  • Page 1 DC-DC3 Power Convert Module User’s Manu al Edition 1.21 2025/01/10...
  • Page 2 DC-DC3 User’s Manual Copyright Copyright 2014, all rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.

  • Page 3: Packing List

    DC-DC3 User’s Manual Packing List: Please check the package content before you starting using the board. 1 x DC-DC3 Power Convert Module (Include Heat spreader) 1 x DC Input Power Cable 1 x DC Output Power Cable (OALDC-B / 1040513) (OALDC-DC3 / 1040614) (DC-DC3-5V &...

  • Page 4: Mechanical And Environmental

    DC-DC3 User’s Manual 1. <Product Specification> Mechanical & Environmental Accessories OALDC-DC3 x 1, OALDC-B x 1 (DC-DC3-5V & DC-DC3-12V Only) Dimensions (L x W ) 41.98mm x 33.00mm Temperature Operating within 0~60 centigrade Relative Humidity 10%~90%, non-condensing Ordering Code DC-DC3-5V:...
  • Page 5 DC-DC3 User’s Manual 2. <Power Supply> 2.1 <Power Input> DC_IN: Terminal Block 2-pin power connector Signal Signal Power in DC-DC3-5V supports 6~30V wide voltage input. DC-DC3-12V supports 9~30V wide voltage input. Power jack 2.5mm DC_IN: Power jack connector Signal Signal Power in DC-DC3J-5V supports 6~30V wide voltage input.
  • Page 6 DC-DC3 User’s Manual 2.2 <Power Output> DC_OUT: Terminal Block 2-pin power connector Signal Signal Power Out DC-DC3-5V supports 5V power output. DC-DC3-12V supports 12V power output. DC_OUT: Terminal Block 2-pin power connector Signal Signal Power Out DC-DC3J-5V supports 5V power output.

  • Page 7: Contact Information

    Taiwan Commate Computer Inc. 19F., No.94, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei Address City 22102, Taiwan +886-2-26963909 Website http://www.commell.com.tw E-Mail info@commell.com.tw (General Information) tech@commell.com.tw (Technical Support) Commell is a brand name of Taiwan commate computer Inc.
