- Page 1 Dell PowerVault MD3460/3860i/3860f Storage Arrays Getting Started Guide Regulatory Model: E08J Series Regulatory Type: E08J001 https://manual-hub.com/...
-
Page 2: Notes, Cautions, And Warnings
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. © 2013 Dell Inc. All Rights Reserved. ™ ™... -
Page 3: Installation And Configuration
(43.0 lb) and when fully populated with all the physical disks is 105.20 kg (232.0 lb). WARNING: Your system must be installed by Dell certified service technicians. For safe installation of an empty system, a minimum of three service technicians are required. To install a fully populated system, a mechanized lifting tool is required to position the system in a rack. - Page 4 Opening And Closing The Disk Drawer Figure 2. Opening and Closing the Disk Drawer Open the disk drawer to install or remove the physical disk carrier(s). NOTE: You can open only one disk drawer at a time. Forcing to open more than one drawer at a time may damage the assembly or produce unexpected results.
-
Page 5: Connecting The Power Cables
Connecting The Power Cable(s) Figure 4. Connecting the Power Cable(s) Connect the system’s power cable(s) to the system. Securing The Power Cable(s) Figure 5. Securing the Power Cable(s) Open the cable retention bracket by pulling the tabs on its sides, insert the cable, and secure the system power cable, as shown in the illustration. -
Page 6: Turning On The System
Install the bezel as shown in the figure. Dell Software License Agreement Before using your system, read the Dell Software License Agreement that came with your system. You must consider any media of Dell-installed software as BACKUP copies of the software installed on your system’s hard drive. -
Page 7: Other Information You May Need
NOTE: Always check for updates on dell.com/support/manuals and read the updates first because they often supersede information in other documents. - Page 8 950 m or 3117 ft) on the equipment NOTE: For information on supported expanded operating temperature range and configurations, see the Owner's Manual dell.com/support/ manuals. Humidity Percentage Range 10% to 80% Relative Humidity with 26 °C (78.8 °F) maximum dew point.
- Page 9 Environmental Maximum shock Operating One shock pulse in the positive z axis (one pulse on each side of the system) of 31 G for 2.6 m in the operational orientation. Storage Six consecutively executed shock pulses in the positive and negative x, y, and z axes (one pulse on each side of the system) of 71 G for up to 2 m.
- Page 10 Environmental NOTE: Applies to data center and non-data center environments. Gaseous Contamination NOTE: Maximum corrosive contaminant levels measured at ≤50% relative humidity Copper Coupon Corrosion Rate <300 Å/month per Class G1 as defined by ANSI/ ISA71.04-1985. Silver Coupon Corrosion Rate <200 Å/month as defined by AHSRAE TC9.9.
