PX - S1100

USER'S GUIDE (Basics)

Please keep all information for future reference.

Be sure to read the separate "Safety Precautions" and use the Digital Piano correctly.

These instructions provide general information about Digital Piano

operations. For more detailed information, refer to the User's Guide

available on the CASIO website. Also refer to the "Keyboard

Function List", "Wireless MIDI & audio adaptor, Audio and Computer

Connection Guide", and "MIDI Implementation" on the website.

https://support.casio.com/global/en/emi/manual/PX-S1100/

• When the Digital Piano is being operated on battery power only, notes may sound distorted when

performing or playing back a song at maximum volume. This is due to the difference between AC adaptor

power and battery power, and does not indicate Digital Piano malfunction. If you notice distortion, switch to

AC adaptor power or lower the volume level.

Supported Operations

✔ 18 tones for keyboard play

☞THESE INSTRUCTIONS: "Selecting a Tone"

✔ Adjustable Touch Response

☞THESE INSTRUCTIONS: "Changing Keyboard

Response to Touch Pressure (Touch Response)"

✔ Hall simulator and surround effects

☞THESE INSTRUCTIONS: "Using the Sound Mode"

✔ Metronome to guide practice

☞THESE INSTRUCTIONS: "Using the Metronome"

✔ Duet Mode

☞THESE INSTRUCTIONS: "Splitting the Keyboard for

Duet Play"

✔ Built-in tune playback and practice

☞THESE INSTRUCTIONS: "Listening to Demo Play",

"Listening to Songs (Music Library)"

✔ Keyboard play recording

☞THESE INSTRUCTIONS: "Recording and Playing

Back Performances (MIDI Recorder)"

✔ Smart device linking for enhanced function

☞THESE INSTRUCTIONS: "Linking with a Smart Device

(APP Function)"

✔ Using the Digital Piano's speakers to sound

playback from a smart device connected

using Bluetooth

☞THESE INSTRUCTIONS: "Using the Included Wireless

MIDI & audio adaptor"

✔ Other useful features

• Keyboard pitch adjustment (Transpose, Tuning,

Octave Shift)

• Effects (Chorus, Brilliance)

• Acoustic piano sound characteristic adjustment

(Acoustic Simulator)

• 17 scales including equal temperament (Scale

Tuning)

• Connection to a computer for performance

information (MIDI data) exchange

✔ Troubleshooting

☞CASIO WEBSITE: User's Guide

wireless technology.

Table of Contents

Need help?

Do you have a question about the PX-S1100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Casio PX-S1100

