Mactronic MAVERICK Manual

AHL0051
/ EN
Focus Control Headlight
SPECIFICATION
Light source
Runtime and
operation modes
Sensor mode
Power supply
Auxiliary power supply
Dimensions
Weight
Waterproofness
Light range
Charging time
Impact resistance
Focus
* Flashing mode specifications cannot be measured by ANSI FL1 standard.
Flashing mode runtime is based on measurement of battery capacity change only.
Thank you for choosing the Mactronic product. To ensure high durability and reliability
of the product, please operate and maintain it properly. Please read the following
instructions and keep it for future reference, as they contain important information on
safe operation and use.
NOTICE
It is not recommended to use the flashlight for purposes other than intended. The
manufacturer explicitly voids the warranty if the flashlight has been used for other than
its intended purpose.
FLASHLIGHT OPERATION
To turn the flashlight on, press the button located at the top of the housing. The
flashlight will turn on with the: SENSOR MODE (the sensor mode is active when the
switch on the flashlight is lit blue). With this mode on, you can turn the flashlight on and
off alternately by moving your hand close to the optical motion sensor (in front of the
head of the flashlight, more towards the left). To adjust the light power with the active
mode: SENSOR, press and hold the button. Power will be alternately and steplessly
reduced to 5% (double blink) and then it will be steplessly increased to reach 100%
(double blink). Release the button to choose the light power you want. Press the button
on the flashlight again to switch between the available modes. The modes will change
in the following sequence: SENSOR MODE (510 lm) -> HIGH (510 lm) -> MEDIUM (240
lm) -> LOW (30 lm) -> FLASHING -> OFF. If the time between presses to change the
mode of operation exceeds 5 seconds, the flashlight will turn off.
*The flashlight has a FOCUS (light beam adjustment) function.
CHARGING
To install the rechargeable battery, open the battery compartment lid by prying the
snap-in connector up. Starting from the positive pole of the rechargeable battery, place
the rechargeable battery in the battery compartment. Observe the arrows inside the
battery compartment. To install the batteries, remove the rechargeable battery and
place AAA batteries observing the markings inside the battery compartment.
To charge the rechargeable battery, connect the supplied USB cable to the mains
Cree XP-L White LED
WHITE HIGH - 2 h 30 min - 510 lm
WHITE MEDIUM - 5 h 30 min - 240 lm
WHITE LOW - 21 h - 30 lm
FLASHING* - 1 h 30 min
510 lm
Li-Poly 3.7V 800 mAh
3 x AAA
62 x 46 x 45 mm
97 g
IP64
150 m
2 h 30 min
2 m (Drop-proof)
Yes
