- Page 1 DC-PD Module User’s Manual Edition 1.6 2018/05/18...
- Page 2 Trademark All trademarks are the property of their respective holders. Any questions please visit our website at http://www.commell.com.tw...
-
Page 3: Packing List
DC-PD User’s Manual Packing List: Please check the package content before you starting using the board. 1 x DC-PD-5V/12VT 1 x DC-PD-5V/12VR 1 x DC Output Power Cable (OALDC-DC3/1040614) Accessories for DC-PD-5V/12VR-02 Accessories for DC-PD-5V/12VR-03 1 x MPX-350 1 x MPX-210D 1 x CN_LAN Cable 1 x CN_LAN Cable (OALPOE-03/1040629) -
Page 4: Product Description
Power Sourcing Equipment Controller Temperature -40~+85°C Ordering Code DC-PD-5VT DC to DC, with Terminal Block, DC Input 37~57V, DC Output 5V / 7A DC-PD-5VR Compliant IEEE802.3at/af, and LTPoE++™ 90W with RJ45 connector, DC Output 5V / 7A DC-PD-5VR-02... - Page 5 DC-PD User’s Manual 2. < Block Diagram > 2.1 <DC-PD-5V/12VR> Power Sourcing Equipment Input Connector CN_LAN Controller LAN signal DC output Device - 5 -...
- Page 6 DC-PD User’s Manual 2.2 <DC-PD-5V/12VT> DC input 37V-57V 54V_IN Controller DC output Device - 6 -...
- Page 7 DC-PD User’s Manual 3. < Mechanical Drawing > - 7 -...
- Page 8 DC-PD User’s Manual 4. < Connector Location and Reference > CN_LAN RJ45 DC_OUT 54V_IN Connector Function CN_LAN 12-pin Ethernet Connector RJ45 RJ-45 LAN Port 54V_IN 2-pin power input with Terminal Block DC_OUT 2-pin power output with Terminal Block 4.1 <Power Input> Note : DC input used by T series modules Connector : 54V_IN Description...
- Page 9 DC-PD User’s Manual 4.2 <Power Output> Connector : DC_OUT Description Description Power output For DC-PD-5V , with +5V / 7A Output For DC-PD-12V , with +12V / 6A Output 4.3 <PoE Input> LAN Connector : RJ45 Description Description MI0+ MI0- MI1+ MI2+ MI2-...
- Page 10 DC-PD User’s Manual 5. < DC-PD T-series Installation Guide > 1. Check your 54V power supply work correctly. 2. Connect 54V power supply to 54V_IN connector, and then DC_OUT is 12V if you use DC-PD-12VT 12V / 6A 54V Power supply - 10 -...
- Page 11 DC-PD User’s Manual 6. < DC-PD R-series Installation Guide > 1. Check your Power Sourcing Equipment (PSE)work correctly 2. Connect MPX-350 / MPX-210D to DC-PD with CN_LAN cable (There are LAN ports in MPX-350.Put the CN_LAN cable into CN_LAN1 or CN_LAN2, the other for LAN adapter.) MPX-350 OALPOE-02 Cable CN_LAN1...
-
Page 12: Contact Information
Taiwan Commate computer Inc. 19F., NO.94, Sec. 1, Xintai 5 Rd., Xizhi Dist., New Taipei Address City 22102, Taiwan. +886-2-26963909 +886-2-26963911 Website www.commell.com.tw info@commell.com.tw (General infomation) E-mail tech@commell.com.tw (Technical Support) Commell is a brand name of Taiwan Commate computer Inc. - 12 -...
