- Page 1 LATCH 5 FINGERPRINT Smart Fingerprint Lock Installation Guide V1.1 Need help? To get help or learn more https://support.u-tec.com...
- Page 2 Part Code Part Name Quantity Exterior Assembly Interior Mounting Plate Interior Assembly Handles Cover Spindle Spring Backup Keys AA Batteries Latch Strike Reset Needle Screwdriver Drilling Template Screw Code Screw Name Quantity #8 x 3/4" Wood Screws #8-32 x 1-3/8" Machine Screws M4x25 Machine Screw (Optional) BB + M4 x 30+6 Stud Screw (Optional)
- Page 3 Install latch and strike Prepare the door. Φ2/5” (10mm) Drill the hole if needed. Part Code Part Name Quantity Exterior Assembly Interior Mounting Plate BB + Interior Assembly 1-3/8” - 1-3/4” Handles Cover Spindle (35 mm - 44mm) Spring Backup Keys AA Batteries Latch Strike...
- Page 4 Install exterior keypad assembly Make sure the triangle is facing upwards as illustrated.
- Page 5 Route the cable above the bolt and through the hole stated below.
- Page 6 Install Interior Mounting Plate. Screw BB #8-32 x 1-3/8" Machine Screws...
-
Page 7: Install Interior Assembly
Install interior assembly Install the spring if the door thickness is over 1.65”(42mm). Plug in the spindle. Spring Spindle Interior Exterior... - Page 8 Attach the connectors as indicated and secure the interior assembly. Screw C #8-32 x 5/16" Machine Screws Screw D #8-32 x 15/32" Machine Screws...
- Page 9 Install batteries and cover. Screw E #4-32 x 15/32" Captive Screw...
- Page 10 Install interior / exterior lever Place the handles to the opposite direction of the door’s edge.
- Page 11 Using the hex wrench provided, screw the set screw anticlockwise inside the handle base.
