Sealey VS5260 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instruction protection
manual
1. SAFETY
WARNING! Wear approved eye protection. Wear appropriate Personal Protective Equipment. A full range of Personal Protective
‰
Equipment is available from your Sealey stockist.
WARNING! Ensure that health & safety, local authority regulations and general workshop practice regulations are adhered to when
‰
using tools.
DO NOT use tools if damaged.
8
Maintain tools to ensure that they are in an adequate condition for safe use and optimum performance.
9
Ensure that a vehicle that has been raised by a jack is adequately supported. Use axle stands.
9
DO NOT attempt to start or move a vehicle whilst in gear and with timing devices fitted.
8
Wear suitable clothing to avoid snagging. DO NOT wear jewellery. Tie back long hair.
9
Account for all tools, parts and components being used. DO NOT leave these in or near the engine. Return tools to suitable storage
9
after use.
When not in use, store in a safe, dry childproof place.
9
Keep children and unauthorised persons away from the work area.
9
▲ IMPORTANT! These instructions are intended as a guide only. Always refer to the vehicle manufacturer's service instructions or a
proprietary manual to establish the correct procedure and data.
WARNING! The warnings, conditions and instructions in this manual cannot cover all possible conditions and situations. The Operator/
‰
User must apply caution and common sense (good practical sense).
When timing an engine, always prevent the engine from being turned over. Use a notice and/or inhibit the engine.
9
WARNING! Incorrect or out of phase camshaft timing can result in contact between the valve head and the piston crown. This will
‰
cause damage to the engine.
2. INTRODUCTION
Contents include Camshaft Alignment Tools, Crankshaft Alignment Tool and a Flywheel Locking Tool. Heavy-Duty Camshaft Holding
Tools ensure accurate positioning. Supplied in a storage case with full instructions.
3. CONTENTS
© Jack Sealey Limited
TIMING TOOL FOR MERCEDES, RENAULT,
NISSAN, DACIA 1.3 PETROL ENGINES
VS5260
MODEL NO:
1
2
Original Language Version
Item Part No.
1 VS5260-01
2 VS5260-02
3 VS5260-03
4 VS5260-04
OEM Tool(s):
Dacia:
3
Nissan:
Renault:
Mercedes:
Description
Flywheel locking tool
Crankshaft Setting Tool
Camshaft Setting Tool Set
Chain Tensioner Pin
MOT2188, MOT2203
MOT2188, MOT2203
MOT2188, MOT2203
282589004000, 282589002303,
282589002301, 282589002302
VS5260 Issue 3 (4) 21/05/25
