Sangean POCKET 640 Quick Start Manual

Quick Start Guide
Battery operation
Before you insert the batteries, check the NiMH/Alkaline
switch position.
If you use non-rechargeable batteries, make sure the
NiMH/Alkaline switch which located inside the battery
compartment is switched to Alkaline position. If you
use rechargeable batteries, make sure to switch NiMH/
Alkaline switch to NiMH position.
Insert two LR6 (AA size) batteries into the space in
the compartment. Ensure the batteries are inserted in
accordance with the diagram shown.
Charging the batteries
Make sure the radio is switched off and connected to the power source.
When the battery charge indicator LED flashes green, this indicates the batteries
are charging. Batteries will be fully charged in around 3-5 hours. The battery charge
indicator LED shows steady green light when the battery charging process is
complete.
Using USB cable to charge (European Version)
Use USB cable to connect your radio to any power source with a USB port (e.g.PC)
to charge.
1. Plug the Micro USB end into the Micro USB socket of the radio.
2. Plug the other end of the USB cable into any power source with USB port (e.g.PC).
Using the USB power adapter (Australian Version)
Use the USB power adapter to provide power to your radio and charge the battery.
1. Plug the Micro USB end into the Micro USB socket of the radio.
2. Plug the power adapter into a wall socket.
Listening to the Radio
1. Extend the antenna.
If needed, when the antenna is fully extended you
can stabilize the radio using the foldable stand
located on the rear of your radio.
2. Press and hold the Power button to switch on your
radio. You can also press and release this button to
view the clock time.
3. Press the Band button to select DAB or FM and
switch between them.
(DPR-64)
GB
