Summary of Contents for FERREX F-WDV35 B1

  • Page 2: Table Of Contents

    Table of contents Table of contents 1. Introduction ....................2. Product description (Fig. 1-13) ..............3. Scope of delivery (Fig. 2)................10 4. Proper use ..................... 5. Safety instructions..................12 6. Technical data ....................14 7. Unpacking ..................... 15 8. Assembly ....................... 15 9.
  • Page 3 Explanation of the symbols on the product Explanation of the symbols on the product Symbols are used in this manual to draw your attention to potential hazards. The safety symbols and the accompanying explanations must be fully understood. The warnings themselves will not rectify a hazard and cannot replace proper accident prevention measures.

  • Page 4: Introduction

    Introduction 1. Introduction Manufacturer: Scheppach GmbH Günzburger Straße 69 D-89335 Ichenhausen Dear Customer We hope your new product brings you much enjoyment and success. Note: In accordance with the applicable product liability laws, the manufacturer of this product assumes no liability for damage to the product or caused by the product arising from: •...

  • Page 5: Scope Of Delivery (Fig. 2)

    Scope of delivery (Fig. 2) Locking mechanisms Base frame Holders Mounting holes Castors Drain cover Suction connection Fitting port Product socket outlet On/off switch Blast connection Filter cage 11a. Safety float valve Vacuum hose 12a. Hose coupling Handle 13a. Slider Telescopic tube 14a.

  • Page 6: Proper Use

    Proper useExplanation of the signal words in the operating manual 4. Proper use The wet and dry vacuum cleaner is suitable for wet and dry vacuuming using the ap- propriate filter. The product is not intended for vacuuming flammable, explosive or harmful substances.

  • Page 7: Safety Instructions

    Safety instructions CAUTION Signal word to indicate a potentially hazardous situation which, if not avoided, could result in minor or moderate injury. ATTENTION Signal word to indicate a potentially hazardous situation which, if not avoided, could result in product or property damage. 5.
  • Page 8 Safety instructions • Never point the product or nozzles at yourself or others, especially your eyes and ears, during operation. There is a danger of injury. • Do not suck up any hot, glowing, flammable, explosive or hazardous substances. These include hot ash, petrol, solvents, acids or alkalis. There is a risk of fire and injury.

  • Page 9: Technical Data

    Technical data • Furthermore, despite all precautions having been met, some non-obvious resid- ual risks may still remain. • Residual risks can be minimised if the "Safety Instructions" and the "Intended Use" together with the operating manual as a whole are observed. •...

  • Page 10: Unpacking

    Unpacking 7. Unpacking WARNING The product and the packaging material are not children's toys! Do not let children play with plastic bags, films or small parts! There is a danger of choking or suffocating! • Open the packaging and carefully remove the product. •...
  • Page 11 Assembly 3. Lift the container cover (2) from the container (3). Attaching the container cover: 1. Place the container cover (2) on the container (3). 2. Fasten the container cover (2) with the latches (3a). Ensure that the latches (3a) latch into the recesses in the container cover (2). 8.2.
  • Page 12 Assembly 8.4.1. Assembling/removing the paper filter bag (17) (Fig. 5) Removing: 1. Remove the paper filter bag (17) from the bar (7a) on the suction connection (7). Assembling: 1. Attach the paper filter bag (17) to the bar (7a) on the suction connection (7) inside the container (3).
  • Page 13 Assembly 8.5.2. Blast function (Fig. 9) 1. Push the hose coupling (12a) fully into the blowing connection (10). 2. Turn the hose coupling (12a) clockwise until it fully engages. 3. Check that the suction hose (12) is installed correctly by gently pulling on the hose coupling (12a).

  • Page 14: Operation

    Operation 8.9.1. Fitting the nozzle (Fig. 11) 1. Insert the desired nozzle (15/16) into the handle (13) or the telescopic pipe (14). 2. Remove the nozzle (15/16) by pulling it forwards off the respective telescopic pipe (14) or off the handle (13). 9.