Page 1 For more detailed information, refer to the User’s Guide operations. For more detailed information, refer to the User’s Guide available on the CASIO website. Also refer to the “Keyboard available on the CASIO website. Also refer to the “Keyboard Function List”, “Wireless MIDI &...
Page 2 General Guide Bluetooth Indicator Front Rear 1P (Power) button 9PHONES jacks 2Volume knob bkUSB Type B port 3FUNCTION button blUSB Type A port 4SOUND MODE button bmDAMPER PEDAL jack 5METRONOME button bnPEDAL UNIT jack 6a button boLINE OUT R, L/MONO jacks 70 (REC) button bpDC 12V terminal 8GRAND PIANO button...
Page 3 Keyboard Function List Function settings can be configured by holding down a touch button as you press a keyboard key. For more information refer to the Keyboard Function List available from the CASIO website. ■ GRAND PIANO Button + Keyboard Key ■...
Page 4 About Music Score data You can download music score data as a PDF file from the CASIO website. You will then be able to view music scores on your smart device. You can jump from the PDF file table of contents directly to the music score you want, and you can print out scores as needed.
Page 5: Getting Ready
Getting Ready Preparing a Power Supply ■ Using the AC Adaptor Make sure that you use only the AC adaptor specified for this Digital Piano. Use of a different type AC adaptor can cause smoking or malfunction. Specified AC Adaptor: AD-A12150LW (JEITA Standard plug) bp DC 12V Household power outlet...
Page 6 Connect the supplied pedal (SP-3) to the bm DAMPER PEDAL jack. This pedal functions as a damper pedal under initial Digital Piano default settings. For details about how to assign functions to this pedal, refer to the User’s Guide that is available on the CASIO website.
Page 7 34) to the bn PEDAL UNIT jack on the back of the Digital Piano. You can then use the pedals for expression that is similar to that available on an acoustic piano. ☞CASIO WEBSITE: User’s Guide Using Headphones Using headphones cuts off output from the built-in speakers, which means you can practice playing even late at night without disturbing others.
Page 8: Selecting A Tone
To save power, you can configure a setting that will turn off all button lights, except for 3 FUNCTION, after a certain period of non-operation. ☞CASIO WEBSITE: User’s Guide Selecting a Tone Your Digital Piano comes with 17 tones that are assigned to the entire keyboard range, plus one bass tone that can be assigned to lower range only.
Page 9: Listening To Demo Play
Press a keyboard key within the range of A0 through C{2 to sound both tones at the same time. • For information about the tone assigned to each keyboard key, see the “GRAND PIANO Button + Keyboard Key” entry in the “Keyboard Function List”. Release 8 GRAND PIANO.
Page 10: Changing Keyboard Response To Touch Pressure (Touch Response)
Changing Keyboard Response to Touch Pressure (Touch Response) Touch Response alters tone volume in accordance with keyboard pressure (speed). This provides you some of the same expressivity you get on an acoustic piano. ■ To change touch response sensitivity While holding down 8 GRAND PIANO, press a keyboard key from F{3 through B3.
Page 11: Specifying The Tempo
■ To change the metronome beat While holding down 5 METRONOME, press a keyboard key from C2 through A2. Pressing Selects this Which does this: this key: setting: Sounds a click for all beats. Sounds a bell for all beats. These keys specify a beat setting of 2 to 9.
Page 12: Using The Sound Mode
Using the Sound Mode You can use 4 SOUND MODE to enable and disable the effects described below. ● Hall Simulator The hall simulator effect simulates the rich clarity, unconstrained brilliance, and other distinctive acoustic characteristics of world-famous concert halls and structures. You can also adjust the depth of the hall simulator effect.
Page 13 ■ To specify the Surround type While holding down 4 SOUND MODE, press the F1 (Surround Type 1) or F{1 (Surround Type 2) keyboard key. Release 4 SOUND MODE. Splitting the Keyboard for Duet Play You can split the keyboard in the center for duet play so the left and right sides have the same ranges.
Page 14 ■ To use the Duet Mode NOTE • For the location of the keyboard key used to configure the setting below, see the “FUNCTION Button + Keyboard Key” entry of the “Keyboard Function List”. While holding down 3 FUNCTION, press the C6 keyboard key.
Page 15 For details about the recording operation, refer to the User’s Guide that is available on the CASIO website. • Up to approximately 10,000 notes (total of two tracks) can be recorded for a single song.
Page 16 To record keyboard play Touch 70 (REC) so it lights white. This enters record standby, which is indicated by flashing 70 (REC) (red) and 6a (white) lights. To start recording, play something on the keyboard. This causes the 70 (REC) (red) light to change from flashing to lit, which indicates that recording is in progress.
Page 17 • Turn off the Digital Piano before disconnecting the Wireless MIDI & audio adaptor. ■ Connecting with External Devices Refer to “Wireless MIDI & audio adaptor, Audio and Computer Connection Guide” in the User’s Guide, which you can access at the CASIO website. https://support.casio.com/global/en/emi/manual/PX-S1100/...
Page 18: Product Specifications
(Piano Remote Controller function), and to use various other app functions. • For details about operations, refer to the user documentation of each app. Download the smart device app from the CASIO website and install it on the smart device you want to use. https://support.casio.com/global/en/emi/manual/PX-S1100/ Product Specifications Model: PX-S1100BK/PX-S1100WE/PX-S1100RD Keyboard: 88-key piano keyboard;...
Page 19 USER’S GUIDE (Basics) Pedals: Included SP-3 pedal assignable functions: Damper (off, on), sostenuto (off, on), soft (off, on), metronome (start, stop), tempo setting; Separately available SP-34 pedal unit: Damper (off, half, on), sostenuto (off, on), soft (off, on) Other Functions: Auto Resume; Operation Lock; Notification tones (Selectable sets 1, 2, 3;...
Page 20 Music Library List Title Nocturne Op.9-2 C{2 Fantaisie-Impromptu Op.66 Étude Op.10-3 “Chanson de l’adieu” Étude Op.10-5 “Black Keys” Étude Op.10-12 “Revolutionary” Étude Op.25-9 “Butterflies” Prélude Op.28-7 Valse Op.64-1 “Petit Chien” Valse Op.64-2 Moments Musicaux 3 Impromptu Op.90-2 Marche Militaire 1 (Duet) Frühlingslied [Lieder Ohne Worte Heft 5] C{3 Fröhlicher Landmann [Album für die Jugend] Von fremden Ländern und Menschen...
Page 21 Title Gymnopédie 1 C{6 Je Te Veux Salut d’Amour The Entertainer Maple Leaf Rag L’arabesque [25 Etüden Op.100] La Styrienne [25 Etüden Op.100] Ave Maria [25 Etüden Op.100] Le retour [25 Etüden Op.100] La chevaleresque [25 Etüden Op.100] No.13 [Études de Mécanisme Op.849] No.26 [Études de Mécanisme Op.849] *1 Keyboard Key Note Name...
Page 22: Operating Precautions
Operating Precautions Be sure to read and observe the following operating precautions. Location Avoid the following locations for this product. • Areas exposed to direct sunlight and high humidity • Areas subjected to temperature extremes • Near a radio, TV, video deck, or tuner The above devices will not cause malfunction of the product, but the product can cause interference in the audio or video of a nearby device.
Page 23 AC Adaptor Handling Precautions • Never insert metal, pencils, or any other objects into the product’s DC12V terminal. Doing so creates the risk of accident. • Do not try to use the power cord that comes with the product with another device. •...
Page 24 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Declaration of Conformity Model Number: PX-S1100 Trade Name: CASIO COMPUTER CO., LTD. Responsible party: CASIO AMERICA, INC. Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801 Telephone number: 973-361-5400...
Page 25 • Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal use, any other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.
