- Page 1 XR900-5 CLASS D FIVE CHANNEL POWER AMPLIFIER INSTRUCTION MANUAL 5声道D类功率放大器 使用说明书 © 2012 JVCKENWOOD Corporation B64-5065-00/00 (WV)
-
Page 2: Safety Precautions
(such as coins or metal tools) inside the unit. • If the unit starts to emit smoke or strange smells, turn off the power immediately and consult your Kenwood dealer. • Do not touch the unit during use because the surface of the unit becomes hot and may cause burns if touched. -
Page 3: Protection Function
Protection function The protection function is activated in the following situations: This unit is equipped with a protection function for protecting this unit and your speakers from various accidents or problems that can occur. When the protection function is triggered, the power indicator goes off and the amplifier stops operating. -
Page 4: Installation
Installation / 安装 7 Accessories / 附件 Self-tapping screws / 自攻螺钉 ø 4 x 16 mm Hexagon wrench / 六角扳手 2.0 mm Hexagon wrench / 六角扳手 2.5 mm Hexagon wrench / 六角扳手 4.0 mm 260 mm 242 mm ø 4.6 2 Parts included 1 Parts included 配件... - Page 5 7 Installation procedure Since there are large variety of settings and connections possible according to applications, read the instruction manual well to select the proper setting and connection. 1. Remove the ignition key and disconnect the negative · terminal of the battery to prevent short circuits.
- Page 6 Connection / 连接 WARNING Particular attention must be given to making good electrical contact at the amplifier-output and speaker terminals. Poor or loose connections can cause sparking or burning at the terminals because of the very high power that the amplifier can deliver. CAUTION •...
- Page 7 Remove the ignition key and disconnect the negative · terminal of the WARNING battery to prevent short circuits. 拔取点火钥匙，拆掉蓄电池负极·端子，以防短路。 警告 7 Power wire and speaker wire connection 3 Parts included Center unit (CD receiver, etc.) 电源线和扬声器线的连接 配件 中心装置（CD 接收机等） (2.5 mm) Power control wire 电源控制缆线...
- Page 8 Connection / 连接 Connection / 连接 A.ch B.ch SUB 7 RCA cable connections 7 RCA cable connections ■ 5 7 连接RCA 缆线 7 连接RCA 缆线 ■ 7 About the Lead Terminals 7 关于导线端子 1. Wire Thicknesses 1. 导线截面 Center unit (CD receiver, etc.) Center unit (CD receiver, etc.) You can use wires with the following 您可以使用以下粗细的导线：...
- Page 9 7 About the Lead Terminals 1. Wire Thicknesses You can use wires with the following thicknesses: Battery wire and AWG 4 – AWG 6 ground wire Speaker wire AWG 8 – AWG 16 2. Strip the wire Make a cut in the wire sheath (insulator made from vinyl, etc.) at the position 10-13 mm away from the end of the wire, and then remove the...
- Page 10 ystem examples / 系统配置实例 System examples / 系统配置实例 System examples / 系统配置实例 ■ 5-channel system 5-channel system ■ 5 声道系统 5 声道系统 ■ 5-channel system ■ 5 声道系统 Front left speaker Front left speaker 前置左扬声器 前置左扬声器 Front left speaker Center unit 前置左扬声器...
- Page 11 For the pre-output level, refer to the <Specifications> in the If you can’t find the specified capacity fuse at your store etc., 控制本机的接通／关闭。 instruction manual of the center unit. consult your Kenwood dealer. 注 9 BASS BOOST LEVEL control (SUB) 2 Battery terminal (BATT.) Sets the low frequency level to be compensated.
-
Page 12: Stereo Connections
1 Fuse (40 A x 3) NOTE If you can’t find the specified capacity fuse at your store etc., consult your Kenwood dealer. 2 Battery terminal (BATT.) 3 Power control terminal (P.CON) Controls the unit ON/OFF. NOTE Controls the unit power. - Page 13 6 SPEAKER OUTPUT terminals (SUB) As this unit accepts speakers with a minimum impedance of 2 ohms, connect speakers with 2-ohm or higher impedance to these terminals. 7 LINE IN terminal (A.ch/B.ch/SUB) 8 INPUT SENSITIVITY control (A.ch/B.ch/SUB) Set this control according to the pre-output level of the center unit connected with this unit.
-
Page 14: Troubleshooting Guide
Troubleshooting guide What might appear to be a malfunction in your unit may just be the result of slight misoperation or miswiring. Before calling service, first check the following table for possible problems. PROBLEM POSSIBLE CAUSE SOLUTION No sound. • Input (or output) cables are disconnected. •...
