0060(2.2K) FR-E846-0095(3.7K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 195  Without the power ON/OFF switch FR-E846-0026(0.75K), FR-E846-0040(1.5K), FR-E846-0060(2.2K), FR-E846-0095(3.7K) Inverter model FR-E846-0026(0.75K) FR-E846-0040(1.5K) FR-E846-0060(2.2K) FR-E846-0095(3.7K) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 196 4.4.4 Dedicated motor outline dimension drawings  Dedicated motor (SF-PR-SC) outline dimension drawings (standard horizontal type) Frame number: 90L Connector (for encoder) MS3102A20-29P ＲＡＡ Frame leg viewed Section AA from above Frame number: 100L, 112M Connector (for encoder) MS3102A20-29P Ａ...
Page 197 Dimensions table (Unit: mm) Output (kW) Motor Frame poles poles (KP) — 230.5 143 62.5 — 158 435.5 175 — 150 92.5 24j6 100L 6.5 203.5 230 28j6 — 28j6 112M — 28j6 132S 270 211.5 132 305 38k6 132M 289 230.5 132 324 38k6 160M...
Page 198 Frame number: 160M, 160L, 180M Connector (for encoder) MS3102A20-29P Exhaust Suction With guard wires Direction of cooling fan wind Mark for earthing (grounding) Earth (ground) terminal (M8) Sliding distance Frame leg viewed from above Section AA For motor (U, V, W) Earthing (grounding) terminal (M8) Make sure to earth (ground) the earth (ground) terminal of the flange...
Page 199  Dedicated motor (SF-V5RU(H)) outline dimension drawings (standard horizontal type with brake) Frame number: 90L Frame number: 100L, 112M, 132S, 132M Connector (for encoder) Connector (for encoder) MS3102A20-29P MS3102A20-29P Terminal box for cooling fan Terminal box for cooling fan Main Exhaust Exhaust Main...
Page 200 • The 400 V class motor has "H" in its model name. • Since a brake power device is a stand-alone, install it inside the enclosure. (This device should be arranged by the customer. Refer to the FR-E800 catalog.) 4. Specifications...
Page 201  Dedicated motor (SF-V5RU(H)) outline dimension drawings (flange type) Frame number: 90L Frame number: 100L, 112M, 132S, 132M Connector (for encoder) Connector (for encoder) MS3102A20-29P MS3102A20-29P LN LZ Exhaust LN LZ Exhaust Section Section Suction Suction Direction of cooling fan wind Earth (ground) terminal (M5) Direction of Mark for earthing (grounding)
Page 202 Frame number: 160M, 160L, 180M Connector (for encoder) MS3102A20-29P LN LZ Exhaust Section Suction Direction of Earth (ground) terminal (M8) cooling fan wind Mark for earthing (grounding) With guard wires Section BB Make sure to earth (ground) the earth (ground) terminal of the flange For motor (U, V, W) section as well as the earth (ground) terminal in the terminal box.
Page 203  Dedicated PM motor (MM-GKR) outline dimension drawings MM-GKR13 □43 □40 60.7 φ4.5 installation hole × 4 21.5 Use a hex socket bolt. Power supply connector 13.9 19.2 27.5 39.8 Power supply connector pin-outs Non-load side Power supply connector 19.2 MM-GKR23, 43 □60 φ5.8 installation hole × 4...
Page 204 Power supply connector pin-out Pin number Signal name (PE) NOTE • Unless otherwise specified, use general dimensional tolerances. • Use a friction coupling for connection with a load. • The servo motor with oil seal (MM-GKR_J) has outline dimensions different from those of the standard motor. For details, contact your sales representative.
Page 205  Dedicated PM motor (MM-GKR) (with electromagnetic brake) outline dimension drawings MM-GKR23B □60 96.4 φ5.8 installation hole × 4 Use a hex socket bolt. Power supply connector 10.8 13.9 19.2 21.6 40.8 36.4 27.8 Power supply connector pin-outs Brake connector Non-load side Power supply connector...
