- Page 1 DES-1032 10/100 Fast Ethernet Switch User’s Guide Printed In Taiwan RECYCLABLE...
- Page 2 Spare parts and spare kits Ninety (90) days D-Link’s sole obligation shall be to repair or replace the defective Hardware at no charge to the original owner. Such repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office.
- Page 3 RMA number must be prominently marked on the outside of the package. The packaged product shall be insured and shipped to D-Link, 53 Discovery Drive, Irvine CA 92618, with all shipping costs prepaid. D-Link may reject or return any product that is not packaged and shipped in strict compliance with the foregoing requirements, or for which an RMA number is not visible from the outside of the package.
- Page 4 AS TO THE QUALITY, SELECTION AND PERFORMANCE OF THE PRODUCT IS WITH THE PURCHASER OF THE PRODUCT. Limitation of Liability: TO THE MAXIMUM EXTENT PERMITTED BY LAW, D-LINK IS NOT LIABLE UNDER ANY CONTRACT, NEGLIGENCE, STRICT LIABILITY OR OTHER LEGAL...
- Page 5 Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Vervenden Sie keine Flüssig- oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung. Um eine Beschädigung des Gerätes zu vermeiden sollten Sie nur Zubehörteile verwenden, die vom Hersteller zugelassen sind. Das Gerät is vor Feuchtigkeit zu schützen.
-
Page 6: Copyright Statement
Trademarks Copyright ©1999 D-Link Corporation. Contents subject to change without prior notice. D-Link is a registered trademark of D-Link Corporation/D-Link Systems, Inc. All other trademarks belong to their respective proprietors. Copyright Statement No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems Inc., as stipulated by the... -
Page 9: Table Of Contents
OWER ON LED Indicators ..................11 Power Failure ..................11 IDENTIFYING EXTERNAL COMPONENTS ......12 ..................... 12 RONT ANEL ....................13 ANEL LED I ..................14 NDICATORS CONNECTING THE DES-1032 ............15 DES-1032 PC ..................15 DES-1032 )............. 16 WITH PLINK... - Page 10 ............17 UB WITHOUT PLINK PORT Using straight cable................18 Using crossover cable................18 DES-1032 DES-1032 ( ) ............ 19 Using straight cable................19 Using crossover cable................19 TECHNICAL SPECIFICATIONS ..........21 RJ-45 PIN SPECIFICATION ............24 INDEX ....................26...
-
Page 11: About This Guide
♦ Chapter 3, Identifying External Components. Describes the front panel, rear panel, and LED indicators of the DES-1032. ♦ Chapter 4, Connecting the DES-1032. Tells how you can connect the DES-1032 to your Ethernet network. ♦ Chapter 5, Programming the DES-1032. This chapter describes the programmable parameters of the DES-1032 and use of the configuration program. - Page 12 10/100 Fast Ethernet Switch User’s Guide ♦ Appendix A, Technical Specifications. Lists the technical (general, physical and environmental, and performance) specifications of the DES-1032. ♦ Appendix B, RJ-45 Pin Specification. Describes the RJ-45 receptacle/ connector and the straight and crossover cable connector.
-
Page 13: Introduction
10/100 Fast Ethernet Switch User’s Guide NTRODUCTION This section describes the features of the DES-1032, as well as giving some background information about Ethernet/Fast Ethernet switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. -
Page 14: Switching Technology
10/100 Fast Ethernet Switch User’s Guide Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. -
Page 15: Trunking Technology
Gigabit Ethernet. • Congestion Relief Existing equipment can be utilized more efficiently by relieving the congestion between the DES-1032 and the server. Connections to a server can be made simply by adding more network interface cards. VLAN (Virtual Local Area Network) A VLAN is a group of end-stations that are not constrained by their physical location and can communicate as if in a common broadcast domain, a LAN. -
Page 16: Features
Port-based (or port-group) VLAN is the most common method of implementing a VLAN, and is the one supplied in the DES-1032. Each DES-1032 port can belong from one to thirty-two VLAN. And each DES- 1032 can store configuration information on up to 16 VLAN. -
Page 17: Performance Features
10/100 Fast Ethernet Switch User’s Guide The DES-1032 is a perfect choice for sites planning to upgrade to Gigabit Ethernet. The DES-1032 combines dynamic memory allocation with store-and-forward switching to ensure that the buffer is effectively allocated for each port while data flow is controlled between the transmitting and receiving nodes to guarantee against all possible packet loss. - Page 18 10/100 Fast Ethernet Switch User’s Guide ♦ Data filtering rate eliminates all error packets, runts, etc. at 148,800 pps per port at 100% of wire-speed for 100Mbps speed. ♦ Data filtering rate eliminates all error packets, runts, etc. at 14,880 pps per port at 100% of wire-speed for 10Mbps speed.
