Sangean DPR-35 Manual

Hide thumbs

Advertisement

Table of Contents

DPR-35
GB
Version 1

Advertisement

Table of Contents
loading

Related Manuals for Sangean DPR-35

Summary of Contents for Sangean DPR-35

  • Page 1 DPR-35 Version 1...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 3 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged. liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 5 Controls Headphone socket Lock switch (Note: If this is activated, your radio will not operate.) Telescopic antenna Power button Volume button LCD display Loudspeaker Tuning/ Menu jog wheel DC socket...

  • Page 6: Charging The Radio

    Charging the radio T h e D P R 3 5 f e a t u r e s a b u i l t i n  8 5 0 m A H L i t h i u m rechargeable battery to power the radio.

  • Page 7: Setting The Clock

    Setting the clock The DPR-35’s clock will automatically update each time you turn on the radio and tune to a DAB+ radio station or to an FM station which is broadcasting the time via RDS. Time display will flash 0:00 for a few seconds then display the clock time when it receives DAB+ or FM –...

  • Page 8: Menu Functions

    Service Information – DAB+ The Service Information display - Technical information on the current status of the station being broadcast. While listening to DAB+, continually press in the jog wheel to cycle through information on a. Program type (PTY) b. Multiplex Name c.
  • Page 9 ● Back press in the jog wheel to go back to the previous menu display. ● Manual Tune press in and turn the jog wheel to scroll the whole station list. Press in the jog wheel to select desired station. B) Back Press in the jog wheel to go back to current listening status.
  • Page 10 You should not attempt to update your radio unless it is recommended to you by Sangean Customer Services. Updating the software may remove all network settings and radio station presets from your radio. Software updates for your radio may be available in the future.
  • Page 11 ● Set contrast Turn and press in the jog wheel to select required LCD display contrast. Display contrast will change accordingly. ● Set backlight Press in the jog wheel to select Backlight Auto. Select YES and display backlight will auto shut off 2 seconds after last operation.
  • Page 12 ● Sleep Use the Sleep menu to set auto shut off timer. Press in the jog wheel to cycle through: Sleep off (auto shut off disabled), 90-60-45-30-15 Auto shut off timer. Radio will turn off after selected sleep time has elapsed. E) Favourites –...

  • Page 13: Service Information

    Operating your radio – FM . Turn on the radio by pressing Power button. Press in jog wheel for 2 seconds to enter Menu. Turn the jog wheel and scroll to FM Mode and press in to select the FM band. Searching tuning - FM .
  • Page 14 A) Distant/Local When using the FM mode your radio can be set to either scan local stations or to scan all stations including distant radio stations. Press in and turn the jog wheel to enter the setting. Select ‘Local’: only the stations with the strongest signals are found during scanning Select ‘Distant’: all available stations are found during scanning...
  • Page 15 You should not attempt to update your radio unless it is recommended to you by Sangean Customer Services. Updating the software may remove all network settings and radio station presets from your radio. Software updates for your radio may be available in the future.
  • Page 16 ● Set contrast Turn and press in the jog wheel to select required LCD display contrast. Display contrast will change accordingly. ● Set backlight Press in the jog wheel to select Backlight Auto. Select YES and display backlight will auto shut off 2 seconds after last operation.

  • Page 17: Key Lock Function

    Stations which have been stored in the preset favorites list may be overwritten by following the above procedures. ● Recall a station Press in the jog wheel to find “Preset Recall”. Turn the jog wheel to find the preset station you wish to recall. Press in the jog wheel to select.
  • Page 18 If the battery does not recharge after several attempts, it may be drained (has a low charge), please contact info@sangean.com.tw for repair information. However, if you do not want us to replace the battery, you will need to dispose of used batteries/device in accordance to the laws and regulations in your area.

  • Page 19: Specifications

    Specifications Power Requirement: Mains (via supplied AC adaptor) AC 00-240 50/60 Hz DC5V 500 mA Batteries: 3.7V/850 mAH Battery Life: Approx 20 hours listening through the speaker for 4 hours a day at normal volume. Approx 28 hours of listening with headphones for 4 hours a day at normal volume.
