Summary of Contents for Agromatic Roto
- Page 1 Operation manual Speed detector support Roto Agromatic AG Goldingerstrasse 30 8637 Laupen Switzerland Phone: +41 (0)55 256 21 00 info@agromatic.com www.agromatic.com Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 1 of 9...
-
Page 2: Table Of Contents
Type plate ......................6 6.1. Type code ........................ 6 6.2. Matching sensors..................... 6 Copyrights / license terms ................7 Revision history ....................7 Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 2 of 9... -
Page 3: Safety Instructions
Keep the main control unit in the original packing at a suitable place until you finally place it. Please determine the final place before unpacking the unit. Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 3 of 9... -
Page 4: Instructions For Application In Dangerous Explosion Areas Acc. To Atex
The requirements of the standard with regard to dust deposits and temperatures must be observed. 2. Scope of delivery Speed detector support for inductive sensors with technical datasheet Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 4 of 9... -
Page 5: Mounting
A hole must be drilled in the centre of the shaft to be monitored and provided with an M8 thread. The shaft of the Roto speed vane can then be screwed onto this shaft. Use a removable thread adhesive for this purpose. -
Page 6: Maintenance
Article number Description 3080014 Speed detector support Roto 6.2. Matching sensors Article number Description 3060002 Inductive sensor ASI30-DC15, ATEX 0004023 Inductive sensor ASI18-DC8, ATEX Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41 (0)55 256 21 00, www.agromatic.com Page 6 of 9... -
Page 7: Copyrights / License Terms
Agromatic's products and services - including images, text and software downloads ("Content") - belong either to Agromatic AG or to third parties who have granted Agromatic permission to use the Content. Agromatic cannot give you permission to use content that belongs to third parties. - Page 8 4 impulses per rotation, max 350rpm Temperature range Operation -20°C bis +80°C Storage -25°C bis +80°C Max. case temp. 80°C Safety relevant data IP protection class IP67 ATEX certification none Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41(0)552562100, www.agromatic.com Page 8 of 9...
- Page 9 Mechanical data Dimensions (mm) max. 400 max. 250 Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Tel:+41(0)552562100, www.agromatic.com Page 9 of 9...
