24 in. RWD 3-in-1 Gas Walk Behind Self-Propelled
Lawn Mower
Operator's Manual
MODEL NUMBER
YG4760
SERIAL NUMBER
PURCHASE DATE
Both model numbers and serial
numbers may be found on the
main label.
(See Page 2, Figure 1)
You should record both of them
in a safe place for future use.
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING THE MACHINE.
FAILURE TO COMPLY WITH THE SAFETY INSTRUCTIONS IN THE MANUAL MAY RESULT IN
DANGER
WARNING
CAUTION
NOTE
PERSONAL INJURY.
Save This Manual for Future Reference
Tame the Great Outdoors
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for YARDMAX YG4760
Summary of Contents for YARDMAX YG4760
- Page 1 Save This Manual for Future Reference 24 in. RWD 3-in-1 Gas Walk Behind Self-Propelled Lawn Mower Operator’s Manual MODEL NUMBER YG4760 SERIAL NUMBER PURCHASE DATE Both model numbers and serial numbers may be found on the main label. (See Page 2, Figure 1) You should record both of them in a safe place for future use.
-
Page 2: Table Of Contents
YARDMAX delivers the perfect combination of Up for the job? YARDMAX is. performance and practicality. An Outdoor Power Equipment (OPE) to get the job done right, at the right price. YARDMAX has a solution that’s right for you. TABLE OF CONTENTS Introduction Know Your Machine... -
Page 3: Engine Manual
DISCLAIMER engine manufacturer's service center. DANGER YARDMAX reserves the right to discontinue, change, and improve its products at any time without notice CALIFORNIA PROPOSITION WARNING or obligation to the purchaser. The descriptions and... - Page 4 SUPPORT Have questions about your YARDMAX equipment? Call us at 847-327-0566 or 844-YARDMAX, email us at support@yardmax.com, or contact us via your favorite social media site. Introduction...
-
Page 5: Specifications
Walk-Behind Self Propelled Lawn Mower Operator’s Manual » YG4760 SPECIFICATIONS Model # YG4760 Mower Type Self-Propelled, RWD Cutting Options Bag, Mulch, Rear Discharge Cutting Width 24" Max. Cutting Height 3.74" Min. Cutting Height 1.57" Cutting Height Options 7 positions Deck Material... -
Page 6: Symbols
SYMBOLS The rating plate on your machine may show symbols. These represent important information about the product or instructions on its use. DANGER Always stop the engine before refueling. WARNING CAUTION Gasoline and its vapors are extremely MAX.15° flammable and explosive. Never fuel FAST the machine indoors or while the engine is hot or running. -
Page 7: Safety
Walk-Behind Self Propelled Lawn Mower Operator’s Manual » SAFETY The definitions below give the level of severity for each signal word. DANGER This symbol points out safety T h i s s y m b o l p o i n t s o u t DANGER WARNING instructions. -
Page 8: Engine Safety
alcohol, or any medication that could affect your ability to use it the noise level and the risk of fire. Examine the muffler regularly properly. to make sure that it is attached correctly and not damaged. Wear sturdy, rough-soled work shoes and close-fitting slacks and Muffler and engine become hot and can cause burns. -
Page 9: Specific Safety Rules
Walk-Behind Self Propelled Lawn Mower Operator’s Manual » Store fuel in a cool, well-ventilated area, safely away from sparks, damages that our product causes if: open flames, or other sources of ignition. • remove the product is incorrectly repaired. Never store fuel or a machine with fuel in the tank inside a •... -
Page 10: Slope Operation
If the equipment should start to vibrate abnormally, stop Be careful when you go near hidden corners and objects that can the engine and check immediately for the cause. Vibration is prevent your view. generally a warning of trouble. Maintain a high level of caution when you reverse or pull the This manual cannot include all situations that can occur when product in your direction. -
Page 11: Contents Supplied
Walk-Behind Self Propelled Lawn Mower Operator’s Manual » CONTENTS SUPPLIED Your YARDMAX lawn mower contains the following: Premium 4-Cycle NET CONTENTS 17 OZ (0.5 L) 1. Main Machine 4. Operator's Manual and Engine Manual 2. Grass Catcher 5. Funnel 3. Product Adapter 6. -
Page 12: Assembly
ASSEMBLY This lawn mower comes assembled and only needs simple unfolding and fastening. Follow the below instructions: DANGER HANDLEBARS WARNING 1. Slowly move the folded handlebars back to the working position. (See Figure 2, illustration 1) 2. Unlocking the knobs, attached the short studs into any one of the three holes in the handle bracket. (See Figure 2, illustration 2) CAUTION The three holes in the handle bracket are for three different handle heights. -
Page 13: Grass Catcher
Walk-Behind Self Propelled Lawn Mower Operator’s Manual » ENGINE STARTER POSITIONING 1. Hold the engine start/stop control lever against the upper handle. (See Figure 3, Illustration 1) 2. Slowly pull the starter rope handle from the engine and slip the starter rope into the rope guide. -
Page 14: Know Your Machine
KNOW YOUR MACHINE FEATURES AND CONTROLS Engine Start/Stop Control Drive Control Lever Speed Control Lever Recoil Starter Upper Handle Grass Catcher Lower Connecting Handlebar Fuel Cap Cutting Height Adjustment Lever Rear Wheel Front Wheel Know Your Machine... - Page 15 Walk-Behind Self Propelled Lawn Mower Operator’s Manual » Engine Start/Stop Control Grass Catcher The engine start/stop control is attached to the upper Use the grass catcher to collect the grass clippings handle of the mower. Depress and squeeze it against while you are operating the mower.