Page 206 MM-GKR73B 135.3 □80 φ6.6 installation hole × 4 Use a hex socket bolt. Power supply connector 10.3 19.2 20.7 46.1 69.6 27.8 Brake connector Power supply connector pin-outs Non-load side Power supply connector Brake connector pin-outs 18.4 19.2 Brake connector Power supply connector pin-out Pin number Signal name Earth...
Page 207  Dedicated PM motor (MM-GKR) (with reduction gear) outline dimension drawings For reverse rotation command Rotation direction For forward rotation command □LD 4-φM Power supply connector Power supply connector pin-outs Dimensions table (Unit: mm) Reduction ratio (actual MM-GKR[]G0 reduction ratio) (42/221) 1/12 112.7 60h7 16h6 48.5 91.7 34.5 60.5 (9/104) 1/20 (12/247) 1/30 127.7...
Page 208 Signal name number NOTE • Unless otherwise specified, use general dimensional tolerances. • Use a friction coupling for connection with a load. • The MM-GKR[][]G0 (reduction gear equipped model for general industrial machines) has a straight shaft as standard. The models with a key shaft are also available as dedicated models.
Page 209 1.5kW 45° 4×φ9 2.2kW 45° φ9 × 3.7kW 116.5 104.5 45° 4×φ13.5 2×M8 screw, depth: 16 Screw holes for suspension bolts (upper/lower) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 210 5.5kW 116.5 149.5 2×M8 screw, depth: 16 φ×13.5 Screw holes for suspension bolts (upper/lower) 7.5kW □176 116.5 194.5 2×M8 screw, depth: 16 4× φ13.5 Screw holes for suspension bolts (upper/lower) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 211  EM-AMFB 0.1kW, 0.2kW φ6.6 × 0.4kW 245.5 205.5 φ6.6 × 0.75kW 275.5 235.5 45° 4×φ6.6 (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 212 1.5kW 111.5 45° φ9 × 2.2kW 141.5 45° φ9 × 3.7kW 116.5 104.5 45° 2×M8 screw, depth: 16 4×φ13.5 Screw holes for suspension bolts (upper/lower) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 213 5.5kW □176 116.5 149.5 2×M8 screw, depth: 16 4×φ13.5 Screw holes for suspension bolts (upper/lower) 7.5kW □176 116.5 194.5 2×M8 screw, depth: 16 4×φ13.5 Screw holes for suspension bolts (upper/lower) (Unit: mm) 4. Specifications 4.4 Outline dimension drawings...
Page 214 CHAPTER 5 Appendix How to check specification changes........................214 Instructions for EAC..............................221 Compliance with the UK certification scheme.......................221 Restricted Use of Hazardous Substances in Electronic and Electrical Products..........222 Referenced Standard (Requirement of Chinese standardized law) ..............222...
Page 215 Slave: up to 64 stations (16 stations × 4 groups)  Functions available for the inverters manufactured in May 2020 or later • Firmware version: 1 or later Item Details Mitsubishi Electric geared motor GM-[] Plug-in option FR-A8ND E kit, FR-A8NP E-kit Stand-alone option...
Page 216 Item Details The SF-V5RU 1.5 to 5.5 kW motors can be driven by the FR-E820-0110(2.2K) to 0330(7.5K) Mitsubishi Electric Vector control inverters. dedicated motor (SF-V5RU (1500 r/min The SF-V5RUH 1.5 to 5.5 kW motors can be driven by the FR-E840-0060(2.2K) to 0170(7.5K) series)) inverters.
Page 217  Functions available for the inverters manufactured in January 2021 or later • Firmware version: 3 or later Item Details Related manuals Position control (Vector control) is supported for induction motors. • The following parameters are added:Pr.420, Pr.421, Pr.423, Pr.425 to Pr.427, Pr.430, Pr.446, Pr.464 to Pr.478, Pr.510, Pr.511, Pr.538, Pr.698, Pr.1222, Pr.1223, Pr.1225 to Pr.1227, Pr.1229 to Pr.1231, Pr.1233 to Pr.1235, Pr.1237 to Pr.1239, Pr.1241 to Pr.1243, Pr.1245 to Pr.1247, Pr.1249, Pr.1282, Pr.1283, Pr.1285,...
