ITY-8LDX
DESI-Less 8 Button IP Reference Sheet
MAKE A CALL
Lift the Handset or press Speaker.
Dial the required number.
(For external calls, dial "0" first)
LAST NUMBER REDIAL
Without lifting handset, press the REDIAL
button.
Press the Cursor key left/right to search
the required number.
Press
to initiate the call.
Ask the caller to please hold:
Press the Hold key.
You may replace handset if you wish.
To retrieve a call:
Lift the handset.
Press the flashing line.
NOTE:
For exclusive hold – press Hold twice.
TRANSFER
With a call in progress:
Press the Transfer key.
Dial an extension or external number and
announce the call (optional).
Replace the handset.
NOTE:
If the called extension is busy or does not
answer, press the Transfer to return to your
caller. If the extension does not accept the call,
ask them to hang up and your call is returned.
Menu
From this key, the user may access additional
functions such as Setting and Config.
Soft Keys
Any feature shown at the bottom of the LCD is
available. The appropriate feature key is
displayed on the screen according to the call
handling process.
Programmable Keys
These keys can be programmed as either a
Flexible Line key, Programmable Feature key or
One-Touch Speed Dial key.
Cursor Key
®
HOLD
ITY-8LDX DESI-Less
FUNCTION KEYS
CONFERENCE
With a call in progress (internal or external)
Press the Transfer key.
Dial an internal or external number.
When the third party answers, press the
Conf soft key.
A three way conference is now
established.
NOTE:
Any party may exit the conference by hanging
up. The two parties will remain connected, as
long as one of the remaining parties is internal.
SWAP CALL
Allows users to toggle between calls
Press the Transfer key (this puts the first
call on hold and provides you with dial
tone to call the 2
Dial required 2
Press the Transfer key each time you
wish to toggle between the parties.
When finished with one party, hang up on
them and the telephone will ring and
connect you to the other party.
nd
party).
nd
number.
NDA-31743
Issue 1.0
