Quick Installation Guide
AX3000 Dual Band Gigabit Wi-Fi 6 Router
RX12 Pro/TX12 Pro
Package contents
• Wireless router x 1
• Power adapter x 1
• Ethernet cable x 1
• Quick installation guide x 1
Please read this guide before you start with the quick setup upon the first use.
For product or function details, please go to www.tendacn.com to download the user guide.
Advertisement
Table of Contents
Related Manuals for Tenda RX12 Pro
Summary of Contents for Tenda RX12 Pro
- Page 1 Quick Installation Guide AX3000 Dual Band Gigabit Wi-Fi 6 Router RX12 Pro/TX12 Pro Package contents • Wireless router x 1 • Power adapter x 1 • Ethernet cable x 1 • Quick installation guide x 1 Please read this guide before you start with the quick setup upon the first use.
- Page 2 Scenario1: Set up the device as a router I. Connect the router Step 2: Connect the WAN port of the router The "new router" and "router" in this guide refer to the router in the package. Step 1: Import your PPPoE user name and password into Note the new router (Optional) If you use the modem for internet access, please power off the modem first...
- Page 3 II. Connect the router to the internet Method 1: Setup through Tenda WiFi App 1. Download the Tenda WiFi App onto your mobile device by scanning the QR code or searching for Tenda WiFi in Google Play or App Store. Then install the Tenda WiFi App.
- Page 4 Method 2: Setup through web UI 1. Connect the client to the router. Method 1: Connect the wireless client such as a mobile phone to the WiFi network of the router. The SSID and password can be found on the bottom label of the device. Method 2: Use an Ethernet cable to connect the computer to the 1, 2 or IPTV/3 port of the router.
- Page 5 Then, click Start Now. tendawifi.com English Welcome to Tenda WiFi Faster, Safer, Smoother, Smarter Start Now Scan to download Tenda WiFi Manage your router easily Tips If you cannot log in to the web UI, refer to Q1 in FAQ.
- Page 6 3. The router detects your connection type automatically. − If you have imported your PPPoE user name and password into the router, click Next. − If you did not import your PPPoE user name and password into the router, select the ISP Type based on your region and ISP and enter required parameters (if any).
- Page 7 4. Set the WiFi name, WiFi password and login password for the router. Click Next. English Internet access is a few steps away! Detect Internet Internet Settings Complete WiFi Settings Connection Type WiFi Name Tenda_XXXXXX WiFi Password ••••••••• Not encrypted Set WiFi password to router login password Next Previous...
- Page 8 Done. Detect Internet Internet Settings WiFi Settings Complete Connection Type Configuration completes. You can access the internet now Current WiFi network is cut off. Please connect to the new WiFi network WiFi Name Tenda_XXXXXX WiFi Password Login Password Complete To access the internet with: - Wired devices: Connect to the LAN port of your router.
- Page 9 LED indicators&Jack, ports and buttons indicator After the router is powered on for about 40 seconds, the system completes startup. The status of the LED indicator is shown in the following table. LED indicator Node Type Description Status The system is starting up, or the router is already Solid green connected to the internet.
- Page 10 Tips Please ensure that the router has never been used. If not, reset it first. • Currently, RX12 Pro/TX12 Pro can be networked with the same model, Mesh6X, • Mesh12X, RX27 Pro, or TX27 Pro. 1. Place the router in an elevated and open position within 3 meters from your existing node.
- Page 11 LED indicator blinks red fast. When the LED indicator lights solid green, your device is reset successfully. Q3: The device failed to be detected by the Tenda WiFi app upon my first time using the device, what should I do? A3: Try the following solutions: 1.
- Page 12 Q4: When I use the product as a router, I cannot access the internet after the configuration. What should I do? A4: Try the following solutions: • Check whether the WAN port of the router is connected to a modem or Ethernet jack properly.
-
Page 13: Safety Precautions
Safety Precautions Before performing an operation, read the operation instructions and precautions to be taken, and follow them to prevent accidents. The warning and danger items in other documents do not cover all the safety precautions that must be followed. They are only supplementary information, and the installation and maintenance personnel need to understand the basic safety precautions to be taken. - Page 14 Declaration of Conformity Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the radio equipment types RX12 Pro, TX12 Pro are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.tendacn.com/download/list-9.html...
-
Page 15: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 16 RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment. User has the choice to give his product to a competent recycling organization or to the retailer when he buys a new electrical or electronic equipment.
-
Page 17: Technical Support
Copyright © 2022 Shenzhen Tenda Technology Co., Ltd. All rights reserved. Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and product names mentioned herein are trademarks or registered trademarks of their respective holders. Specifications are subject to change without notice.
