EB-810E/EB-815E
Quick Setup
IMPORTANT: Before using the projector, make sure you read these instructions
and the safety instructions in the online User's Guide.
Note: Product availability varies by country and region.
Note: The illustrations show the EB-810E, but the steps are the same for all
models, unless otherwise specified.
Connect the projector
Remove the side cover.
Computer
Choose from the following connections. See the sections below or the online
User's Guide for details.
HDMI cable
USB cable
HDMI
port
®
Connect one end of an HDMI cable to one of the projector's HDMI ports and
the other end to an HDMI port on your computer.
USB port
Connect the square end of a USB cable to the projector's USB-B (square) port.
Connect the flat end of the cable to any USB port on your computer.
Windows
7 or later: After turning on the projector, follow the on-screen
®
instructions to install the Epson
USB Display software (EMP_UDSE.EXE;
®
only on first connection). If the software screen does not display
automatically, open My Computer, Computer, or This PC, then double-click
EPSON_PJ_UD.
OS X 10.8.x or higher: After turning on the projector, the setup folder for
USB Display appears in the Finder. Double-click USB Display Installer and
follow the on-screen instructions to install the Epson USB Display software
(only on first connection). If the software screen does not display automatically,
double-click EPSON_PJ_UD, then double-click USB Display Installer.
HDBaseT
®
Connect the projector to an optional HDBaseT transmitter using a 100Base-TX
network cable. Use a Cat5e (Category 5e) STP cable or better.
Network cable

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EB-810E and is the answer not in the manual?

Questions and answers

Related Manuals for Epson EB-810E

Summary of Contents for Epson EB-810E

  • Page 1 IMPORTANT: Before using the projector, make sure you read these instructions and the safety instructions in the online User’s Guide. Note: Product availability varies by country and region. Note: The illustrations show the EB-810E, but the steps are the same for all models, unless otherwise specified. Connect the projector Remove the side cover.

  • Page 2: Using The Remote Control

    Note: If you connected a streaming device to an HDMI port, you can also connect it to the projector’s USB-A (flat) port for power. Camera, USB device, or document camera Connect a digital camera, USB flash drive, USB storage device, or Epson DC-07 document camera to the projector’s USB-A (flat) port. USB cable If you connect a digital camera, USB flash drive, or USB storage device, you can use the projector’s PC Free feature.

  • Page 3: Adjust The Image

    Turn on your equipment Remove the side cover, if necessary. Turn on your computer or video source. Make sure the power cord is connected and plugged into an electrical outlet. Press the power button on the projector or remote control. The projector beeps, and the status light flashes blue and then stays on.
  • Page 4 Select Network Settings and press Note: If you are prompted to enter a password for Epson Web Remote and for Epson Web Control, you can create a password or leave it blank. Select Wireless LAN as the Priority Control Interface setting.
  • Page 5 Install the optional software You can use Epson iProjection™ software to display wirelessly from a computer to your networked projector. Download the software and operation guide from your product’s support page (see “Where to get help”) and install the program on each computer that will project over the network.
  • Page 6 Open your web browser and enter the IP address of the projector you want to monitor in the browser’s address bar. The Epson Web Control menu opens.

  • Page 7: Troubleshooting

    Managing content You can manage content from your computer using the Epson Projector Content Manager software, or over the network using a web browser (Epson Web Control) or the Epson iProjection app. Using the Content Manager software The Epson Projector Content Manager software allows you to add images and movies to playlists and load them easily and directly to your projector via USB for playback.

  • Page 8: Optional Accessories

    (U.S. sales) or http://epsonstore.ca (Canadian sales). To find the nearest reseller in Latin America, go to http://latin.epson.com. EPSON is a registered trademark, the EPSON logo is a registered logomark, and Epson iProjection is a trademark of Seiko Epson Corporation. PrivateLine is a registered trademark of Epson America, Inc.
