Legacy™ Line
558J 17-30
Single Package Rooftop with Cooling Only
Vertical Air Flow Unit with Puron
558J units for installation in the United States contain use of Bryant's 2-speed indoor fan control system.
This complies with the U.S. Department of Energy (DOE) efficiency standard of 2018.
558J units for installation outside the United States may or may not contain use of the 2-speed indoor fan
control system as they are not required to comply with the U.S. Department of Energy (DOE) efficiency
standard of 2018.
For specific details on operation of the Bryant 2-speed indoor fan system refer to the Variable Frequency
Drive (VFD) Factory-Installed Option 2-Speed Motor Control Installation, Setup, and Troubleshooting
manual.
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . 1
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rated Indoor Airflow (cfm) . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Job-Site Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Step 1 - Plan for Unit Location . . . . . . . . . . . . . . . . . . 16
Step 3 - Inspect Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Step 4 - Provide Unit Support . . . . . . . . . . . . . . . . . . . 16
Step 5 - Field Fabricate Ductwork . . . . . . . . . . . . . . . 21
Step 6 - Rig and Place Unit . . . . . . . . . . . . . . . . . . . . . 21
Step 8 - Assemble Barometric Hood . . . . . . . . . . . . . . 23
Step 10 - Make Electrical Connections . . . . . . . . . . . 25
DISCONNECT
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53558013-01
®
Installation Instructions
Page
Printed in U.S.A.
Form II558J-17-30-V-03
(R-410A) Refrigerant
RTU Open Control System . . . . . . . . . . . . . . . . . . . . . . . 45
Smoke Detectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Step 12 - Install Accessories . . . . . . . . . . . . . . . . . . . . . 49
Step 13 - Check Belt Tension . . . . . . . . . . . . . . . . . . . . 49
Pre-Start and Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . 50
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . . CL-1

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can be
hazardous due to system pressure and electrical components.
Only trained and qualified service personnel should install,
repair, or service air-conditioning equipment.
Untrained personnel can perform basic maintenance functions
of cleaning coils and filters and replacing filters. All other
operations should be performed by trained service personnel.
When working on air-conditioning equipment, observe
precautions in the literature, tags and labels attached to the
unit, and other safety precautions that may apply.
Follow all safety codes. Wear safety glasses and work gloves.
Use quenching cloth for unbrazing operations. Have fire
extinguisher available for all brazing operations.
It is important to recognize safety information. This is the
safety-alert symbol
and in instructions or manuals, be alert to the potential for
personal injury.
Pg 1
. When you see this symbol on the unit
7-21
Replaces: II558J-17-30-V-02