-
Page 16: Operation
DANGER WARNING OPERATION CAUTION 1. The engine must be off and allowed to cool at least three minutes This unit is shipped without NOTE before adding fuel. gasoline or oil in the engine. 2. Remove the fuel filler cap and fill the tank. (See engine manual DANGER Be certain to service the engine with gasoline and oil for fuel capacity, fuel recommendation, and location of the fuel... - Page 17 Walk-Behind Self Propelled Lawn Mower Operator’s Manual » DANGER Rapid retraction of the starter WARNING cord (kickback) will pull your hand and arm toward the engine faster than you can CAUTION let go. Broken bones, fractures, bruises, or sprains NOTE could result.
- Page 18 3 HANDLE HEIGHTS ADJUSTABLE • The rear discharging mode of your product is the best cutting mode. If you try to cut a large quantity of grass and the product The three holes in the handle bracket are for three different handle does not operate correctly, or has decreased operation time, heights.
-
Page 19: Stopping The Machine
Walk-Behind Self Propelled Lawn Mower Operator’s Manual » STOPPING THE MACHINE Release the engine start/stop control lever to stop the engine and blade. (See Figure 17) DANGER Wait for the blade to stop WARNING completely before performing any work on the mower. CAUTION NOTE Support Stud... -
Page 20: Maintenance Schedule
MAINTENANCE DANGER MAINTENANCE SCHEDULE A l w a y s s t o p t h e e n g i n e , WARNING In the maintenance schedule, you can see which parts of your allow the engine to cool, machine require maintenance, and at which intervals it should take disconnect spark plug, and ground against the engine CAUTION... - Page 21 Walk-Behind Self Propelled Lawn Mower Operator’s Manual » 2. The transmission is pre-lubricated and sealed at the factory and does not require lubrication. Quick Coupler (User Supplied) 3. Follow the Engine Operator’s Manual for lubrication schedule and instructions for engine lubrication. Garden Hose DECK WASH Your mower’s deck is equipped with a female adapter on its surface...
-
Page 22: Changing The Engine Oil
DANGER • Clean spark plugs and reset the gap once a season. Spark plug Always keep the air filter WARNING replacement is recommended at the start of each mowing and carburetor facing up season. Check Engine Operator’s Manual for correct plug type and gap specifications. -
Page 23: Blade Care
Walk-Behind Self Propelled Lawn Mower Operator’s Manual » 4. Tip the machine onto its side (so that the air filter is up) to drain 11. Install the dipstick into the oil-fill tube securely. the used oil from the oil-fill tube. (See Figure 25) 12. -
Page 24: Drive Control Adjustment
DANGER WARNING DANGER DANGER Always keep the air filter Use only a replacement WARNING CAUTION WARNING and carburetor facing up b l a d e a p p r o v e d b y t h e whenever needed to tip the machine onto its side. CAUTION manufacturer of your mower. -
Page 25: Belt Replacement
Walk-Behind Self Propelled Lawn Mower Operator’s Manual » ENGINE START/STOP CONTROL ADJUSTMENT BELT REPLACEMENT When depress the engine start/stop lever against the upper handle, and pull the recoil starter several times, the engine doesn't start, you must tighten the engine start/stop control cable. See the below CABLE ADJUSTMENT section. -
Page 26: Replace The Wheel
3. Assemble the new wheel with wheel nut. (See Figure 37) Front Wheel DANGER Figure 37 WARNING Figure 34 Make ensure the inner gear CAUTION ring of the wheel and the gear 5. Remove the belt. (See Figure 35) of the wheel guard are meshed in place. NOTE 4. -
Page 27: Troubleshooting
DANGER Walk-Behind Self Propelled Lawn Mower Operator’s Manual » WARNING DANGER CAUTION When loading or moving the product, do not go more than the WARNING Refer to Engine Operator’s NOTE maximum recommended operation angle of 15 degrees. Manual for the correct engine Empty the fuel tank by operating the product until the tank is empty. - Page 28 Problem Cause Remedy Air filter, carburetor and spark plug Hard to start or Replace air filter. Clean carburetor and polluted by oil and gas spilled from blowing white smoke spark plug. tipping on the incorrect side. 1. Connect and tighten the spark plug boot. 2.
-
Page 29: Parts Diagram
Walk-Behind Self Propelled Lawn Mower Operator’s Manual » PARTS DIAGRAM Parts Diagram... - Page 30 YG4760 PARTS LIST Description Description Lock Nut M10 Height Adjustment Connecting Rod Wheel Retaining Ring 12 Front Wheel Axle Left Gear Cutting Deck Ball Bearing R8ZZ Hexagon Head Self-tapping Screw Sealing O-Ring ST6.3x19C Shaft Bushing Cross Recessed Tapping Screw Waveform Elastic Washer ST4.8x19C...
- Page 31 Walk-Behind Self Propelled Lawn Mower Operator’s Manual » Description Description Engine Start Cable+Stop Control Transmission Box Protection Plate 2 Cable Cross Recessed Tapping Screw Screw ST6.3x25 Right Torsion Spring Cap Nut Rear Discharge Cover Drive Control Lever Rear Cover Shaft Engine Start/Stop Control Lever Right Handle Bracket Upper Handle...
- Page 32 Tame the Great Outdoors ® 847-327-0566 or 844-YARDMAX | support@yardmax.com...
