Netscape ENTREPRISE SERVER 6.1 - 04-2002 ADMINISTRATOR Administrator's Manual page 264

Allowing Users to Monitor Individual Virtual Servers
For security reasons, this administration user interface is on a separate port from
either the administration server port or the Enterprise Server instance port.
This user interface runs on a virtual server within the Administration Server. This
virtual server is set up by default and is called useradmin. You must set up a listen
socket in the administration server that is separate from the listen socket the
administration server runs on, so that people can access the virtual server
administration user interface without having access to your Administration Server
port.
Figure 11-1 shows the administrators of individual virtual servers accessing the
useradmin virtual server in order to access the information for their virtual servers.
Figure 11-1
VS1
Admin
VS2
Admin
VS3
Admin
When you turn on a virtual server, users can administer it through the following
URL:
server_name:port/
For example:
http://example:8889/user-app/example/vs2
The server instance doesn't include the "https" portion of the server instance name.
To configure your server to use this feature, follow these steps:
264 Netscape Enterprise Server Administrator's Guide • April 2002 (Draft)
Configuring virtual server administrator's user interface
Admin
Server
Port 8888
Virtual
Server
useradmin
Port 8889
Firewall
/server_instance/virtual_server_ID
user-app
Server Instance
VS1
VS2
VS3
