YARDMAX YG4761-YF1320 Operator's Manual

24 in. electric start rwd 3-in-1 mower w/ blower
Hide thumbs

Advertisement

Quick Links

Download this manual
24 in. Electric Start RWD 3-in-1 Mower w/ Blower
Model YG4761-YF1320
24 in. Electric Start RWD 3-in-1 Mower without
Blower Model YG4761
Operator's Manual
SERIAL NUMBER
Both model numbers and
serial numbers may be found
on the main label. (See Page
PURCHASE DATE
2, Figure 1) You should record
both of them in a safe place for
future use.
Save This Manual for Future Reference
Read and understand the entire
DANGER
manual before operating the
machine. failure to comply with
WARNING
the safety instructions in the
manual may result in personal
CAUTION
injury.
NOTE
Tame the Great Outdoors
®
