RocwooD RWHPPW Owner's Manual

Petrol pressure washer
Hide thumbs Also See for RWHPPW:
Table of Contents

Advertisement

Quick Links

Download this manual
RocwooD Petrol
Pressure Washer
OWNERS MANUAL
RWHPPW
EN
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY,
PROPERTY DAMAGE AND MAY VOID WARRANTY.
KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary
in appearance, assembly, inclusions, specificaions, descripion, and packaging.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RWHPPW and is the answer not in the manual?

Questions and answers

Related Manuals for RocwooD RWHPPW

Summary of Contents for RocwooD RWHPPW

  • Page 1 RocwooD Petrol Pressure Washer OWNERS MANUAL RWHPPW READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary...
  • Page 2 Introduction This manual has been produced by RocwooD and should be kept with the product and referenced for operation, maintenance and troubleshooting. This manual contains an overall description of the product, together with all the necessary information for using the product correctly and safely.

  • Page 3: Specification

    Specification Brand RocwooD RWHPPW Continuous Rated Pressure 2900 psi (200 bar) Maximum Pressure 3190 psi (220 bar) Horse Power Engine Type 4-stroke OHV Engine Displacement 210cc Flow Rate 9.1 Litres Per Minute Starting System Recoil Start Power Source Petrol Tank Capacity...
  • Page 4 Contents 2) Introduction 3) Specification 4) Contents 5) For Safe Operation 6-7) Safety 8-9) Parts Assembly 10-11) Features 12-14) Assembly 15) Pre-Operation Checklist 16-17) Starting the Engine 18) Turning off the Engine 19) Additional Operations 20-22) Maintenance 23) Troubleshooting 24) Warranty...

  • Page 5: For Safe Operation

    For Safe Operation Risk of electric shock. Wear protective gloves. Wear ear protection Hot surface. Wear eye protection. Wear appropriate clothing. The manufacturer cannot Risk of explosion. anticipate every possible hazardous circumstance that the user may encounter. Therefore, the warnings in this manual, on tags, and on affixed decals are not all-inclusive.
  • Page 6 Safety Read and understand this manual in its entirety before operating this pressure washer. Improper use of this pressure washer could result in serious injury or death. This machine has been designed for use with the cleaning agent supplied or recommended by the manufacturer.
  • Page 7 Safety The high pressure stream of water produced can cut through skin and underlying tissue. Never squeeze the trigger or point the spray gun at other people, animals, plants, or fragile objects such as glass, even if the engine is stopped. This unit is not a toy.

  • Page 8: Parts & Assembly

    Parts Assembly...
  • Page 9 Parts Assembly...
  • Page 10 Features Spray Gun Nozzles Exhaust Choke & Fuel Level High Pressure Hose Fuel Tank 8" Wheels Detergent Tank On/Off Switch Recoil Start...
  • Page 11 Features Soft Grip Handle Lance High Pressure Outlet Pressure Release Valve Pump Water Inlet...
  • Page 12 Assembly Packing List: Pressure washer Operator’s manual Spray gun Do not operate this pressure washer if Lance any of the parts are damaged or High pressure hose missing until the part is replaced. Spray nozzles (3) - 0°, 25°, 40° and soap nozzle Using this product with damaged or Spray gun hook (upper) missing parts can cause damage to...
  • Page 13 Assembly 3) Attatch the Upper Gun Hook 4) Install the High Pressure Pipe Hook Use the sleeve to unscrew the panel mounting Pass the top stock, flat pad and nut through bolts on one side of the fuel tank and remove the bolt in turn, and tighten the nut.
  • Page 14 Assembly 8) Add Petrol Into Pressure Washer 7) Add Oil Into Pressure Washer Place pressure washer on a level surface. Set pressure washer on a clean and level Remove one or both of the dipsticks to surface in an area that is well ventilated. ensure you do not overfill the engine.

  • Page 15: Pre-Operation Check List

    Pre-Operation Checklist Read and understand this operator manual in it's entirety before operating ☑ Check oil level and add oil to the proper level if low ☑ Check fuel level and add fuel if needed ☑ ☑ Check connections of handle and all holes to make sure they are secure Check all hoses for kinks and damage ☑...

  • Page 16: Starting The Engine

    Starting the Engine 1) Turn the Fuel Valve to “ON” 2) Slide Choke Lever Left to “Choke” Place pressure washer on a level surface. Close the choke by sliding the choke lever Purge the systems water pump of air by to the left.
  • Page 17 Starting the Engine 5) Slide Choke to “RUN” 6) Turn on Water Supply As soon as your pressure washer is running, turn Slide choke lever to the right (RUN position). on your water supply immediately. The machine will run normally when the Using the machine for an extended period of lever is fully moved to the "RUN"...

  • Page 18: Turning Off The Engine

    Turning Off The Engine 1) To Stop The Engine Turn Switch Off 2) Release Pressure and Flick Lock Turn the ON/OFF switch to the "OFF" Once the water supply is off. Squeeze the position. The engine should immediately trigger handle to release all water pressure. stop.

  • Page 19: Additional Operations

    Additional Operations Using Spray Nozzles To connect or disconnect spray nozzle, pull back on the quick-connect collar. Insert or remove spray nozzle then release collar. When spray nozzle is connected, pull on the spray nozzle to make sure it is in. For general cleaning use the 40°...

  • Page 20: Maintenance

    Maintenance Regular maintenance will extend the life of this pressure washer and improve its performance. The warranty does not cover items that result from operator negligence, misuse, or abuse. To receive full value from the warranty, operator must maintain the pressure washer as instructed in this manual, including proper storage.
  • Page 21 Maintenance Changing Engine Oil Engine oil will drain better if the engine is still warm, but not hot. Shut off engine. Clean the area around the oil fill cap/dipstick to keep out debris then remove oil fill cap/dipstick. Place an oil pan on the ground to catch oil. Remove oil plug then tilt pressure washer back and to the side to empty out the oil from the crankcase.
  • Page 22 Maintenance Checking Spark Plug Disconnect the spark plug cap from the spark plug. Before removing the spark plug, clean the area around its base to prevent debris from entering the engine. Clean carbon deposits off the electrode with a wire brush. Check the electrode gap and slowly adjust to 0.80mm (0.031in.) if necessary.

  • Page 23: Troubleshooting

    Troubleshooting...
  • Page 24 No claims will be accepted after this time. RocwooD will arrange collection of faulty goods within the first 60 days and thereafter it will be a return to base warranty (the customer must return and we will check, if found faulty the machine will be repaired and returned back to the customer.
