User's manual

What's in the box

Your telephone package contains the following items.

Save your sales receipt and original packaging in the

event warranty service is necessary.

NOTE

• To purchase a replacement battery or power adapter,

visit our website at

www.vtechphones.com or call

1 (800) 595-9511. In Canada, go to

phones.vtechcanada.com/ or call

1 (800) 267-7377.

User's

manual

to register your product

(Canada) for latest

1 set for CS6114-2

CS6114-21

1 set for CS6114/CS6114-

11/CS6114-2/CS6114-21/

VA17141BK

DECT 6.0 cordless

For more support information

1 set for CS6114/CS6114-11/CS6114-2/

CS6114-21/ VA17141BK

1 set for CS6114/CS6114-11/

VA17141BK;

2 sets for CS6114-2/ CS6114-

CS6114

CS6114-11

CS6114-2

CS6114-21

VA17141BK

telephone

Need help?

Do you have a question about the CS6114 and is the answer not in the manual?

Questions and answers

Summary of Contents for VTech CS6114

Page 1 CS6114 Go to www.vtechphones.com to register your product for enhanced warranty support and latest VTech CS6114-11 product news. phones.vtechcanada.com Go to (Canada) for latest CS6114-2 VTech product news. CS6114-21 VA17141BK DECT 6.0 cordless telephone For more support information User’s manual What’s in the box...
Page 2 Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: Read and understand all instructions. Follow all warnings and instructions marked on the product. CAUTION: Do not install the telephone base at a height above 2 meters.
Page 3 Precautions for users of implanted cardiac pacemakers Cardiac pacemakers (applies only to digital cordless telephones): Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S. Food and Drug Administration, WTR recommends to physicians that: Pacemaker patients •...
Page 4 • Answer an incoming call when you receive a call waiting alert. 5 – 1 • Press repeatedly to add or remove 1 in front of the caller ID log entry before dialing or saving it to the phonebook. 6 – TONE •...
Page 5 Telephone base overview 1 – /FIND HANDSET • Page all system handsets. 2 – Charging pole Charger overview 1 – Charging pole Display icons overview The battery icon flashes when the battery is low and needs charging. The battery icon animates when the battery is charging.
Page 6 wall switches. • The adapters are intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet. •...
Page 7 Install and charge the battery Install the battery Install the battery as shown below. THIS SIDE UP NOTES • Use only supplied battery. • Charge the battery provided with this product only in accordance with the instructions and limitations specified in this manual. •...
Page 8 • If you place the handset in the telephone base or the charger without plugging in the battery, the screen displays No battery. Battery Battery status Action indicators The screen The battery Charge without is blank, or has no or very interruption displays Put in little charge.
Page 9 If you do not hear a dial tone: • Make sure the installation procedures described above are properly done. • It may be a wiring problem. If you have changed your telephone service to digital service from a cable company or a VoIP service provider, the telephone line may need to be rewired to allow all existing telephone jacks to work.
Page 10 Handset returns to the previous menu, and you hear a confirmation tone. Dial mode The dial mode is preset to touch-tone dialing. If you have pulse (rotary) service, you need to change the dial mode to pulse dialing before using the telephone. Press MENU when the handset is not in use.
Page 11 Mute The mute function allows you to hear the other party but the other party cannot hear you. During a call, press MUTE. The handset displays Muted. Press MUTE again to resume the conversation. The handset displays Microphone on briefly. Join a call in progress You can use up to two system handsets at a time on an outside call.
Page 12 To access a number from the caller ID log while on a call: Press MENU and then press q or p to select Caller ID log. Press SELECT and then press q or p to scroll to the desired entry. Press SELECT to dial the displayed number.
Page 13 Press when the handset is not in use. Press REDIAL and then press q, p or REDIAL repeatedly until the desired entry displays. Press SELECT to dial. Delete a redial list entry Press REDIAL when the handset is not in use. Press q, p or REDIAL repeatedly to browse to the desired entry.
Page 14 Review a phonebook entry Entries are sorted alphabetically. Press when the phone is not in use. Press q or p to browse through the phonebook, or use the dialing keys to start a name search. -OR- Press MENU when the handset is not in use. Press q or p to scroll to Phonebook, and then press SELECT to choose.
Page 15 Caller ID If you subscribe to caller ID service, information about each caller appears after the first or second ring. If you answer a call before the caller information appears on the screen, it will not be saved in the caller ID log. The caller ID log stores up to 30 entries.
Page 16 Missed call indicator When there are calls that have not been reviewed in the caller ID log, the handset displays XX missed calls. Each time you review a caller ID log entry marked NEW, the number of missed calls decreases by one. When you have reviewed all the missed calls, the missed call indicator no longer displays.
Page 17 While entering names and numbers, you can: • Press DELETE to backspace and erase a digit or character. • Press and hold DELETE to erase all digits or the entire name. • Press q or p to move the cursor to the left or right. •...
Page 18 NOTE • If you turn off the ringer volume, you will not hear ringer tone samples. Ringer volume You can adjust the ringer volume level, or turn the ringer off. Press MENU when the handset is not in use. Press q or p to choose Ringers and then press SELECT.
Page 19 Clear the new voicemail indicators If you have retrieved your voicemail while away from home, and the handset still displays the new voicemail indicators, use this feature to clear the indicators. NOTE • This feature turns off the indicators only, it does not delete your voicemail messages.
Page 20 You have turned off the Muted handset microphone. The other party cannot hear you but you can hear the other party. There are new voicemail message(s) from your voicemail telephone service provider. You place the handset in No battery the telephone base or charger without installing a battery in it.
Page 21 For operations and guides to help you using your telephone, and for latest information and supports, go and check the online help topics and online FAQs. Use your smartphone or mobile device to access our online help. https:/ /help.vtechphones.com/cs6114 • Go to (US); OR phones.vtechcanada.com (Canada) •...
Page 22 VTech’s participation in RBRC makes it easy for you to drop off the spent battery at local retailers participating in the RBRC program or at authorized VTech product service centers.
Page 23 including interference that may cause undesired operation. Privacy of communications may not be ensured when using this telephone. To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product.
Page 24 What does this limited warranty cover? The manufacturer of this VTech product, VTech Communications, Inc. (“VTech”), warrants to the holder of a valid proof of purchase (“Consumer” or “you”) that the Product and all accessories provided by VTech in sales package (“Product”) are free from...
Page 25 Other limitations This warranty is the complete and exclusive agreement between you and VTech. It supersedes all other written or oral communications related to this product. VTech provides no other warranties for this product. The warranty exclusively describes all of VTech’s responsibilities regarding the product.
Page 26 VTech Communications, Inc. and its suppliers assume no responsibility for any damage or loss resulting from the use of this user’s manual. VTech Communications, Inc. and its suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this product.
Page 27 Disclaimer and Limitation of Liability VTech Communications, Inc. and its suppliers assume no responsibility for any damage or loss resulting from the use of this user’s manual. VTech Communications, Inc. and its suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this product.