-
Page 19: Unpacking And Setup
ETUP This chapter provides unpacking and setup information for the DES-1032es. Unpacking Open the shipping carton of the DES-1032 and carefully unpack its contents. The carton should contain the following items: ♦ One DES-1032 10/100 Fast Ethernet DES-1032 ♦ One AC power cord ♦... -
Page 20: Setup
DES-1032. Do not place heavy objects on the DES-1032. Desktop or Shelf Installation When installing the DES-1032 on a desktop or shelf, the rubber feet included with the device must first be attached. Attach these cushioning feet on the bottom at each corner of the device. -
Page 21: Rack Installation
Shelf Rack Installation The DES-1032 can be mounted in an EIA standard size, 19-inch rack, which can be placed in a wiring closet with other equipment. To install, attach the mounting brackets on the DES-1032’s front panel (one on each side) and... - Page 22 10/100 Fast Ethernet Switch User’s Guide Figure 2.2 Attaching the mounting brackets to the 10/100 Fast Ethernet DES-1032 Then, use the screws provided with the equipment rack to mount the DES- 1032 in the rack. Figure 2.3 Installing the DES-1032 in an equipment rack...
-
Page 23: Power On
10/100 Fast Ethernet Switch User’s Guide Power on The DES-1032 can be used with AC power sources 100 - 240 VAC, 50 - 60 Hz. To turn the DES-1032 on, plug the AC adapter into the nearby outlet. LED Indicators After the switch is turned on, the LED indicators should respond as follows: ♦... -
Page 24: Identifying External Components
This chapter describes the front panel, rear panel, and LED indicators of the DES-1032. Front Panel The front panel of the DES-1032 consists of 32 (10/100 Mbps MDI-X) ports in the DES-1032 and LED indicators. A description of the ports appear in the Introduction of this User’s Guide (see Features, Chapter 1). -
Page 25: Rear Panel
10/100 Fast Ethernet Switch User’s Guide Rear Panel The rear panel of the DES-1032 consists of a power switch, an AC power connector and two system fans. Figure 3.2 Rear panel view of the DES-1032 ♦ System Fans The fans are used to circulate air inside the DES-1032 and also to dissipate heat. -
Page 26: Led Indicators
The LED indicators of the DES-1032 include Power, 100M, Link/Act (Link/Activity) and FDX (Full-duplex). The LED indicators are used to facilitate monitoring and troubleshooting of the DES-1032. The following shows the LED indicators for the DES-1032 along with an explanation of each indicator. D-Link... -
Page 27: Connecting The Des-1032
DES-1032 to PC A PC can be connected to the DES-1032 via a Category 3, 4, 5 UTP/STP straight cable. The PC (equipped with a RJ-45 10/100 Mbps jack) should be connected to any of the thirty-two ports (1x -32x) for the DES-1032. -
Page 28: Des-1032 To Hub (With Uplink)
DES-1032 to Hub (with Uplink) A hub (10 or 100BASE-TX) can be connected to the DES-1032 via a Category 3, 4, 5 UTP/STP straight cable. The connection is accomplished from the hub’s Uplink (MDI-II) port to any of the DES-1032’s (MDI-X) ports. -
Page 29: 10Base-T Hub
10/100 Fast Ethernet Switch User’s Guide 10BASE-T Hub For a 10 BASE-T hub, the DES-1032’s LED indicators should show the following: ♦ 10/100M LED speed indicator is yellow. ♦ Full/Col LED indicator is yellow. 100BASE-TX Hub For a 100Base-TX hub, the DES-1032’s LED indicators should show the following: ♦... -
Page 30: Using Straight Cable
Using straight cable When using straight cable, the connection can be made from the Uplink (MDI-II) port of the DES-1032 to any port of the hub (see figure 11). Using crossover cable When using crossover cable, the connection can be made from any MDI-X... -
Page 31: Des-1032 To Des-1032 (And/Or Hub)
Using straight cable When using straight cable, this is done from the Uplink kit of the DES-1032 to any of the 10 Mbps or 100 Mbps (MDI-X) ports of the other DES-1032 or other devices (see Figure 4.4). Using crossover cable... - Page 32 10/100 Fast Ethernet Switch User’s Guide The DES-1032’s LED indicators for the respective connected ports are as follows: ♦ 100M is ON for 100BASE-TX, otherwise OFF. ♦ Link/Act is ON. ♦ FDX depends on the connected switch or other device.