  • Page 15: Working Instructions

    Working instructions 3. Set the on/off switch (9) to position II. 4. When you switch on the power tool*, the automated process of switching on the product begins. Switching off 1. Switch the power tool* off. The product has an automated switch-off function that activates after a delay of approximately 6 to 7 seconds.
  • Page 16 Working instructions 10.1.1. Dry vacuuming (Fig. 5, 7, 8, 11) Note: Do not use a wet or damp product for dry vacuuming! 1. Insert the paper filter bag (17) into the container (3) (see 8.4.1. ). 2. Fit the filter cartridge (19) (see 8.4.3. ). 3.

  • Page 17: Electrical Connection

    Electrical connection 7. Hold the suction pipe (12) handle (13) firmly. 8. Switch on the product (see 9.1. or 9.2. ). 9. Vacuum the area to be cleaned. 10. Switch off the product (see 9.1. ). 11. Clean the product (see 12.1. ). 10.2.
  • Page 18 Electrical connection • Pressure points, where connection cables are passed through windows or doors, • Kinks where the connection cable has been improperly fastened or routed, • Places where the connection cables have been cut due to being driven over, •...

  • Page 19: Cleaning And Maintenance

    Cleaning and maintenance 12. Cleaning and maintenance WARNING Have maintenance and repair tasks that are not described in this operating manual, carried out by a specialist workshop. Use only original spare parts. There is a risk of accident! Always carry out maintenance and cleaning work with the motor switched off and the mains plug disconnected.
  • Page 20 Cleaning and maintenance 12.1.1. Emptying the container (3) (Fig. 3) WARNING Empty and clean the product before and after use to avoid the accumulation of materials that could pose a fire risk in the prod- uct. 1. Remove the container cover (2) from the container (3) as described in Attaching and removing the container cover (2) (Fig.

  • Page 21: Storage And Transport

    Storage and transport 12.2. Maintenance 1. Check the product for obvious defects such as loose, worn or damaged parts be- fore each use. 2. Check the covers and protective devices for damage and correct seating. Replace them if necessary. 12.2.1. Replacing the foam filter (18) and filter cartridge (19) (Figs. 3, 6, 7) 1.

  • Page 22: Repair & Ordering Spare Parts

    Repair & ordering spare parts 14. Repair & ordering spare parts After repairs or maintenance, make sure that all safety-related parts are installed and are in perfect condition. All parts which may cause injury must be kept where they are inaccessible to children or others. ATTENTION According to the German Product Liability Act, no liability is accepted for damage caused by improper repairs or by not using original...

  • Page 23: Troubleshooting

    Troubleshooting 15. Troubleshooting The following table shows fault symptoms and describes remedial measures in the event of your product failing to work properly. If you cannot localise and rectify the problem with this, please contact your service workshop. Fault Possible cause Remedy Product does not run.
  • Page 24 Troubleshooting Fault Possible cause Remedy The suction capacity is The filter cartridge or Remove the filter cartridge or also reduced after foam filter is damaged. foam filter. cleaning the filter car- tridge or the foam fil- ter. The product is over- The filter cartridge or Clean the filter cartridge or foam heated.

  • Page 25: Warranty Details

    Warranty Details 16. Warranty Details Wet / dry vacuum cleaner Warranty Details REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 60 months (dependant on product) from the date of purchase.

  • Page 26: Repair And Refurbished Goods Or Parts Notice

    Repair and Refurbished Goods or Parts Notice 17. Repair and Refurbished Goods or Parts Notice Wet / dry vacuum cleaner Repair and Refurbished Goods or Parts Notice REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION Unfortunately, from time to time, faulty products are manufactured which need to be returned to the Supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored onamobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost.

  • Page 27: Exploded View

    Exploded view...
  • Page 28 Notes Notes...
  • Page 29 Notes...
