PX - S1000
USER'S GUIDE (Basics)
Please keep all information for future reference.
Be sure to read the separate "Safety Precautions" and use the Digital Piano correctly.
These instructions provide general information about Digital Piano
operations. For more detailed information, refer to the User's
Guide available on the CASIO website, which you can access using
the nearby QR code or the URL below.
https://support.casio.com/global/en/emi/manual/PX-S1000/
• When the Digital Piano is being operated on battery power only, notes may sound distorted when
performing or playing back a song at maximum volume. This is due to the difference between AC adaptor
power and battery power, and does not indicate Digital Piano malfunction. If you notice distortion, switch to
AC adaptor power or lower the volume level.
Supported Operations
✔ 18 tones for keyboard play
☞THESE INSTRUCTIONS: "Selecting a Tone"
✔ Adjustable Touch Response
☞THESE INSTRUCTIONS: "Changing Keyboard
Response to Touch Pressure (Touch Response)"
✔ Hall simulator and surround effects
☞THESE INSTRUCTIONS: "Using the Sound Mode"
✔ Metronome to guide practice
☞THESE INSTRUCTIONS: "Using the Metronome"
✔ Duet Mode
☞THESE INSTRUCTIONS: "Splitting the Keyboard for
Duet Play"
✔ Built-in tune playback and practice
☞THESE INSTRUCTIONS: "Listening to Demo Play",
"Listening to Songs (Music Library)"
✔ Keyboard play recording
☞THESE INSTRUCTIONS: "Recording and Playing
Back Performances (MIDI Recorder)"
✔ Smart device linking for enhanced function
☞THESE INSTRUCTIONS: "Linking with a Smart Device
(APP Function)"
✔ Bluetooth connectivity for playing external
device audio through Digital Piano speakers
☞THESE INSTRUCTIONS: "Using the Digital Piano as a
Bluetooth Speaker System"
✔ Other useful features
• Keyboard pitch adjustment (Transpose, Tuning,
Octave Shift)
• Effects (Chorus, Brilliance)
• Acoustic piano sound characteristic adjustment
(Acoustic Simulator)
• 17 scales including equal temperament (Scale
Tuning)
• Connection to a computer for performance
information (MIDI data) exchange
☞CASIO WEBSITE: "User's Guide", "Keyboard
Function List", "Bluetooth, Audio Device, and
Computer Connection Guide"
✔ Troubleshooting
☞CASIO WEBSITE: User's Guide
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PX-S1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Casio PX-S1000

Summary of Contents for Casio PX-S1000

  • Page 1 Be sure to read the separate “Safety Precautions” and use the Digital Piano correctly. These instructions provide general information about Digital Piano operations. For more detailed information, refer to the User’s Guide available on the CASIO website, which you can access using the nearby QR code or the URL below. https://support.casio.com/global/en/emi/manual/PX-S1000/ •...
  • Page 2 General Guide Front Rear 1P (Power) button 9ELEC. PIANO button 2Volume knob bkPHONES jacks 3FUNCTION button blUSB port 4SOUND MODE button bmDAMPER PEDAL jack 5METRONOME button bnPEDAL UNIT jack 6a button boAUDIO IN jack 70 (REC) button bpLINE OUT R, L/MONO jacks 8GRAND PIANO button bqDC 12V terminal ■...
  • Page 3 Keyboard Function List Function settings can be configured by holding down a touch button as you press a keyboard key. For more information refer to the Keyboard Function List available from the CASIO website. ■ GRAND PIANO Button + Keyboard Key * ■...

  • Page 4: Included Accessories

    About Music Score data You can download music score data as a PDF file from the CASIO website, which you can access using the URL or QR code below. You will then be able to view music scores on your smart device. You can jump from the PDF file table of contents directly to the music score you want, and you can print out scores as needed.

  • Page 5: Getting Ready

    Getting Ready Preparing a Power Supply ■ Using the AC Adaptor Make sure that you use only the AC adaptor specified for this Digital Piano. Use of a different type of AC adaptor can cause malfunction. Specified AC Adaptor: AD-A12150LW (JEITA Standard plug) bq DC 12V Household power outlet...
  • Page 6 Connect the supplied pedal (SP-3) to the bm DAMPER PEDAL jack. This pedal functions as a damper pedal under initial Digital Piano default settings. For details about how to assign functions to this pedal, refer to the User’s Guide that is available on the CASIO website.

  • Page 7: Using Headphones

    34) to the bn PEDAL UNIT jack on the back of the Digital Piano. You can then use the pedals for expression that is similar to that available on an acoustic piano. ☞CASIO WEBSITE: User’s Guide Using Headphones Using headphones cuts off output from the built-in speakers, which means you can practice playing even late at night without disturbing others.

  • Page 8: Selecting A Tone

    Press the B1 keyboard key. This selects the JAZZ ORGAN tone and causes the confirmation tone to sound using the JAZZ ORGAN tone. Release 8 GRAND PIANO. • Now you can play on the keyboard with the JAZZ ORGAN tone. Selecting a Tone Your Digital Piano comes with 17 tones that are assigned to the entire keyboard range, plus one bass tone that can be...

