24"- 36"W AUF McKenzie Alder
Bookcases: 60"- 84"H
Ready to Finish
Assembly Instructions
24" x 60"
24" Wide
Model #
1523AUF
30" x 60"
30" Wide
Model #
1533AUF
36" x 60"
36" Wide
Model #
1543AUF
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
P.O. Box 2827
Eugene, OR 97402 USA
24" x 84"
24" x 72"
1524AUF
1526AUF
30" x 84"
30" x 72"
1534AUF
1536AUF
36" x 84"
36" x 72"
1544AUF
1546AUF
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
Fax: 541-687-2060• Email: info@whittierwood.com
IMPORTANT NOTES:
• This assembly requires two people.
• For
normal household use only. Not recommended for commercial use.
• Do not climb, sit or stand on this piece of furniture.
• Do not overload the shelves.
• Unload items before you move this unit.
• Before you load or move this unit, tighten all screws and supports.
• For maximum stability, attach unit to the wall using the enclosed
hardware as per instructions and supports.
• Before
you begin your project, completely read the Assembly Instructions
and Finishing Hints.
• Periodically inspect your furniture for any loose glue joints, screws or
any other problem that might affect the stability of your furniture.
Tighten or repair as needed.
Serious or fatal crushing injuries can occur from furniture tip-over. Use of
tip-over restraints may only reduce but not eliminate the risk of tip-over.
To help prevent tip-over:
•
Place heaviest items in the bottom shelves.
•
Unless specifically designed to accommodate, do not set TVs or other
heavy objects on top of this product.
•
Never allow children to climb or hang on drawers, doors or shelves.
•
Never open more than one drawer at a time.
Warning: At least one tipping restraint kit was included with your piece of
Whittier Wood Furniture. When you receive your furniture, be sure to find
and properly install the tipping restraint(s). If you cannot locate the
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
WARNING
4 /17
