- Page 1 EN User Manual | Dishwasher FSB73427Z aeg.com\register...
- Page 2 INSTALLATION min.550 820-900 645-720 818-898 max. 1200 645-776 max 5 mm How to install your AEG/Electrolux www.youtube.com/electrolux www.youtube.com/aeg 45 cm dishwasher...
-
Page 3: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................3 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................7 4. CONTROL PANEL..................7 5. -
Page 4: General Safety
• Children should be supervised to ensure that they do not play with the appliance. • Keep detergents away from children. • Keep children and pets away from the appliance when the door is open. • Children shall not carry out cleaning and user maintenance of the appliance without supervision. -
Page 5: Safety Instructions
• The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused. 2. SAFETY INSTRUCTIONS 2.1 Installation • Always use a correctly installed shockproof socket. • Do not use multi-plug adapters and WARNING! extension cables. - Page 6 2.4 Use sensors, software and firmware including reset software. The following spare parts • Do not put flammable products or items are available for at least 10 years after the that are wet with flammable products in, model has been discontinued: door hinge near or on the appliance.
-
Page 7: Product Description
3. PRODUCT DESCRIPTION Rinse aid dispenser Detergent dispenser Cutlery basket Lower basket Upper basket 3.1 Beam-on-Floor Beam-on-Floor is a light that is displayed on the floor below the appliance door. It is off when the appliance is deactivated. 10 9 •... -
Page 8: Indicators On The Display
4.2 Indicators on the display Indicator Description Rinse aid indicator. It is on when the rinse aid dispenser needs refilling. Refer to Before first use. Salt indicator. It is on when the salt container needs refilling. Refer to Before first use. Machine Care indicator. - Page 9 5.4 Programmes overview Programme Dishwasher Degree of Programme phases EXTRAS load soil Quick Crockery, cutlery Fresh • Dishwashing 50 °C • ExtraPower • Intermediate rinse • GlassCare • Final rinse 50 °C • AirDry Crockery, cutlery Fresh, lightly • Dishwashing 60 °C •...
-
Page 10: Consumption Values
Consumption values Water (l) Energy (kWh) Duration (min) Programme 1)2) Quick 0.604 0.697 1h 30min 0.826 2h 40min 0.948 0.628 AUTO Sense 0.952 Machine Care 0.440 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values. -
Page 11: Setting Mode
• The display shows the current setting value. 2. Press OK to enter the setting. • The bar of the ECOMETER dedicated to the chosen setting is on. The other bars are off. • The current setting value flashes. 6.1 Setting mode 3. -
Page 12: The Rinse Aid Level
Water hardness German de‐ French de‐ mmol/l mg/l (ppm) Clarke de‐ Water softener grees (°dH) grees (°fH) grees level 47 - 50 84 - 90 8.4 - 9.0 835 - 904 58 - 63 43 - 46 76 - 83 7.6 - 8.3 755 - 834 53 - 57... -
Page 13: Key Tones
6.5 AirDry CAUTION! AirDry improves the drying results. The If children have access to the appliance, appliance door opens automatically during we advise to deactivate AirDry. The the drying phase and remains ajar. automatic opening of the door may pose AirDry is automatically activated with all a danger. -
Page 14: Daily Use
CAUTION! The compartment (C) is for rinse aid only. Do not fill it with detergent. CAUTION! Only use rinse aid designed specifically for dishwashers. 6. Turn the cap clockwise to close the salt container. 1. Press the release element (A) to open the lid (B). -
Page 15: How To Delay The Start Of A Programme
1. Select a programme using MY TIME CAUTION! selection bar. 2. Press the button dedicated to the option Only use detergent designed specifically you want to activate. for dishwashers. • The light related to the button is on. 1. Press the release button (B) to open the •... -
Page 16: Opening The Door While The Appliance Operates
If the door is opened for more than 30 seconds during the drying phase, the running programme ends. It does not happen if the If you cancel the delay start, you have to door is opened by AirDry function. select the programme again. 8.9 Auto Off function 8.7 How to cancel a running programme... -
Page 17: Using Salt, Rinse Aid And Detergent
9.2 Using salt, rinse aid and 9.4 Before starting a programme detergent Before you start the selected programme, make sure that: • Only use salt, rinse aid and detergent designed for dishwasher. Other products • The filters are clean and correctly can cause damage to the appliance. -
Page 18: Care And Cleaning
After the programme is completed, water can still remain on the inside surfaces of the appliance. 10. CARE AND CLEANING 10.2 Internal cleaning WARNING! • Clean the appliance interior with a soft Before any maintenance other than damp cloth. running the programme Machine Care, •... -
Page 19: Cleaning The Filters
10.5 Cleaning the filters The filter system is made of 3 parts. 7. Reassemble the filters (B) and (C). 8. Put back the filter (B) in the flat filter (A). Turn it clockwise until it locks. 1. Turn the filter (B) counterclockwise and remove it. -
Page 20: Troubleshooting
3. Wash the spray arm under running water. Use a thin pointed tool, e.g. a toothpick, to remove particles of soil from the holes. Run water through the holes to wash soil particles away from the inside. 4. To install the spray arm back, insert the mounting element in the spray arm and fix it in the duct by turning it counterclockwise. - Page 21 Problem and alarm code Possible cause and solution The appliance does not fill with wa‐ • Make sure that the water tap is open. ter. • Make sure that the pressure of the water supply is not too low. For this The display shows i10 or i11.
- Page 22 Problem and alarm code Possible cause and solution Small leak from the appliance door. • The appliance is not levelled. Loosen or tighten the adjustable feet (if applicable). • The appliance door is not centred on the tub. Adjust the rear foot (if ap‐ plicable).
- Page 23 Problem Possible cause and solution Whitish streaks or bluish • The released quantity of rinse aid is too high. Adjust the dosage to a lower level. layers on glasses and • The quantity of detergent is too high. dishes. Stains and dry water •...
-
Page 24: Technical Data
12. TECHNICAL DATA Dimensions Width / height / depth (mm) 446 / 818 - 898 / 550 Voltage (V) 220 - 240 Electrical connection Frequency (Hz) Water supply pressure Min. / max. MPa (bar) 0.05 (0.5) / 1 (10) Water supply min. - Page 28 156829810-A-352024...
