- Page 1 Operation instructions Capacitive sensor ANC33M-RE25 Agromatic AG Goldingerstrasse 30 8637 Laupen Switzerland Phone: +41 (0)55 256 21 00 info@agromatic.com www.agromatic.com Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 1 of 13...
-
Page 2: Table Of Contents
Type keys ......................10 6.2. Accessories ......................10 Copyrights / license terms ................11 Declaration of conformity ................11 Revision history ..................... 11 Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 2 of 13... -
Page 3: Safety Instructions
Keep the main control unit in the original packing at a suitable place until you finally place it. Please determine the final place before unpacking the unit. Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 3 of 13... -
Page 4: Instructions For Application In Dangerous Explosion Areas Acc. To Atex
The requirements of the standard regarding dust deposits and temperatures must be observed. 2. Scope of delivery Capacitive sensor ANC33M-RE25, with technical data sheet Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 4 of 13... -
Page 5: Mounting
It must be ensured that no explosive climate or dust deposits or swirls are present during assembly. Caution: Installation in Ex zone 22 is only permitted with the accessory set! Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 5 of 13... -
Page 6: Dimensions
Do not install these cables together or parallel with high voltage or high current leading cables; neither with cables driving frequency- controlled machines or motors (minimum distance 25cm). Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 6 of 13... -
Page 7: Adjustments
Adjust to driest and lightest material first, then check with dampest and heaviest material. (Response to all isolated materials with humidity approx. > ca. 5% and also to steel). Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 7 of 13... -
Page 8: Function
1.0 x Sn ≈ Water 1.0 x Sn ≈ Plastic 0.5 x Sn ≈ Glass 0.5 x Sn ≈ Wood 0.4 x Sn Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 8 of 13... - Page 9 When the switch is changed from A to B, the relay function is also changed! Drop-out delay Mode Sensor Contact 3 and 4 Contact 3 and 2 free closed Open covered is lighting opens (delayed) close Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 9 of 13...
-
Page 10: Maintenance
0003714 Sight glass-plate separation with Viton O-ring sealing A507/130, ATEX 0003724 Universal-Mounting set with plexiglass plate A512 3080016 Mounting bracket for 30mm sensors Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 10 of 13... -
Page 11: Copyrights / License Terms
Agromatic's products and services - including images, text and software downloads ("Content") - belong either to Agromatic AG or to third parties who have granted Agromatic permission to use the Content. Agromatic cannot give you permission to use content that belongs to third parties. - Page 12 Temperature range Operation -20°C bis +70°C Storage -25°C bis +70°C Max. Case temp. Additional temperature limit system (TF) Safety relevant data Protection class IP protection class IP65 Zone allocation ATEX certification Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41(0)552562100, www.agromatic.com V1.6...
- Page 13 B = pull-in delayed drop-out delayed, N.C. contact red / white 5 Cable Further information in the operating instructions! Instructions for correct installation Side by side mounting Non flush mounting Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41(0)552562100, www.agromatic.com V1.6...
