- Page 1 79961/79962/79963/79964 DEEP WELL PUMP INSTRUCTION MANUAL 220-240V~50Hz SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION CAUTION! Before starting operation,remember that The electrical connection is made in a socket with earth contact and voltage of 230V~50Hz.Minimum protection:16 amperes. ATTENTION! ( for your own safety) Before starting operation of your new submerged pump, have a technician check operating eficiency as follows:--The electrlcal connections must be protected from dampness. - Page 3 SETUP OPERATING INSTRUCTIONS Motor 2-polc induction motor, 50Hz(n=2850r/min) 60Hz(n=3450r/min) Resin impregnated winding. Sized for connection to the pump according to NEMA standards. Standard voltages:-Single-phase 220V-240V,with thermal protector;-Three-phase 380V-415V;-Other voltages and frequency on request. Inulation class:4",5"6"motor:B grade.Protection: Ip58 Control box Single-phase:general start control box or auto-control box. Three-phase:general motor protector. Coupling Screwed couple:ISO228.
-
Page 4: Troubleshooting And Maintenance
TROUBLESHOOTING & MAINTENANCE TROUBLESHOOTING problem cause remedy no electricity The pump does not deliver: THE MOTOR Plug not inserted correctly DOES NOT START Automatic switch tripped Fuses bumt out(three-phase pump) Automatically resets a er the motor Overload protection tripped has cooled(single-phase version) The micro-circuit breaker resets Amperometric protection tripped automatically. -
Page 5: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79961/79962/79963/79964 DEEP WELL PUMP Complies with the essential health and safety requirements of the following Directices: Directive 2006/42/EC Standards and technical specifications referred to:... - Page 6 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
