Solar Powered Tyre Pressure
Monitoring System
TPMS
User Guide
WARNING
THIS PRODUCT CONTAINS BUTTON/COIN CELL BATTERIES
Button/coin cell batteries are hazardous and must be kept out of reach of children at all times, whether the battery is new
or used. These batteries can cause severe or fatal injuries in 2 hours or less if swallowed or placed inside any part of the
body. If it is suspected a button/coin cell battery has been swallowed or placed inside any part of the body, seek medical
attention immediately or contact the Australian Poisons Information Centre on 131126 for 24/7 fast, expert advice.
TPS10-4E - With 4 Sensors
TPS10-6E - With 6 Sensors
Advertisement
Table of Contents
Related Manuals for Oricom TPS10-4E
Summary of Contents for Oricom TPS10-4E
- Page 1 TPS10-4E - With 4 Sensors TPS10-6E - With 6 Sensors Solar Powered Tyre Pressure Monitoring System TPMS WARNING THIS PRODUCT CONTAINS BUTTON/COIN CELL BATTERIES Button/coin cell batteries are hazardous and must be kept out of reach of children at all times, whether the battery is new User Guide or used.
- Page 2 Pack Includes LCD Display X4 or X6 Washers x5 or x7 Nuts x5 or x7 X4 or X6 Ensure that these parts are stored safely.
- Page 3 Product Overview Select button SET button Solar panel Ventilation holes Micro USB input Charging status Pressure data Axles of trailer Temperature unit Pressure unit Warning indicator Temperature data Display battery indicator interface Trailer interface Spare interface...
- Page 4 Display ON/OFF Press any button for 3 seconds to turn on the display. Press “ “ button for 3 seconds to turn off the display. Display installation Installation position Place the anti-slip mat under the display USB charging connection Micro USB Plug USB charger (Not included)
- Page 5 Sensor position F.L. F.R. R.L. R.R. F.R. R.R. Note: Typical sensor position as per diagram to the left. F.L. R.L. Sensor installation 2.Insert the dustproof cover into the valve stem 1.Unscrew the valve cap 3.Screw in the nut 4.Screw on the sensor...
- Page 6 5. Tighten up the nut to the sensor by using the 6. Check air leakage by spraying soapy water spanner Sensor battery replacement 1.Unscrew the nut 2.Unscrew the sensor 3.Take out the washer 4.Unscrew the sensor cover by using 5.Replace the battery 6.Repeat steps in “Sensor installation”...
- Page 7 tyre >25km / h Installation is complete when all tyre data has been received and is showing on the display.
- Page 8 Sensor programming(All sensors in package are preprogrammed) When programming a new sensor or a missing sensor to the display. Press " " button 5 times, the display will beep 4. The tyre data will be shown on the display, once and enters programming mode. then press “...
- Page 9 Alerts High temperature Sensor failure Display low battery...
-
Page 10: Function Settings
Function settings Enter/Exit the setting mode Press “ “ button for 4 seconds to enter the setting mode, a beep will sound. Press “ “ button for 4 seconds to exit the setting mode two beeps will sound. The setting sequence as below: Time interval of Pressure unit Temperature unit... - Page 11 Temperature unit setting: In temperature unit setting , press “ ” button to select the temperature unit, then press “ ” button once to save and move to the next setting; Time interval setting of each interface: In time interval setting page, press “ ”...
- Page 12 Low pressure value setting: In low pressure value setting page. press button to select the low pressure value, once you have reached the desired value press button once to enter the next setting. High temperature value setting: In high temperature value setting page. press button to select the high temperature value, once you have reached the desired value.
- Page 13 Trailer axles setting: Enabled status(default) Disabled status Spare Tyre settings (individual): Enabled status(default) Disabled status Tyre data deletion: In tyre data deletion page, press button to select the programmed tyre data to be deleted. Then hold button until the display shows "--", the tyre data has been deleted.
-
Page 14: Specifications
Specifications 2.3~3.3V temperature: –20℃~ + 80℃/ -4℉~ + 176℉ 2.5mA –20℃~ + 70℃/ -4℉~ + 158℉ Adjustable Alarm Value: High pressure value: 2.6~7.9Bar/37~115PSI Low pressure value: 0.9~3.9Bar/13~55PSI High temperature value: 70~90℃/ 158℉~ 194℉ Default Value: High pressure value: 3.3Bar/47PSI Low pressure value: 1.7Bar/24PSI High temperature value: 80℃/176℉... - Page 15 Disclaimer 1. (TPMS) is designed for vehicles with tyre pressure up to 6.0 Bar/ 86PSI. 2. All sensors in this unit have been pre-set individually for each tyre in the factory. 3. Whenever the location of tyre changed, the sensors must be changed to the corresponding tyre.
-
Page 16: Troubleshooting
Troubleshooting 1. After the installation, there is no tyre data on the display * The sensors were not programmed to the display, please reprogram the sensors * The display should show the real time tyre data automatically when the speed is over 25km/h 2. -
Page 17: Express Warranty (Australia)
“Oricom”. replacement product of its choosing that is at least South Windsor NSW 2756 Australia Oricom warrants that the product is free from defects in equivalent to your product in performance. Please note that this Express Warranty excludes... - Page 18 How to make a claim under your Express Warranty in Australia Oricom has a simple warranty process for you to follow: • Please call or email our Customer Support Team, 02 4574 8888 or support@oricom.com.au. • A Customer Support Team member will verify after troubleshooting with you if your product qualifies under warranty.
- Page 19 Oricom Support - Australia For all product enquiries, troubleshooting or to discuss the range of Oricom products, feel free to contact Oricom or visit our website for answers to frequently asked questions. 02 4574 8888 Monday - Friday 8am –...
