- Page 1 VERVE 2, 3 GEN 5 SERVICE MANUAL...
- Page 2 Verve 2, 3 Gen 5 Contents About this manual Brake/shift routing Rear derailleur Headset Copyright 2024 Trek Bicycle Corporation All Rights Reserved...
-
Page 3: About This Manual
It does not contain instructions for all components (such as brake calipers). Refer to the original manufacturer for more information. Torque value Replacement parts Trek recommends using only Trek OEM (original manufacturer) replacement parts. Apply appropriate threadlocker Additional info The Owner’s Manual is available at Trekbikes.com/manuals. - Page 4 Verve 2, 3 Gen 5 Brake/shift routing 4 Nm Housing sleeves — W528082 Front brake hose Cable stop — W519905 Rear brake hose Fasteners (M5 x 8 mm) — W549307 Rear derailleur housing Front derailleur housing Front derailleur cable...
-
Page 5: Rear Derailleur
Verve 2, 3 Gen 5 Rear derailleur 5 Nm Fasteners (M5 x 9 mm) — W300580 Rear derailleur hanger — W322175... - Page 6 Verve 2, 3 Gen 5 Headset 7 Nm Fastener (M6 x 33 mm) — 5263845 Compression nut (1 1/8”) Stem plug — 602179 5262988 Adjustable stem (85 mm) Bearing cover — W5260269 Split ring — 5319267 Headset bearings — W540243 Crown race reducer —...