  • Page 9: Listening To Demo Play

    Release 9 ELEC. PIANO. • Now when you press a keyboard key to play, the two tones you selected will sound at the same time. ■ To use split to play bass notes in the lower range Use the procedure under “Selecting a Single Tone” to select the upper range tone.

  • Page 10: Changing Keyboard Response To Touch Pressure (Touch Response)

    Changing Keyboard Response to Touch Pressure (Touch Response) Touch Response alters tone volume in accordance with keyboard pressure (speed). This provides you some of the same expressivity you get on an acoustic piano. ■ To change touch response sensitivity While holding down 8 GRAND PIANO, press a keyboard key from F{7 through B7.

  • Page 11: Specifying The Tempo

    ■ To change the metronome beat While holding down 5 METRONOME, press a keyboard key from C2 through A2. Pressing Selects this Which does this: this key: setting: Sounds a click for all beats. Sounds a bell for all beats. These keys specify a beat setting of 2 to 9.

  • Page 12: Using The Sound Mode

    Using the Sound Mode You can use 4 SOUND MODE to enable and disable the effects described below. ● Hall Simulator The hall simulator effect simulates the rich clarity, unconstrained brilliance, and other distinctive acoustic characteristics of world-famous concert halls and structures. You can also adjust the depth of the hall simulator effect.
  • Page 13 ■ To specify the Surround type While holding down 4 SOUND MODE, press the F1 (Surround Type 1) or F{1 (Surround Type 2) keyboard key. Release 4 SOUND MODE. Splitting the Keyboard for Duet Play You can split the keyboard in the center for duet play so the left and right sides have the same ranges.
  • Page 14 ■ To use the Duet Mode NOTE • For the location of the keyboard key used to configure the setting below, see the “FUNCTION Button + Keyboard Key” entry of the “Keyboard Function List”. While holding down 3 FUNCTION, press the C4 keyboard key.
  • Page 15 For details about the recording operation, refer to the User’s Guide that is available on the CASIO website. • Up to approximately 10,000 notes (total of two tracks) can...
  • Page 16 To record keyboard play Touch 70 (REC) so it lights white. This enters record standby, which is indicated by flashing 70 (REC) (red) and 6a (white) lights. To start recording, play something on the keyboard. This causes the 70 (REC) (red) light to change from flashing to lit, which indicates that recording is in progress.
  • Page 17 • Control the Digital Piano from a phone (Piano Remote Controller) • Transfer music data from a smart device ■ To download the smart device app Download the Chordana Play for Piano app from the CASIO website and install it on the smart device. https://support.casio.com/global/en/emi/manual/PX- S1000/...

  • Page 18: Product Specifications

    ■ To link to a smart device After installing the Chordana Play for Piano app on a smart device, use a commercially available USB cable to connect the smart device’s USB port with the Digital Piano’s USB port. After connecting the smart device to the Digital Piano, use the smart device app to perform operations.
  • Page 19 USER’S GUIDE (Basics) Inputs/Outputs: PHONES jacks: Stereo mini jacks (3.5mm) × 2; Power: 12V DC; AUDIO IN jack: Stereo mini jack (3.5mm) (Input impedance: 10kΩ, Input voltage: 200mV); LINE OUT R, L/MONO jacks: Standard jacks (6.3mm) × 2 (Output impedance: 2.3kΩ, Output voltage: 1.3V (RMS) MAX);...
  • Page 20 Music Library List Title Nocturne Op.9-2 C{1 Fantaisie-Impromptu Op.66 Étude Op.10-3 “Chanson de l’adieu” Étude Op.10-5 “Black Keys” Étude Op.10-12 “Revolutionary” Étude Op.25-9 “Butterflies” Prélude Op.28-7 Valse Op.64-1 “Petit Chien” Valse Op.64-2 Moments Musicaux 3 Impromptu Op.90-2 Marche Militaire 1 (Duet) Frühlingslied [Lieder Ohne Worte Heft 5] C{2 Fröhlicher Landmann [Album für die Jugend] Von fremden Ländern und Menschen...
  • Page 21 Title Gymnopédie 1 C{5 Je Te Veux Salut d’Amour The Entertainer Maple Leaf Rag L’arabesque [25 Etüden Op.100] La Styrienne [25 Etüden Op.100] Ave Maria [25 Etüden Op.100] Le retour [25 Etüden Op.100] La chevaleresque [25 Etüden Op.100] No.13 [Études de Mécanisme Op.849] No.26 [Études de Mécanisme Op.849] *1 Keyboard Key Note Name...

  • Page 22: Operating Precautions

    Operating Precautions Be sure to read and observe the following operating precautions. Location Avoid the following locations for this product. • Areas exposed to direct sunlight and high humidity • Areas subjected to temperature extremes • Near a radio, TV, video deck, or tuner The above devices will not cause malfunction of the product, but the product can cause interference in the audio or video of a nearby device.
  • Page 23 AC Adaptor Handling Precautions • Never insert metal, pencils, or any other objects into the product’s DC12V terminal. Doing so creates the risk of accident. • Do not try to use the power cord that comes with the product with another device. •...
  • Page 24 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Declaration of Conformity Model Number: PX-S1000 Trade Name: CASIO COMPUTER CO., LTD. Responsible party: CASIO AMERICA, INC. Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801 Telephone number: 973-361-5400...
  • Page 25 • Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal use, any other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.
