AP45 Hardware Installation Guide

Overview

The AP45 contains four IEEE 802.11ax radios that deliver 4x4 MIMO with

four spatial streams when operating in multi-user (MU) or single-user (SU)

mode. The AP45 is capable of operating simultaneously in the 6GHz band,

5GHz band, and 2.4GHz band along with a dedicated tri-band scan radio.

AP45 Hardware Installation Guide

Juniper Business Use Only

Need help?

Do you have a question about the AP45 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Juniper AP45 Series

Page 1 The AP45 is capable of operating simultaneously in the 6GHz band, 5GHz band, and 2.4GHz band along with a dedicated tri-band scan radio. Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 2 100/1000/2500/5000BASE-T RJ45 interface that supports Eth0+PoE-in 802.3at/802.3bt PoE PD 10/100/1000BASE-T RJ45 interface + 802.3af PSE (if PoE- Eth1+PSE-out in is 802.3bt) USB2.0 support interface Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 4 In a wall mount installation, please use screws that have a 1/4in. (6.3mm) diameter head with a length at least 2 in. (50.8mm). APBR-U that is in the AP45(E) box includes a set screw and an eyehook. Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 9 The threaded rod adapter attaches to a rod that is either 1/2"-13, 5/8”-11, or M16-2. Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 10 Suitable for use in environmental air space in accordance with Section 300-22(C) of the National Electrical Code, and Sections 2-128, 12-010(3), and 12-100 of the Canadian Electrical Code, Part 1, CSA C22.1. Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 11 Adapter for channel rail and recessed 9/16” t-rail APBR-ADP-CR9 Adapter for recessed 15/16" t-rail APBR-ADP-RT15 Adapter for recessed 1.5" t-rail APBR-ADP-WS15 Power Supply options 802.3at or 802.3bt PoE power Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 12 LAN connections as defined by the 802.3at Standard. Operations in the 5.15GHz – 5.35GHz band are restricted to indoor usage only. If you need further assistance with purchasing the power source, please contact Juniper Networks, Inc. Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023.
Page 13 ● The 5.925 ~ 7.125GHz operation of this device is prohibited on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet. Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 14 ● Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or Communications with unmanned aircraft systems. Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 16 AP45 PIFA Juniper AP45 PIFA Note1 Juniper AP45 PIFA AP45, AP45E AccelTex ATS-OO-2456-466-10MC-36 OMNI AccelTex ATS-OP-2456-81010-10MC-36 Panel AP45E AccelTex ATS-OO-2456-466-10MC-36 OMNI AccelTex ATS-OP-2456-81010-10MC-36 Panel Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 17 (v) Utilisation interdite à bord de plateformes de forage pétrolier, de voitures, de trains, de bateaux et d’aéronefs, sauf à bord d’un gros aéronef volant à plus de 10 000 pieds d’altitude. Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 18 Cet équipement doit être installé et utilisé avec un minimum de 24cm (AP45), 34cm (AP45E) de distance entre la source de rayonnement et votre corps. Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
Page 19 Hereby, Juniper Networks, Inc. declares that the radio equipment types (AP45, AP45E) are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following: https://www.mist.com/support/ The frequency and maximum transmitted Power in EU:...
Page 20 Hereby, Juniper Networks, Inc. declares that the radio equipment types (AP45, AP45E) are in compliance with Radio Equipment Regulations 2017. The full text of the UK declaration of conformity is available at the following: https://www.mist.com/support/ The frequency and maximum transmitted Power in UK:...
Page 21 Paraguay En Paraguay, este equipo deberá ser configurado para operar con las limitaciones establecidas en la Norma Técnica NTC-RF-5925:2025 de la CONATEL Juniper Business Use Only AP45 Hardware Installation Guide Juniper Networks (C) Copyright 2021-2023. All Rights Reserved...
