Summary of Contents for Jabra Evolve 65

  • Page 1 Jabra Evolve 65 User manual...
  • Page 2 ® © 2014 GN Audio A/S. All rights reserved. Jabra is a trademark ® of GN Audio A/S . The Bluetooth word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by GN Audio A/S is under license.
  • Page 3 4. How to charge the battery ..11 4.1 Sleep mode 5. How to connect ......13 5.1 Connect to PC (using Jabra Link 380/390) 5.2 Connect to mobile device (using Bluetooth) 5.3 Connect to PC (using USB cable) 6. How to use ......... 16 6.1 Everyday use...
  • Page 4 7. Software and firmware .... 21 7.1 Jabra Direct 7.2 Update firmware 8. Support ........22 8.1 FAQ 8.2 How to care for your headset 9. Technical specifications ... 23...
  • Page 5 1. Welcome Thank you for using the Jabra Evolve 65. We hope you will enjoy it! Jabra Evolve 65 features ƒ Connects to PC via Jabra Link 380/390 bluetooth adapter or USB cable ƒ Connects to mobile devices via Bluetooth ƒ...
  • Page 6 2. Jabra Evolve 65 overview 2.1 Stereo variant Magnetic microphone groove Adjustable headband Volume up Busylight indicator Multi-function button Volume down USB connect & Battery charging port indicator Microphone boom-arm Bluetooth On/off/connect switch indicator...
  • Page 7 Adjustable headband Volume up Busylight indicator Multi-function button Volume down USB connect & Battery charging port indicator Microphone boom-arm Bluetooth indicator On/off/connect switch 2.3 Included accessories (stereo and mono) Jabra Link 380/390 Travel pouch USB cable USB-A Bluetooth adapter...

  • Page 8: How To Wear

    3. How to wear 3.1 Left or right wearing style The Jabra Evolve 65 can be worn on the left or right by flipping the microphone to the other side (270° limit). To prevent damaging or breaking the microphone, do not rotate it more than 270°.

  • Page 9: Adjust The Headband

    3.2 Adjust the headband Adjust the headband to find the most comfortable fit. 3.3 Position the microphone It is recommended to position the microphone close to your mouth (0.5 inches).
  • Page 10 The microphone is bendable for personal preference. 3.4 Storing the microphone When listening to music or outdoors, the microphone can be magnetically stored in the headband groove.
  • Page 11 4. How to charge the battery headset battery will charge when connected to a PC using a USB cable, or when using any USB charger supplied with your mobile device. The headset can still be used for calls while charging using a USB cable connected to a PC. It takes approx.

  • Page 12: Sleep Mode

    After 24 hours of sleep mode, the headset will power down completely. To power the headset back on, slide the On/off/connect switch from On to Off, and then back to On. Sleep mode is enabled by default, and can be disabled using Jabra Direct.

  • Page 13: How To Connect

    5. How to connect 5.1 Connect to PC (using Jabra Link 380/390) 1. Ensure the headset is switched on. 2. Plug the Jabra Link 380/390 dongle into a USB port on your PC. The headset and Jabra Link 380/390 are already pre-connected.

  • Page 14: Connect To Mobile Device

    5.2 Connect to mobile device (using Bluetooth) 1. Wear the headset. 2. Hold (3 secs) the On/off/connect switch in the connect position until you hear the voice guided instructions. The Bluetooth indicator will flash blue. 3. Follow the voice guided instructions to connect.
  • Page 15 5.3 Connect to PC (using USB cable) 1. Ensure the headset is switched on. 2. Plug the headset into a USB port on your PC using the supplied USB cable.

  • Page 16: How To Use

    6. How to use Volume up Busylight indicator Multi-function button Volume down USB connect & Battery charging port indicator Bluetooth indicator On/off/connect switch...

  • Page 17: Everyday Use

    6.1 Everyday use Function Action Slide the On/off/connect Headset on/off switch Tap the Multi-function Answer/end call button Double-tap the Multi- Reject call function button Battery and Tap the Multi-function connection button when not on a call status Press and hold the Enable/disable Multi-function button while Voice prompts...

  • Page 18: Multiple Call Handling

    6.2 Multiple call handling The headset can accept and handle multiple calls at the same time. Function Action End current call and Tap the answer incoming call Multi-function button Press and hold Switch between held (2 secs) the call and active call* Multi-function button Press and hold...
  • Page 19 6.3 Busylight The busylight indicator on the headset can be turned on to let others know that you are busy. MANUALLY TURN BUSYLIGHT ON/OFF To manually turn the busylight on/off, tap both the Volume up and Volume down buttons at the same time.
  • Page 20 6.4 Using the travel pouch When transporting the headset from location to location, it is recommended to use the travel pouch to prevent damaging the headset. The earcups can only be rotated in one direction. To prevent breaking the headset, do not rotate the earcups in the opposite direction.

  • Page 21: Software And Firmware

    Download the latest free version from jabra.com/direct 7.2 Update firmware Firmware updates improve performance or add new functionality to Jabra devices. 1. Connect the Jabra Evolve 65 to a computer. 2. Use Jabra Direct to check for the latest firmware updates.
  • Page 22 8. Support 8.1 FAQ View the FAQs on Jabra.com/evolve65 8.2 How to care for your headset ƒ Always store the headset with the power off and safely protected. ƒ Avoid storage at extreme temperatures (above 55°C/131°F or below -10°C/14°F). This can shorten battery life and may adversely affect the headset.
  • Page 23 9. Technical specifications Jabra Evolve 65 headset Specification Mono headset: 79 g Headset weight: Stereo headset: 111 g Mono headset: L 154.4 mm x W 58.6 mm x H 170.4 mm Headset dimensions: Stereo headset: L 155.5 mm x W 58.6 mm x H 170.5 mm...
  • Page 24 BLUETOOTH ADAPTER SPECIFICATION (JABRA LINK 380/390) PC connection: USB 2.0 Bluetooth version: Bluetooth range: Up to 30m (100 feet), Class 1 A2DP (v1.2), Hands free profile Bluetooth profiles: (v1.6) Simultaneous Bluetooth connections: Bluetooth audio bandwidth HD voice (wideband), A2DP Visual indicators:...
  • Page 25 jabra.com/evolve65...
