- Page 1 79974 SELF-PRIMING JET PUMP INSTRUCTION MANUAL 220-240V~50Hz 750W SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Fluid Type
SAFETY WARNING Before start-up, note the following The Pump must be connected to a Ground Fault Circuit Interrupter (GFCI) protected plug which has been installed according to regulations. The plug must have a supply voltage of 220-240 VAC at 5 0 Hz. CAUTION This Pump has been evaluated for use with water only. -
Page 3: Specifications & Setup
SPECIFICATIONS & SETUP Compressor use and care SPECIFICATIONS Horsepower Maximum Suction Rated current Maximum Delivery Height 750W Electrical Rating Discharge Port 1" 220-240 VAC / 50 Hz Maximum Flow Power Cord Length 0.3m 60L/min Components Discharge Priming inlet Intake Drain plug Compressor use and care INSTALLATION The Pump must be installed in a stationary position with a fixed pipeline and a steady water supply. -
Page 4: Installation Instructions
SETUP Installation Instructions This Pump is designed for use as a well pump. WARNING! TO PREVENT SERIOUS INJURY FROM ELECTRIC SHOCK: Install indoors or in weather-proof well house only. This Pump is non-submersible. Do not plug in the power cord when wet or standing on damp or wet ground. Do not plug in the power cord until instructed to do so. -
Page 5: Operation
MAINTENANCE OPERATION A er reading these instructions, consider the following points before starting the Pump: 1. Before starting the Pump for the first time, prime it as follows: a. Fill the suction Pipe and Pump Body through the Priming Inlet. b. -
Page 6: Troubleshoot
TROUBLESHOOT problem possible causes Likely Solutions The Pump 1. No power. 1. Check connections, and breaker/fuse. won’t start 2. Thermal Protection cut out. 2. Allow Pump to cool. 3.Blocked impeller. 3. Free the impeller. The Pump 1. Pump not primed. 1. -
Page 7: Please Read The Following Carefully
Please read the following carefully THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