Page 218 • Setting values "27 and 28" added for Pr.320 to Pr.322 • Setting value "22" added for Pr.774 to Pr.776 • Setting value "22" added for Pr.992 • Setting value "22" added for Pr.1027 to Pr.1034 The FR-E800-EPC models are added. Connection/ EtherCAT communication Function/...
Page 219  Functions available for the inverters manufactured in September 2021 or later • Firmware version: 6 or later Item Details Related manuals Added parameters • Pr.726 and Pr.727 Setting values • Setting values "81, 82, and 84 to 86" added for Pr.52, Pr.774 to Pr.776, and Pr.1027 BACnet MS/TP communication Function/ to Pr.1034...
Page 220  Functions available for the inverters manufactured in November 2022 or later • Firmware version: 11 or later Item Details Related manuals 200 V class: 0.1 kW to 0.4 kW are added. Connection/ EM-A motor capacity 400 V class: 2.2 kW is added. Function Added parameters •...
Page 221 Function communication model, and the IP67 model Parameter available for the FR- Pr.1457 added (FR-E800-EPC inverters manufactured in August 2024 or earlier do Function/ E800-EPC not support this parameter even if the firmware is updated to version 14 or later.) Communication ...
Page 222 • Authorized sales representative (importer) in the CU area The authorized sales representative (importer) in the CU area is shown below. Name: Mitsubishi Electric Turkey A.S. Head Office Address: Serifali Mahallesi Kale Sokak. No:41 34775 Umraniye, Istanbul, Turkey Phone: +90-216-969-25-00...
Page 223 Restricted Use of Hazardous Substances in Electronic and Electrical Products The mark of restricted use of hazardous substances in electronic and electrical products is described as follows based on the "Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products" of the People's Republic of China.
Page 224 (1) Damages caused by any cause found not to be the responsibility of Mitsubishi Electric. (2) Loss in opportunity, lost profits incurred to the user by Failures of Mitsubishi Electric products. (3) Special damages and secondary damages whether foreseeable or not, compensation for accidents, and compensation for damages to products other than Mitsubishi Electric products.
Page 225 Manual number Revision Dec. 2019 IB(NA)-0600865ENG-A First edition Apr. 2020 IB(NA)-0600865ENG-B Added • FR-E820S-0008(0.1K) to 0110(2.2K)(E)(SCE) • FR-E800-SCE (safety communication model) Jun. 2020 IB(NA)-0600865ENG-C Added • Vector control Nov. 2020 IB(NA)-0600865ENG-D Added • FR-E820-0470(11K) to 0900(22K)(E)(SCE), FR-E840-0230(11K) to 0440(22K)(E)(SCE) •...
Page 226 FR-E800 TORISETSU Model SETSUZOKU EIBUN Model code 1AJ048 HEAD OFFICE: TOKYO BUILDING 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN IB(NA)-0600865ENG-R(2501)MEE Printed in Japan Specifications subject to change without notice.

This manual is also suitable for:

Fr-e820-0008 Fr-e820-0015 Fr-e820-0030 Fr-e820-0050 Fr-e820-0080 Fr-e820-0110 ... Show all

Mitsubishi Electric FR-E800 Instruction Manual (Connection

Quick Links

Need help?

Questions and answers

Related Manuals for Mitsubishi Electric FR-E800

Summary of Contents for Mitsubishi Electric FR-E800

This manual is also suitable for:
