Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Wear eye
instructions
protection
1.
SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this product.
‰
Locate product in a suitable working area.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
Keep the product clean and tidy in accordance with good workshop practice.
9
Keep children and unauthorised persons away from the working area.
9
DO NOT use the product for any purpose other than that for which it is designed.
8
DO NOT exceed maximum capacity of product.
8
DO NOT use the product out of doors.
8
DO NOT get the product wet or use in damp or wet locations or areas where there is condensation.
8
DO NOT clean the product with any solvents which may damage the paint surface or the protective coating.
8
2.
INTRODUCTION
Wall mounting rack specifically designed for spray can storage. Shelf space for larger products and also a paper towel dispenser bar.
3.
SPECIFICATION
Model no:
Can Holder Diameter:
Can Holders:
Nett Weight:
Paper Towel Holder Width:
4.
CONTENTS
Part Code
A
B
C
D
E
F
© Jack Sealey Limited
SPRAY CAN STORAGE RACK WITH 8 CAN
HOLDERS
MODEL NO:
APSCR8
Ø70mm
8
3.85kg
375mm
Part Shape
Descriptions
Left stud
Right stud
Bottle holder
Shelf
Support plate
Paper towel
holder tube
Original Language Version
APSCR8
Qty
Part Code
Part Shape
1
G
1
H
2
I
2
J
1
K
1
L
Descriptions
Qty
Connecting
2
piece
Plastic cap
2
M6 Bolt & Nut
20
Mini hook
4
M4.8*50.8mm
4
Mounting
screw
Plastic Anchor
4
APSCR8 Issue 1 04/10/24
Advertisement
Related Manuals for Sealey APSCR8
Summary of Contents for Sealey APSCR8
- Page 1 APSCR8 MODEL NO: Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions, and properly maintained, give you years of trouble free performance. IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED.
- Page 2 Step 1. Attach shelf to the left and right stud using the M6 nuts and Step 2. Attach the top bottle holder to the left and right stud using bolts. the M6 nuts and bolts. APSCR8 Issue 1 04/10/24 Original Language Version © Jack Sealey Limited...
- Page 3 Step 8. Place spray can storage rack up against the wall. Use a illustration. spirit level to ensure it is level, using a pencil mark the wall as shown in the illustration. Original Language Version APSCR8 Issue 1 04/10/24 © Jack Sealey Limited...
- Page 4 IMPORTANT: No Liability is accepted for incorrect use of this product. WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim. Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR 01284 757500 sales@sealey.co.uk...