-
Page 33: Technical Specifications
10/100 Fast Ethernet Switch User’s Guide ECHNICAL PECIFICATIONS General Standards: IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100 BASE-TX Fast Ethernet IEEE 802.3 Frame types: Transparent Protocol: CSMA/CD Ethernet Data Transfer Rate: Ethernet: Fast Ethernet: 10 Mbps (half duplex) 100Mbps (half duplex) 20 Mbps (full duplex) 200Mbps (full duplex) Topology:... - Page 34 EIA/TIA- 568 100-ohm STP (100 m) 100BASE-TX: 2-pair UTP Cat. 5 (100 m) EIA/TIA-568 100-ohm STP (100 m) Number of Ports: DES-1032: 32 x 10/100 Mbps ports Physical and Environmental AC inputs: 100 - 240 VAC, 50/60 Hz (internal universal power supply) Power Consumption:...
- Page 35 10/100 Fast Ethernet Switch User’s Guide Performance Transmission Method: Fast Store-and-forward RAM Buffer: DES-1032: 4 M bytes per device Filtering Address Table: 1 K active entries per device Packet Filtering/Forwarding Rate: 14,880 pps per port (for 10Mbps) 148,800 pps per port (for 100Mbps)
-
Page 36: Pin Specification
10/100 Fast Ethernet Switch User’s Guide RJ-45 P PECIFICATION When connecting the DES-1032 to another switch, a bridge or a hub, a modified crossover cable is necessary. Please review these products for matching cable pin assignment. following diagram tables show... - Page 37 The standard Category 3 cable, RJ-45 pin assignment The following shows straight cable and crossover cable connection: Straight cable for DES-1032 (Uplink MDI-II port) to switch/Hub or other devices connection Crossover cable for DES-1032 (MDI-X port) to switch/hub or other...
-
Page 38: Index
10/100 Fast Ethernet Switch User’s Guide NDEX ........23 Humidity 100 M (speed indicator) ... 15 100Base-T ........1 Identifying External Components ..........13 IEEE 802.3 LAN......1 ........23 AC inputs AC Power Connector ....14 AC power cord ......8 LAN card........ - Page 39 10/100 Fast Ethernet Switch User’s Guide RJ-45 Pin Specification.... 25 Technical Specifications ..22 ...... 24 Transmission Method segments........2 Trunking Technology....3 Setup........... 9 ....... 23 Storage Temperature Store and forward....... 6 Unpacking ........8 straight cable ......26 switch .........
- Page 41 2F, No. 233-2 Pao-Chiao Rd, Hsin-Tien, Taipei, Taiwan, R.O.C. TEL: 886-2-2916-1600 FAX: 886-2-2914-6299 WEB: www.dlink.com.tw U.K. D-LINK (EUROPE) LTD. D-Link House, 6 Garland Road, Stanmore, London HA7 1DP U.K. TEL: 44-181-235-5555 FAX: 44-181-235-5500 WEB: www.dlink.co.uk E-MAIL: info@dlink.co.uk U.S.A. D-LINK SYSTEMS, INC.
-
Page 43: Registration Card
8. What category best describes your company? Aerospace Engineering Education Finance Hospital Legal Insurance/Real Estate Manufacturing Retail/Chainstore/Wholesale Government Transportation/Utilities/Communication System house/company Other________________________________ 9. Would you recommend your D-Link product to a friend? Don't know yet 10.Your comments on this product? __________________________________________________________________________________________ __________________________________________________________________________________________...
