24"- 36"W AUF McKenzie Alder
Bookcases: 60"- 84"H
Ready to Finish
Assembly Instructions
24" x 60"
24" Wide
Model #
1523AUFb 1524AUFb 1526AUFb
30" x 60"
30" Wide
Model #
1533AUFb 1534AUFb
36" x 60"
36" Wide
Model #
1543AUFb 1544AUFb 1546AUFb
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
P.O. Box 2827
Eugene, OR 97402 USA
24" x 84"
24" x 72"
30" x 84"
30" x 72"
1536AUFb
36" x 84"
36" x 72"
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
Fax: 541-687-2060• Email: info@whittierwood.com
IMPORTANT NOTES:
• This assembly requires two people.
• For
normal household use only. Not recommended for commercial use.
• Do not climb, sit or stand on this piece of furniture.
• Do not overload the shelves.
• Unload items before you move this unit.
• Before you load or move this unit, tighten all screws and supports.
• For maximum stability, attach unit to the wall using the enclosed
hardware as per instructions and supports.
• Before
you begin your project, completely read the Assembly Instructions
and Finishing Hints.
• Periodically inspect your furniture for any loose glue joints, screws or
any other problem that might affect the stability of your furniture.
Tighten or repair as needed.
Children have died from furniture tipover. To reduce the risk of
furniture tipover:
• ALWAYS install tipover restraint provided.
• NEVER put a TV on this product.
• NEVER allow children to stand, climb or hang on doors, or shelves.
• Place heaviest items on the bottom shelves.
Use of tipover restraints may only reduce, but not eliminate,
the risk of tipover.
Attention: Attached to the bottom of or included with this unit is a tipping
restraint kit. When you receive your furniture, be sure to find and install
the tipping restraint as instructed in the kit. If you cannot locate the
restraint, please contact customer service immediately for replacement.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
WARNING
9/20
