EN
Reference: SIN-2-2-01
Power supply: 230V AC ~ 50Hz
Switching capabilities: 230V AC - 2 x 5A
Consumption: <1W
Maximum output power: 2 x 1150W (Resistive load)
List of compatible loads available on nodon.fr/loads
Radio frequency range: 868.0 to 868.6 Mhz
RF power max: +3dBm
Range: up to 30m indoor
Operational temperature: -10°C to 40°C
Protection rating: IP 30
Pairing: up to 22 controllers
EEP (EnOcean Profile): D2-01-12
Dimensions: 40 mm (l) x 44 mm (L) x 16.9 mm (h)
Weight: 34 g
Warranty: 2 years
• Never use the device if it is not correctly installed and
placed inside a connecting box in conformity with the
current norms.
• Keep the product far away from liquids.
DETAILED
USER GUIDE
Directly access the detailed user
guide on the Support section
on nodon.fr/en/technical-
support/
CONTACT
NodOn SAS
121 rue des Hêtres
45590 St CYR EN VAL
(FRANCE)
ON/OFF LIGHTING
RELAY SWITCH
USE CAUTIONS
USER GUIDE
AFTER SALES SERVICE
nodon.fr/en/ "support" section
support@nodon.fr

Advertisement

loading
Need help?

Need help?

Do you have a question about the SIN-2-2-01 and is the answer not in the manual?

Questions and answers

Related Manuals for nodon SIN-2-2-01

Summary of Contents for nodon SIN-2-2-01

  • Page 1 Switching capabilities: 230V AC - 2 x 5A Consumption: <1W Maximum output power: 2 x 1150W (Resistive load) List of compatible loads available on nodon.fr/loads Radio frequency range: 868.0 to 868.6 Mhz RF power max: +3dBm Range: up to 30m indoor Operational temperature: -10°C to 40°C...

  • Page 2: Approvals And Certifications

    APPROVALS AND CERTIFICATIONS Hereby, NodOn SAS declares that this radio equipment is conform to the RED directive 2014/53/UE. The integral text of the EU declaration of conformity is available at the following online address: nodon.fr/en/ ”support” section. The presence of this symbol on a product indicates that this one is conform to the European directive 2012/19/UE.
  • Page 3 RELAY SWITCH INPUT/OUTPUT Terminal for the Neutral Terminal for the Line Input terminal for the wired switch 1 * Input terminal for the wired switch 2 * Output 1 (controlled by Output 2 (controlled by Each terminal can accept a cable of 2.5mm² maximum, stripped of 8mm.

  • Page 4: Pairing Procedure

    PAIRING PROCEDURE To add a remote or a wall switch or the Soft Button (EnOcean compatible) you must enter the pairing mode, your light must be switched OFF. Relay switch must be power supplied. FOR CHANNEL 1 ( Two modes: 1.
  • Page 5 The Soft Button will work as follows: Types of press Action Single press Reversal Double press Long press PAIRING WITH A HOME AUTOMATION GATEWAY For more details on how to pair a home automation gateway or other compatible products, please consult the “Support” section on nodon.fr/en/...

  • Page 6: Reset Procedure

    UNPAIRING PROCEDURE Do the same procedure as pairing (see “pairing procedure”) and takes care of pressing the button chosen to control your gate/ garage door/electric latch or your electrical outlet. RESET PROCEDURE Relay switch must be power supplied. Press more than 5 seconds on your module’s button. The LED blinks orange.
