- Page 2 D-Link Switch User Manual FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 3: Table Of Contents
D-Link Switch User Manual Table of Contents Table of Contents ............................. i About This Guide ............................. 2 Terms/Usage ..............................2 Copyright and Trademarks ..........................2 Product Introduction ............................3 Product Outlook ............................. 3 Front Panel ..............................3 Rear Panel ..............................4 Grounding the Switch .......................... -
Page 4: About This Guide
This guide provides instructions to install the D-Link DES-1018P/MP switches. Terms/Usage In this guide, the term “Switch” (first letter capitalized) refers to the DES-1018P/MP, and “switch” (first letter lower case) refers to other Ethernet switches. Some technologies refer to terms “switch”, “bridge” and “switching hubs”... -
Page 5: Product Introduction
The first 8 10/100M ports of DES-1018P and all 16 10/100M ports of DES-1018MP support IEEE 802.3af PoE and are capable of feeding power up to 15.4 watts per port. The DES-1018P/MP switches are easy to install and require no configuration. This simplicity is useful for SOHO and SMB users who have limited budgets but require PoE capability in a switch. -
Page 6: Rear Panel
Light off No connection to a PoE device Rear Panel Figure 2 – DES-1018P/MP Rear Panels Power Cord Input: Connects the power cord. Power Cord Retainer Slot: Connects the power cord retainer to the unit. Switch GND: Connect a grounding wire to electrically ground the unit. -
Page 7: Grounding The Switch
D-Link Switch User Manual DES-1018P/MP has been giving customers the best option for physical security through a Kensington Security Slot in the rear panel. The Kensington Security Slot adds value to DES-1018P/MP by offering customers a simple, built-in security solution. -
Page 8: Hardware Installation
Step 2: Switch Installation Please follow the steps below to set up the Switch: 1. Install the DES-1018P/MP in a cool and dry place. Refer to the Technical Specifications for the acceptable operating temperature and humidity ranges. 2. Install the Switch in a site free from strong electromagnetic source, vibration, dust, and direct sunlight. -
Page 9: Attaching The Rubber Feet
As a precaution, in the event of a power failure, unplug the Switch. When power is resumed, plug the Switch back in. Step 5: Connecting the Switch Users can attach IEEE 802.3af compliant devices to the PoE ports on the DES-1018P/MP by plugging in an Ethernet cable. •... -
Page 10: Connect To An End Node
D-Link Switch User Manual NOTE: All Ethernet ports auto-detect MDI/MDIX, port speed (10, 100, 1000 Mbps) and duplex of the device connected to the Switch. Cable Quality For all connections to the Switch, use these rules for cable selection: • For connections to 10BASE-T and 100BASE-TX devices, use Category 5 or 5e UTP/STP cable. -
Page 11: Connect To Network Backbone Or Server
D-Link Switch User Manual Observe the guidelines for cable quality stated at the beginning of this section. The Link/Act/Speed LEDs for ports 1 to 16 light up green when the link is valid. The LEDs for ports 17 to 18 light up amber at 10/100 Mbps and green at 1000 Mbps. -
Page 12: Understanding The Switch Features
Understanding the Switch Features PoE Rule DES-1018P/MP supports many PoE features to guarantee the safety and stability of its PoE power supply. PoE Power Budget: DES-1018P/MP has set a limitation of maximum PoE power supply at 80/246.4 (DES- 1018P/MP) watts to protect the Switch and to stabilize the power being transmitted to the PoE devices. -
Page 13: Appendix A - Technical Specifications
Forwarding Mode: Store-and-forward Packet Buffer memory: 384 Kbytes Port Functions DES-1018P: 8 10/100 Mbps PoE, 8 10/100 Mbps, and 2 10/100/1000BASE-T/SFP combo ports and DES-1018MP: 16 10/100 Mbps PoE, and 2 10/100/1000BASE-T/SFP combo ports are compliant with the following standards: IEEE 802.3...
